Fig 2-1

Features

Important notices

Battery

Installation

Fig1 PARALOW HS403B Red Dot Sight

www.holosun.com

HS403B

PARALOW

Thank you for purchasing the PARALOW HS403B Red Dot

sight,Please read the User's Manual carefully.

1.The HS403B projects its aiming dot in

a way that prevents visibility when viewed from the front

beyond several meters.

2.The user can gain

rapid target acquisition and situational awareness while aiming

with both eyes open.

3. Only a few micro-amperes of current

are required for sight operation. Sight runs on one battery for

up to 30,000 hours.

Concealed aiming:

Full field of view for target acquisition:

Low power consumption:

4. The sensitive motion sensor will turn the

power on with any motion detection when in sleep mode.

5. arallax 1MOA

Motion power on:

Parallax free optical system:Pis.

≤

±

6. The sight will be automatically entered into

sleep mode motionless for 8 hours.

7. There are 12 settings(10 Daylight+2NV)

for the reticle so as to match the ambient lighting conditions.

8.The sight will remember the last saved

brightness setting when powered on and off.

9 The top mounted buttons allow

Sleep time delay:

Brightness adjustment:

Memory function:

.

Two top mounted buttons:

for easy operation without obstructing the user's vision.

10. IP67 Waterproof:

1. Ensure that the firearm is completely unloaded and safe

before device installation or installing/replacing the

battery.

2. Please keep the packaging should you need to make a

warranty claim.

1.The operating voltage for this device is DC3V using one high

quality CR2032 Lithium battery.

2.The battery life is rated up to 50,000 hours at a mid-brightness

setting.

3.Battery Replacement:

Please follow the steps below for battery replacement

1. The included mount is

compatible with Picatinny Rails.

2. First insert the appropriate Torx wrench(included) into the

crossbolt head, then rotate to loosen cross bolt then

attach the sight into a suitable position,

and finally tighten the clamp screw to 15 IN/LBS using

non-permanent thread locker. (Fig3)

Bri ghtness Decrease

Bri ghtness Increase

Protective Cap

Objective Lens

Eyepiece Lens

T10 Torx Crossbolt

Model

Fig 3

Clamp

screw head

Cross bolt

2) Battery installation(Fig2-2):

a) Insert the battery into the battery tray 2032 with

oriented with the POSITIVE SIDE DOWN.

b) Insert and press the tray into the battery compartment.

c)

Fasten screw 1,2.

Caution:

The loss or damage of seal ring will cause water to leak into

the compartment and may damage electronic circuits and

the device.

when battery runs out or for other conditions that require

the battery to be changed :

1) Removing the battery (Fig 2-1):

a)Loosen screws 1,2.

b)Insert coin or similar object in the battery tray slot, pry

out the battery tray, and remove the discharged battery

by lifting it up. A tool is provided for this purpose.

Fig 2-2

Slot

Screw 1

Screw 2

Screw 2

Screw 1

Battery

cabin

Battery

Seal ring

Sight operation

The operation panel is on the top of sight.(see Fig4)
