Seite 1/2
Wired External Sounder
User Manual
EN 50131-1:2006 + A1:2009 + A2:2017 + A3:2020
EN 50131-4:2019
Security Grade 2
Environmental Class IV
Hangzhou Hikvision Digital Technology CO.,Ltd.
No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China
UD37740B-A
1 Appearance
2 Wiring
User Manual Flow Chart
More Languages
Buzzer Indication Operation
Fire Alarm Fire bell.
Medical Alarm
High and low frequemcy alternated
impulsive sound.
Alarm Rapid high frequency impulsive sound.
No. Description
1 Strobe Light
2 Water-Proof Transparecy Cover
3 Buzzer
4 Tamper
5 Strobe Light and Sounder Jumper Cap
6 Tamper Terminal
7 Wiring Terminal
8 Tone Mode Jumper Cap
9 Cut Off Mode Jumper Cap
B
A
1
3
2
Sounder Wiring
All Mode
Positive Active Mode
Negative Active Mode
A
Buzzer Description
Appearance Description
Use a tool (drill) to dig a hole on the wiring hole area.
Make sure the hole's edge has no burrs.
Wiring Hole
1.1 Unbox.
1.2 Check components and indication.
Check the specifications of the device.
Connect cables to the wiring terminals.
Install the device to the wall.
1 Appearance
4 Check Specification
2 Wiring
3 Installation
1
2
3
4
6
5
7
9 8
2.2K
STB+STB-BELL+ TR TR
- +
BELL
Z C
ZONE
1 2
PGM
2.2K
External Sounder (DS-PS102X)
BELL-
ALL MODE
Control Panel
2.2K
PSU
BELL TRSTB B- B+
SIREN
2.2K
STB+STB-BELL+ TR TR
- +
BELL
Z C
ZONE
1 2
PGM
2.2K
External Sounder (DS-PS102X)
BELL-
NEGATIVE ACTIVE
Control Panel
STB+STB-BELL+ TR TR
2.2K
External Sounder (DS-PS102X)
BELL-
NEGATIVE ACTIVE
PSU
BELL TRSTB B- B+
SIREN
STB+STB-BELL+ TR TR
- +
AUX
Z C
ZONE
2.2K
External Sounder (DS-PS102X)
BELL-
POSITIVE ACTIVE
Control Panel
NC4 NO4COM4
OUTPUT4
COM4=12V
0 V 12 V
NC3 NO3COM3
OUTPUT3
STB+STB-BELL+ TR TRBELL-
ALL MODE
External Sounder (DS-PS102X)
B
Jumper Cap Descriptions
Fire Alarm
Medical Alarm
Alarm (Default)
Tone Mode
