HOW TO READ THE MANUAL
Some paragraphs in the manual contain important information regarding
safety and operation and are emphasized in this manner:
NOTE
or
IMPORTANT
It gives details or further infor-
mation on what has already been said, and aim to prevent damage to the
machine.
WARNING!
Non-observance will result in the risk of injury to
oneself or others.
DANGER!
Non-observance will result in the risk of serious
injury or death to oneself or others.
The manual describes several machine models that can mainly dier in:
– type of transmission: with hydrostatic continuous speed adjustment.
– particular ttings and/or attachments.
The symbol
highlights all the dierences in usage and is followed by the
indication of the version to which it refers.
The symbol “
” refers to another part of the manual where further informa-
tion or clarication can be found.
NOTE
Whenever reference is made to a position on the ma-
chine “front”, “back”, “left” or “right” side, this refers to the positions of the
seated operator.
INTRODUCTION
Dear Customer,
thank you for having chosen one of our products. We hope you will be com-
pletely satised with your new ride-on lawnmower and that it will fully meet
all your expectations.
This manual has been compiled in order that you may get to know your ma-
chine and to be able to use it safely and eciently. Don’t forget that it forms
an integral part of the machine, so keep it handy so that it can be consulted
at any time, and pass it on to the purchaser if you resell the machine.
This new machine of yours has been designed and made in line with current
regulations, and is safe and reliable if used for cutting and collecting grass
exactly following the instructions given in this manual (proper usage). Using
the machine in any other way or ignoring the instructions for safe usage,
maintenance and repair is considered “incorrect usage” (
5.1) which will
invalidate the guarantee, and the manufacturer will decline all responsibility,
placing the blame with the user for damage or injury to himself or others
insuch cases.
Since the product is continually being improved, you may nd slight dier-
ences between your machine and the descriptions contained in this manual.
Certain modications can be made to the machine without prior warning and
without the obligation to update the manual, although the essential safety and
function characteristics will remain unaltered. In case of any doubts, do not
hesitate to contact your Dealer. And now enjoy your work!
After-sales Service
This manual provides all the necessary information to run the machine and
for correct basic maintenance operations which can be performed by the
user. Contact your Dealer for operations not described in this manual.
INDEX
1. SAFETY REGULATIONS ....................................................2
Regulations for using the machine safely
2. IDENTIFICATION OF THE MACHINE
AND COMPONENTS ...........................................................5
Explanations on how to identify the machine and its main com-
ponents
3. UNPACKING AND ASSEMBLY ...........................................6
Explanations on how to remove the packing and on how to as-
semble separated parts
4. CONTROLS AND INSTRUMENTS ................................... 8
Position and functions of all the controls
5. OPERATING INSTRUCTIONS ..........................................12
Provides indications for working eciently and safely
5.1 Safety recommendations ......................................... 12
5.2 Why the safety devices cut in ................................... 12
5.3 Preliminary operations before starting work ............. 13
5.4 Using the machine ................................................... 14
5.5 Using on slopes ....................................................... 17
5.6 Transport position .................................................... 18
5.7 Advice on how to obtain a good cut ........................... 18
5.8 Summary of main steps to follow when
using the machine .........................................................19
6. MAINTENANCE ..............................................................19
All the information for maintaining the machine in peak ef-
ciency
6.1 Safety recommendations ......................................... 19
6.2 Routine maintenance .............................................. 20
6.3 Checks and adjustments ............................................ 21
6.4 Dismantling and renewing parts ............................... 24
7. TROUBLESHOOTING ..................................................... 27
A help in quickly resolving any problems
8. ATTACHMENTS ON REQUEST ........................................29
A description of the attachments available for particular types
of work
9. TECHNICAL SPECIFICATIONS .........................................30
A summary of the main specications of your machine
10. ALPHABETICAL INDEX ................................................. 31
Where information can be found
MAJOR HONDA DISTRIBUTOR ADDRESSES ............... i
“EC Declaration of Conformity”
CONTENT OUTLINE ....................................................... ii
1 EN
ORIGINAL INSTRUCTIONS
INSTRUCTION MANUAL
HF2317 • HF2417 • HF2625
Ride-on lawnmower
Honda France Manufacturing S.A.S.
Pôle 45 - Rue des Châtaigniers - 45140 ORMES - FRANCE
All rights reserved
Write your machine’s model here
H F 2 _ _ _ _ _ _
Note your machine serial number here
M A _ _ _ _ _ _ _ _ _
12-2019 Printed in Italy
ENGLISH
CG71505502H16 • HF2317 - HF2417K5 - HF2625
– Add fuel, using a funnel, only outdoors; do not smoke during this
operation and each time fuel is handled;
– Top-up with fuel before igniting the engine; never remove the tank
cap or add fuel while the engine is running or when it is hot;
– If you have spilled some fuel, do not attempt to ignite the engine
but move the machine away from the area of spillage and avoid
creating any source of ignition until the fuel has evaporated and
fuel vapours have dissipated;
– Always put the tank and fuel container caps back on and tighten
well;
– Do not inhale fuel fumes.
– Open the fuel tank slowly to allow the pressure inside to decrease
gradually.
– Never start the machine in the same place in which you relled it
with fuel; the engine must be started in an area at least 3 metres
from where you refuelled.
– If fuel is spilt on clothing, change clothing before starting the en-
gine.
5) Replace faulty silencers.
6) Before using the machine, check its general condition and in
particular:
the appearance of the cutting means, and check that the screws
and cutting-means assembly are not worn or damaged. Replace the
entire cutting means and all damaged or worn screws to preserve
balance. Any repairs must be done at a specialised centre.
