Spec-00212 I

FREESTAND CABINETS PROLINE™ AccEssORIEs

EQUIPMENT PROTECTION SOLUTIONSSUBJECT TO CHANGE WITHOUT NOTICENETWORKING1

Spec-00212

763.422.2661

763.422.2588

NETWOR KING

Free-Stand Cabinet S

PrOLine™ aCCeS SOrieS

FRAME JOINING KITS

Permits joining two enclosure frames while maintaining an

environmental seal.

Side-to-Side Joining Kit consists of six frame nuts and screws, as

well as gasket material to maintain a dust-tight and water-tight seal

between ganged frames. Can be used if rack angles are not in the

front or rearmost positions or if a subpanel is not in the rearmost

position.

Alternate Joining Kit consists of three standoffs, six frame nuts

and screws, as well as gasket material. This kit facilitates frame

joining when rack angles are in the front or rearmost position, or if

a subpanel is in the rearmost position.

Front-to-Back Joining Kit permits front-to-back joining of two

single-bay enclosures. This kit does not fit 1200-mm or 1600-mm

wide frames.

BulletIn: p20, p20eM

Catalog Number Description

PJ2F Standard Frame Joining, Side-to-Side

PJ2FD Standard Frame Joining, Side-to-Side, Non-gasketed

PJ2FHF2 EMC Standard Frame Joining, Side-to-Side

PJ2FF Alternate Frame Joining, Side-to-Side

PJ2FBF Frame Joining, Front-to-Back

Spec-00212 I

Free-Stand CabinetS PROLINE™ AccEssORIEs

PH 763.422.2661 • FAX 763.422.2588 • HOFFMANONLINE.COMEQUIPMENT PROTECTION SOLUTIONS networking 2

L Joining braCket

The L Joining Bracket, made of 10

gauge steel, is used in conjunction

with the standard joining kit as

additional support. Pictured

hardware is included.

BulletIn: p20

Catalog Number Description

PJB2F L Joining Bracket

Frame Feet

Four die-cast feet for use on the

bottom of PROLINE™ frames that

raise the frame 9 mm.

BulletIn: p20

Catalog Number Description

PFFM12 Frame Feet

tooL-LeSS (Snap-in) bLanking paneLS For 19-in. raCkS

These Tool-less 19-in. Blanking

Panels provide easy tool-less

installation and ensure proper

airflow to equipment. Made of black

composite material and can be used

with tapped or square EIA universal

spaced rack mounting angles.

BulletIn: DAccY

Catalog Number

Description

Rack

Units Fits

Pkg.

Qty.

D19BPT1RU Blanking Panel, 19 in. 1 19 in., universal rack spacing,

tapped or square holes

D19BPT2RU Blanking Panel, 19 in. 2 19 in., universal rack spacing,

tapped or square holes



LeveLerS

Four post-type levelers allow

adjustment for uneven floors.

Levelers can be attached to the

bottom of a frame or to a 0-mm solid

base. Levelers are plated and the

leveler base is capped with plastic

to provide resistance to marring.

Adjustable for 17-mm to 35-mm

height. Ball and socket construction.

Four levelers will support a

maximum of 453.6 kg (1000 lb.).

BulletIn: p20

Catalog Number Description

PLM12 Post-type Levelers
