HangzhouHikfireTechnologyCo.,Ltd

Address:Room311,UnitB,Building2,No.399,DanfengRoad,Binjiang

District,HangzhouCity,ZhejiangProvince,China

Tel:0086400-800-5998

HF-S2/HF-S2E

PhotoelectricSmokeDetector

UD41268B

DiagramReferences

ENGLISH

Appearance

1

Dateofreplacement:10years

Technicaldata:seeDoP(https://www.hikvision.com/europe/support/download/

declaration-of-conformity/)No.HKF-2022001heldbythemanufacturer

EN14604:2005

EN14604:2005/AC:2008

1.Beforeinstallation,confirmthatthedetectorandothermountingpartsareingoodcondition.

2.Donotinstallthedetectorinneworrenovatedbuildingsuntilallworkiscompleted.(Dust

anddebrisfrombuildingworkcancontaminatethesmokechamber).

3.Installmultipledetectorsiftheinstallationlocation(suchasceiling)islongerthan32.81ft(10

meters).

•WhereNottoInstall:

-Dampandhumidareassuchaskitchen,hotwaterheater,andbathroom.

-Forcedairsupplyductsforheatingorcooling,ventilatingfans,orotherhighairflowareas.

-Dusty,dirty,orinsectinfestedareas.

-Hotandgreasyareassuchasstoves.

-Wheredrapesandotherobjectswillblockthesensors.

-Within4.92ft(1.5meters)offluorescentlights.

-Deadairspacessuchasapexesofceilings,cornersoftherooms.

Notification:

Installation

2

3

4

Off

TheredLEDison.

Rapidbeeps

LowVoltage

1beepevery

40seconds

LEDIndicator

ConditionBuzzer

Standby

FireAlarm

MazeDirty

TheredLEDflashesevery60seconds.

TheredLEDflashesevery40seconds.

Every40secondstheredLEDflashesrapidlyfortwice.

Note:Whenthemazedirtyalarmistriggered,contactthetechnicalsupport.

2.1

MountingParts

2.2

MountingLocation

2.3

InstallationMethod

Features

Check

CeilingMountingwithoutJunctionBox

CeilingMountingwithJunctionBox

()HF-S2only

>19.69"

Best

Acceptable

>19.69

"

(500mm)

>19.69

"

(500mm)

(500mm)

2.3

2.1

4

FireAlarm

Instandbymode,whenthesmokeparticlesinthesmokesensorreachaspecified

value,thedetectorentersthealarmmode.

Test

VerifythatthebuzzerandLEDindicatorareworkingproperly.

Instandbymode,pressthe

TEST/SILENCE

button,thedetectorentersthetest

mode;aftertesting,itautomaticallyresumestothestandbymode.

TestMode:Thebuzzerbeepsfor5times,andtheredLEDison.

Mute

Inalarmmode,pressthe

TEST/SILENCE

buttontosilencethedetector.

MuteMode:Thebuzzerwillstopbeeping,andtheredLEDison.

MutePeriod:Afterthedetectorissilenced,ifthesmokeconcentrationthat

causedthealertcontinues,thedetectorwillreactivatein8minutes.

Reset

Whenthedetectorisinmutemode,pressthe

TEST/SILENCE

button,thedetector

resumestothestandbymode.

Inalarmmode,ifthesmokedissipatesandthesmokeconcentrationfallsbelowthe

specifiedvalue,thedetectormodewillbedeactivatedandthedetectorwill

automaticallyresumetothestandbymode.

Method

Bringlitcigarettesorsmokegeneratingequipmentclosetothedetector,sothat

thesmokeenterstheairinletofthedetector.

Result

Afterthesmokeconcentrationreachesaspecifiedconcentration,thedetectorwill

betriggered.The,andthebuzzerwillbeeprapidly.redLEDison

Tokeepyourdetectoringoodorder,pleasefollowthesesteps:

1.Verifythebuzzerandindicatoroperationbypressingthe

TEST/SILENCE

button

onceaweek.

2.Whenthedetectorisinmazedirtystate,usingcompressedairoravacuum

cleanerhosetocleanthedetector,andvacuumorblowairthroughtheopenings

aroundthedetector.

3.Neverusealcohol,detergentorotherchemicalsolventstocleanthedetector.

4.Avoidsprayingairfresheners,hairsprayorotheraerosolsnearthedetector.

Maintenance

Cleaning

5

6

5.5mm

5.5mm

φ

φ

Air-

Duster

HF-S2

HF-S2E

ModelHF-S2HF-S2E

Approval

Smokesensor

Alarmsoundlevel

Powersupply

Faulttype

Alarmoutput

Standbycurrent

Alarmcurrent

Temperature

Humidity

Dimensions(φ×H)

Weight

Withoutpackaging:

112g±10g

Withpackaging:

265g±15g

Withoutpackaging:

112g±10g

Withpackaging:

220g±15g

4µAMAX

27mAMAX

-10°Cto55°C(14°Fto131°F)

≤95%nocondensing

/

1-chIOoutput

3VDC

106mm×49.5mm

ComplieswithEN14604:2005,

ComplieswithEN14604:2005/AC:2008

Photoelectric

≥85dB@3m(for1minute)

≥82dB@3m(morethan4minutes)

Mazedirty,lowbattery

HF-S2HF-S2E

HIKFIRE

Removeallbatteriesbeforecleaning.