7) Check the battery status regularly, and replace it if there is any
damage to the casing, cover or terminals.
8) Before starting work, always t the exit guards (grass catcher, rear
discharge guard).
C) DURING USE
1) Do not operate the engine in a conned space where dangerous
carbon monoxide fumes can develop. All starting operations have
to be eected in an open or well ventilated area. Always remember
that exhaust gases are toxic. When starting up the machine, do not
direct the silencer and therefore the exhaust fumes towards am-
mable materials.
2) Work only in daylight or with good articial light in good visibility
conditions. Keep persons, children and animals away from the work-
ing area. Get another adult to keep the children under supervision.
3) Avoid working with wet grass, in the rain and when there is a risk
of a thunderstorm, especially lightening.
4) Before igniting the engine, disengage the cutting means or the
power socket and put the gear in neutral.
5) Pay special attention when approaching obstacles that could
compromise visibility.
6) Engage the parking brake when parking the machine.
7) The machine must not be used on slopes of over 10° (17%), re-
gardless of the mowing direction.
8) Remember there is no such thing as a "safe” slope. Driving on
grass slopes requires particular care. To prevent overturning or loss
of control over the machine:
– Do not stop or start suddenly when going up or downhill.
– Engage the drive slowly and always keep the machine in transmis-
sion, especially when travelling downhill;
– Machine speeds should be kept low on slopes and during tight
turns;
– Watch out for humps, hollows and other hidden hazards;
– Never mow across the face of the slope. Lawns on a slope have
to be mowed moving up and down and never across them. When
changing direction, take great care that the wheels facing the
slope do not hit any obstacles (such as stones, branches, roots,
etc.) that may cause the machine to slide sideways, tip over or
make you lose control.
9) Reduce speed before any change of direction on slopes, and
always apply the parking brake before leaving the machine at a
standstill and unattended.
10) Be very careful near ravines, ditches or embankments. The ma-
chine could overturn if a wheel slides over the edge or if the earth
gives way.
1. SAFETY REGULATIONS
1.1 GENERAL SAFETY REGULATIONS
WARNING!
READ THE INSTRUCTION BOOKLET THOR-
OUGHLY BEFORE USING THE MACHINE. Keep for future refer-
ence.
A) TRAINING
1) WARNING! Read these instructions carefully before operating
the machine. Become acquainted with the controls and the proper
use of the machine. Learn how to stop the engine quickly. Failure to
follow the warnings and instructions may result in re and/or serious
injury. Save all warnings and instructions for future reference.
2) Never allow children or persons unfamiliar with these instructions
to use the machine. Local regulations may restrict the age of the
operator.
3) Never mow while people, especially children, or pets are nearby.
4) Never use the machine if the user is tired or unwell, or has taken
medicine, drugs, alcohol or any substances which may slow his
reexes and compromise his judgement.
5) Bear in mind that the operator or user is responsible for accidents
or unexpected events occurring to other people or their property. It is
the user’s responsibility to assess the potential risk of the area where
work is to be carried out, and to take all the necessary precautions
to ensure his own safety and that of others, particularly on slopes or
rough, slippery and unstable ground.
6) If the machine is sold or lent to others, make sure that the operator
looks over the user instructions contained in this manual.
7) Do not allow children or other passengers to ride on the machine
as they could fall o and injure themselves or compromise safe driv-
ing by the operator.
8) The machine operator must follow the driving instructions carefully
and, in particular:
– Avoid distractions and maintain concentration whilst working;
– Bear in mind that control of a machine sliding on a slope will not
be regained by the application of the brake. The main reasons for
loss of control are:
• Insucient wheel grip;
• Excessive speed;
• Inadequate braking;
• Type of machine unsuitable for its task;
• Lack of knowledge about eects which may result from soil
conditions, especially on slopes;
• Incorrect use as a towing machine.
9) The machine is supplied with a series of micro-switches and safety
devices which must never be tampered with or removed; this will
invalidate the warranty and relieve the manufacturer from all respon-
sibility. Always check that the safety devices are working properly
before using the machine.
B) PRELIMINARY OPERATIONS
1) While using the machine, always wear anti-slip and resistant work
footwear and long pants. Do not operate the machine when barefoot
or wearing open sandals. Never wear scarves, shirts, necklaces,
bracelets, clothing with owing parts, laces or ties or any hanging or
apping accessory that could catch in the machine or in any objects
or materials in the work area. Tie hair back if it is long. Wear hearing
protection devices.
2) Use of hearing protections can reduce the ability to hear any warn-
ings (shouting or alarms). Be careful of what occurs around you in
the work area.
3) Thoroughly inspect the entire work area and remove anything that
could be thrown by the machine or damage the cutting-means as-
sembly or engine (stones, branches, iron wire, bones, etc.).
4) WARNING: DANGER! Petrol is highly ammable.
– Keep the fuel in approved containers, in a safe place, away from
any naked lights or heat sources. Keep the containers out of the
reach of children.
2EN
Produktspezifikationen
| Marke: | Honda |
| Kategorie: | Rasenmäher |
| Modell: | HF 2417 K5 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Honda HF 2417 K5 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Rasenmäher Honda
24 Juli 2025
9 September 2024
31 August 2024
31 August 2024
31 August 2024
31 August 2024
31 August 2024
31 August 2024
17 August 2024
13 August 2024
Bedienungsanleitung Rasenmäher
- McConnel
- MacAllister
- Worx
- Klippo
- Hyundai
- IKRA
- Robust
- Walker
- Cocraft
- Cub Cadet
- Powerplus
- Zipper
- DeWalt
- Ashiko
- MTD
Neueste Bedienungsanleitung für -Kategorien-
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
25 Juli 2025
