Quick guide

PRODUCT DESCRIPTION

CONTROL PANEL

1. Control panel

2. Fan

3. Circular heating element

(not visible)

4. Shelf guides

(the level is indicated on the front

of the oven)

5. Door

6. Upper heating element/grill

7. Lamp

8. Turnspit insert point

Identification plate

(do not remove)

10. Lower heating element

(not visible)

1. LEFTHAND DISPLAY

2. ON / OFF

For switching the oven on and off

and for stopping an active function

at any time.

3. BACK

For returning to the previous menu

when configuring settings.

4. TEMPERATURE

For setting the temperature.

5. KNOB

For selecting menu items and

changing or adjusting the settings

of a function.

6. START

For starting functions and

confirming settings.

7. TI M E

For setting or changing the time

and adjusting the cooking time.

8. CONFIRM

For confirming an item you have

selected or the settings for a

function.

9. RIGHTHAND DISPLAY

1 2 5 6 93 4 7 8

THANK YOU FOR BUYING A

HOTPOINT-ARISTON PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

ACCESSORIES

Download the Use and Care Guide from

docs.hotpoint.eu for more information

WWW

WIRE SHELF DRIP TRAY BAKING TRAY TURNSPIT

The number of accessories may vary depending on which

model is purchased.

Other accessories can be purchased

separately from the After-sales Service.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across

the shelf guides, making sure that the side with the

raised edge is facing upwards.

Other accessories, such as the drip tray and the

baking tray, are inserted horizontally in the same way

as the wire shelf.

USING THE TURNSPIT

Push the skewer through the

centre of the meat (bound

with string if poultry) and

slide the meat onto the

skewer until it is positioned

firmly on the fork and

cannot move. Push the

second fork onto the skewer

and slide it on until it holds

the meat firmly in place.

Tighten the fixing screw to secure it in position.

Insert the end into

the recess provided

in the oven’s cooking

compartment and rest

the rounded part on the

relevant support.

Please note: To collect the

cooking juices, position the

drip tray below and add 500

ml of drinking water. To avoid

burning yourself when the skewer is hot, only handle it by

the plastic handle (which must be removed before cooking).

REMOVING AND REFITTING THE SHELF GUIDES

. To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating: The

shelf guides can now be removed.

. To refit the shelf guides, first fit them back into

their upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

Produktspezifikationen

Marke:	Hotpoint
Kategorie:	Backöfen
Modell:	FI4 800 P BL HA
Breite:	595 mm
Tiefe:	564 mm
Gewicht:	36000 g
Produktfarbe:	Schwarz
Steuerung:	Rotary, Touch
Höhe:	595 mm
AC Eingangsspannung:	220-240 V
AC Eingangsfrequenz:	50 - 60 Hz
Eingebautes Display:	Ja
Geräteplatzierung:	Integriert
Selbstreinigend:	Ja
Warmhaltefunktion:	Ja
Kabellänge:	0.9 m
Grill:	Ja
Stromstärke:	16 A
ECO-Modus:	Ja
Innenbeleuchtung:	Ja
Einbauraum Breite:	568 mm
Einbauraum Tiefe:	550 mm
Ofengröße:	Medium
Anzahl der Öfen:	1
Garraumvolumen Gesamteinheit:	71 l
Leistung Gesamteinheit:	- W
Ofentyp:	Elektrischer Ofen
Netto-Ofenvolumen:	71 l
Reinigungsart:	Pyrolytisch
Anzahl der Gitterroste:	1
Timer-Typ:	Digital
Energieverbrauch (konventionell):	0.9 kWh
Energieverbrauch (erzwungene Konvektion):	0.69 kWh
Einbauraum Höhe (min):	583 mm
Backblech:	Ja
Heißluftbetrieb:	Ja
Dampfgaren:	Nein
Pizzabackfunktion:	Ja
Einbauraum Höhe:	585 mm
Breite installationsfach (min):	560 mm
Anzahl Lampe(n):	1 Lampen
Wi-Fi-gesteuert:	Nein
Handgrifffarbe:	Edelstahl
Anzahl an Kochprogrammen:	16
Mikrowellenkochen:	Nein
Konventionelle Beheizung (Ober-/Unterhitze):	Ja
Brotbackfähigkeit:	Ja
Anzahl der Backbleche:	1
Oben, unten, Lüfter + Umluft (Turbobetrieb):	Ja
Garverfahren im Ofen:	Lüfterbetrieben
Beleuchtungsort:	Hinten
