Seite 1/2
Hoshizaki reserves the right to change specifications without notice.
SLIM-LINE MODULAR CRESCENT CUBER
Item #:
Project:
Qty:
AIA#:
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
Air-Cooled
KM-520MAJ-E
KM-660MAJ-E
559 x 695 x 711 mm
W x D x H
Features
• Durable construction with fewer parts
• Self-diagnostic programming automatically adjusts
to changing conditions
• Snap fit parts for easy cleaning
• Stainless steel double-sided evaporator
• CycleSaver
TM
design
• EverCheck
TM
alert system
• Removable air filters (air-cooled model only)
• Power cord is 3000mm long with Type G plug
• R-404A Refrigerant
Individual crescent cube
Factory-installed ultrasonic bin
control can be adjusted on site
Simple, one-hour cleaning process
®
TM
CLEAN
ASSIST
Air / Water Temp
kg per 24 hours
Condenser
Model
21°/ 10°C 32°/ 21°C
ICE PRODUCTION
Potable
liters per 45 kg
Condenser
liters per 45 kg
Heat
Rejection
BTU/hr.
Voltage
WATER USAGE
32°/ 21°C 32°/ 21°C
ELECTRICAL
32°/ 21°C
kWh Used
per 45 kg
Amperage
Circuit
Wires
(including ground)
Net / Ship
Weight (kg)
Refrigerant
Charge Amount
Volume:
846 x 652 x 875 mm 0.492m
3
Shipping: (LxWxH)
Call factory for information.
Warranty:
Top kit may be required. See bin spec sheets.
Shown on optional bin: B-300
Available on Bins/Dispensers:
B-250SF
B-300SF
B-500SF
B-1150SS
B-1300SS
DB-130H
B-700SF
B-800SF
B-900SF
DB-200H
DM-200B
Power cord included.
Air
KM-520MAJ-E
KM-660MAJ-E
Air
238
280
197
262
108
52
N/A
N/A
6.52
4.85
15A
15A
8.4A
8.4A
220-240V/50/1
220-240V/50/1
3
3
7,300
7,300
500g
760g
59 / 68
59 / 68
© HOSHIZAKI AMERICA, INC.
1
1/2
”
1/2
”
1
1/8
”
* approximate size in inches, image not to scale
Operating Limits
Plumbing
Service
Printed in the U.S.A.
• Ambient Temp Range 7 - 38°C
• Water Temp Range 7 - 32°C
• Water Pressure 69 - 779KPa
• Voltage Range 198-254V
• If GFCI is required, a GFCI breaker MUST be used in lieu
of GFCI receptacle
• Icemaker Water Supply Line: Minimum 6 mm Nominal OD
Copper Water Tubing or Equivalent
• Icemaker Drain Line: Minimum 18 mm Nominal OD Hard
Pipe or Equivalent
• Panels easily removed and all components
accessible for service.
• Allow 15 cm (6”) clearance at rear, sides, and top for
proper air circulation and ease of maintenance/service.
Please refer to water filter specification sheet for recommendations.
Water Filter
COMPONENT
(KM-660MAJ-E Only)
WMTS-105
C of C WM-02 2350
KM-520/660MAJ-E
07/02/24
Item # 13460
Min. Circuit/
Max. Fuse
Size
KMEdge
TM
Cube Dimensions*
618 Hwy, 74 S., Peachtree City, GA 30269 | TEL 800-438-6087 | FAX 800-345-1325 | www.hoshizakiamerica.com
© HOSHIZAKI AMERICA, INC.
BOTTOM VIEW REAR VIEW SIDE VIEW FRONT VIEW
Printed in the U.S.A.
Front
SLIM-LINE MODULAR CRESCENT CUBER
Front
KM-520/660MAJ-E
07/02/24
Item # 13460
mm
[inch]
