4

2

BEFORE

1

Installation Guide

resideo.com

C-WIRE ADAPTER

Online Guides and Support

Remove your old thermostat from

the wall plate.

Overview

This product provides a C wire (common wire) to power a

thermostat. Only install if you do not have a C wire available to

connect to your thermostat.

5

Open HVAC system’s cover

to reveal the control board.

6

Take a picture of the wires

on the control board.

Ensure the terminal labels

and wires are in the image.

You may need to reference

the picture later.

*

O or B terminal may also be used.

CONTINUE

7

Use stickers to label the

following connected wires:

8

Disconnect ONLY the wires

that you just labelled:

AFTER

Do not remove any wires

at this time!

ZONING CONTROL PANEL CHECK

For zoned systems, install the C Wire Adapter

between the thermostat and the zoning panel, NOT

between the zoning panel and HVAC equipment.

3

Take a picture of the wiring.

Ensure the terminal labels

and wires are in the image.

You may need to reference

the picture later.

Confirm that you do not have

a wire in the C terminal. If

you have a wire in the

C terminal, then you do not

need this product.

Look for an unused wire. If

you have an unused wire,

then you do not need this

product. Connect one end of

that wire to C terminal at the

HVAC and the other to C

terminal at new thermostat.

*

The C wire (common) might be

labeled as B rather than C on certain

thermostats.

Go to your HVAC system. It may be located in your

attic, crawl space or basement.

G

R Rcor

•

•

EXAMPLE

W W1or

Y Y1or

•

•

*

Not all systems will have a

W or W1-wire. On a heat pump

application, the wire coming from

O/B on the old thermostat would

match to either O or B at equipment

rather than W.

**

If multiple wires are connected

to a terminal, only label the the wire

running to your thermostat.

G

R Rcor

•

•

W W1or

Y Y1or

•

•

*

Do NOT disconnect wires that you

did not label.

**

If multiple wires are connected

to a terminal, only remove the the

wire running to your thermostat.

***

On a heat pump application,

the wire coming from O/B on the old

thermostat would match to either O

or B at equipment rather than W.

M38945

HVAC

Thermostat

M38946

HVAC

C-Wire

Adapter

Thermostat

M38947

OFF

Turn the power off at the

breaker box or control

switch for your HVAC*

system.

*Heating, ventilation, and air conditioning

OFF

ON

Breaker box

Switch

M38948

M38949

M38950

C2RKY

CWW2GRKY

Terminal Labels

Wires

M38951

C

C terminal

*

M38952

M38953

G

C

R

W

W2

Y

*

M38954

**

*

C

Y or Y1

R or Rc

G

W2

R

G

W

Y

W or W1

EXAMPLE

M38955

*

R

C

W or W1

Y or Y1

R or Rc

G

G

Y

W

W2

**

***

33-00618-03

CAUTION: ELECTRONIC WASTE NOTICE

The product should not be disposed of with other

household waste. Check for the nearest authorized

collection centers or authorized recyclers. The

correct disposal of end-of-life equipment will help

prevent potential negative consequences for the

environment and human health.
