Hotpoint HSIE 2B19 Bedienungsanleitung
Seiten 16 Spülmaschine
Lies die Bedienungsanleitung für Hotpoint HSIE 2B19 kostenlos online oder lade das PDF herunter. 21 Personen fanden diese Anleitung hilfreich. Frage zu diesem Modell? Stelle eine Frage
1
SAFETY INSTRUCTIONS
IMPORTANT TO BE READ AND OBSERVED
Before using the appliance, read these safety
instructions. Keep them nearby for future reference.
These instructions and the appliance itself provide
important safety warnings, to be observed at all times.
The manufacturer declines any liability for failure to
observe these safety instructions, for inappropriate
use of the appliance or incorrect setting of controls.
Very young children (0-3 years) should be kept
away from the appliance. Young children (3-8 years)
should be kept away from the appliance unless
continuously supervised. Children from 8 years
old and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge can use this appliance only if they
are supervised or have been given instructions on
safe use and understand the hazards involved.
Children must not play with the appliance. Cleaning
and user maintenance must not be carried out by
children without supervision.
PERMITTED USE
CAUTION: the appliance is not intended to be
operated by means of an external switching device,
such as a timer, or separate remote controlled
system.
This appliance is intended to be used in household
and similar applications such as: sta kitchen areas
in shops, oces and other working environments;
farm houses; by clients in hotels, motels, bed
& breakfast and other residential environments.
The maximum number of place settings is shown
in the product sheet.
The door should not be left in the open position
- risk of tripping. The open appliance door can only
support the weight of the loaded rack when pulled
out. Do not rest objects on the door or sit or stand
on it.
WARNING: Dishwasher detergents are strongly
alkaline. They can be extremely dangerous if
swallowed. Avoid contact with the skin and eyes and
keep children away from the dishwasher when the
door is open. Check that the detergent receptacle is
empty after completion of the wash cycle.
WARNING: Knives and other utensils with sharp
points must be loaded in the basket with their points
down or placed in a horizontal position - risk of cuts.
This appliance is not for professional use. Do not
use the appliance outdoors. Do not store explosive
or ammable substances (e.g. gasoline or aerosol
cans) inside or near the appliance - risk of re. The
appliance must be used only to wash domestic
EN
dishes in accordance with the instructions in this
manual. The water in the appliance is not potable.
Use only detergent and rinse additives designed
for an automatic dishwasher. When adding salt to
the water softener, run one cycle immediately to
avoid corrosion damage to internal parts. Store the
detergent, rinse aid and salt out of reach of children.
Shut o the water supply and unplug or disconnect the
power before servicing and maintenance. Disconnect
the appliance in the event of any malfunction.
INSTALLATION
The appliance must be handled and installed by
two or more persons - risk of injury. Use protective
gloves to unpack and install - risk of cuts. Connect
the dishwasher to the water mains using only new
hose sets. The old hose sets should not be reused.
All hoses must be securely clamped to prevent them
coming loose during operation. All local waterboard
regulations must be complied with. Water supply
pressure 0.05 - 1.0 MPa. The appliance must be
placed against the wall or built into furniture to limit
the access to its rearside. For dishwashers having
ventilation openings in the base, the openings must
not be obstructed by a carpet.
Installation, including water supply (if any) and
electrical connections, and repairs must be carried
out by a qualied technician. Do not repair or replace
any part of the appliance unless specically stated
in the user manual. Keep children away from the
installation site. After unpacking the appliance, make
sure that it has not been damaged during transport.
In the event of problems, contact the dealer or
your nearest After-sales Service. Once installed,
packaging waste (plastic, styrofoam parts etc.) must
be stored out of reach of children - risk of suocation.
The appliance must be disconnected from the power
supply before any installation operation - risk of
electrical shock. During installation, make sure the
appliance does not damage the power cable - risk of
re or electrical shock. Only activate the appliance
when the installation has been completed.
If installing the dishwasher at the end of a row of
units making the side panel accessible, the hinge
area must be covered to avoid risk of injury. The
inlet water temperature depends on the dishwasher
model. If the installed inlet hose is marked „25°C
Max”, the maximum allowed water temperature is
25°C. For all other models the maximum allowed
water temperature is 60°C. Do not cut hoses and, in
the case of appliances tted with a waterstop system,
do not immerse the plastic casing containing the inlet
Alle Fehlercodes Hotpoint Spülmaschine 11 Fehlercodes aus 4 Bedienungsanleitungen, mit Bedeutung.
Produktspezifikationen
| Marke: | Hotpoint |
| Kategorie: | Spülmaschine |
| Modell: | HSIE 2B19 |
| Breite: | 450 mm |
| Tiefe: | 555 mm |
| Gewicht: | 29600 g |
| Steuerung: | Tasten |
| Höhe: | 820 mm |
| AC Eingangsspannung: | 220 - 240 V |
| AC Eingangsfrequenz: | 50 Hz |
| Eingebautes Display: | Nein |
| Geräteplatzierung: | Voll integriert |
| Selbstreinigend: | Nein |
| Energieeffizienzklasse: | F |
| Kabellänge: | 1.3 m |
| Energieeffizienzskala: | A bis G |
| Startzeitvorwahl: | Nein |
| Verstellbare Füße: | Ja |
| Anschlusswert: | 1900 W |
| Stromstärke: | 10 A |
| Zykluszeit: | 240 min |
| Trocknungsklasse: | A |
| Geräuschpegel: | 49 dB |
| Halbe Beladung: | Nein |
| Türfarbe: | Nicht zutreffend |
| Trocknungssystem: | Statisch |
| Wasserverbrauch pro Zyklus: | 11.5 l |
| Waschwirkungsklasse: | A |
| Anzahl Waschprogramme: | 5 |
| Energieverbrauch pro 100 Zyklen: | 84 kWh |
| Energieverbrauch pro Zyklus: | 0.834 kWh |
| Lärmemissionsklasse: | C |
| Anzahl Maßgedecke: | 10 Maßgedecke |
| Geschirrspülprogramme: | Express |
| Temperatur (max): | - °C |
| Produktgröße: | Single (45 cm breit) |
| Benutzerdefinierte Panel-Bereitschaft: | Ja |
| Bedienfeld Farbe: | Weiß |
| Oberer Korb höhenverstellbar: | Ja |
| Art des Besteckeinsatzes: | Korb |
| Restzeitanzeige: | Nein |
| Einbauraum Breite: | 450 mm |
| Einbauraum Tiefe: | 560 mm |
| Anzeige bei geringem Füllstand an Salz: | Ja |
| Anzeige für fehlenden Klarspüler: | Ja |
| Einbauraum Höhe (min): | 820 mm |
| Einbauraum Höhe (max): | 900 mm |
| Schlauchlänge Wasserzulauf: | 1.55 m |
| Schlauchlänge Wasserablauf: | 1.5 m |
| Höhenverstellbare Füße: | 80 mm |
| Stromverbrauch (aus): | 0.5 W |
| Wasserkapazität: | Cold, Hot |
| Wi-Fi-gesteuert: | Nein |
| Überlaufschutz: | Ja |
| Maximale Versorgungstemperatur für Warmwasser: | 60 °C |
| Art der Fußeinstellung: | Vorne & hinten |
