GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
* By selecting the cycle and excluding the spin cycle, the washing machine will Spin & Drain
drain only.
** The duration of the wash cycles can be checked on the display.
****
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
4) Eco Cotton - Test wash cycles in compliance with regulations 1061/2010. Set
“Cotton”
wash cycle at a temperature of 40°C or 60°C to access this cycles.
Note: If “Steam Hygiene” option is set, the duration of the wash cycles will increase.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most efficient
programme in terms of energy and water consumption for washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
For all testing institutes:
2) Long cotton cycle: set programme at temperature 40°C. Cotton
3) Long synthetics cycle: set cycle at a temperature of 40°C.Synthetics
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1. ON/OFF button
2. KEY LOCKbutton
3. EXTRA TOUCH button
4. EXTRA TOUCH indicator lights
5. START/PAUSE button and indicator light
6. OPTION button and indicator light
7. DELAY START button
8. SPIN button
9.TEMPERATURE button
10.WASH CYCLE SELECTOR KNOB
Maximum load
7 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(****)
Energy
consumption
kWh
Total water lt
Laundry
temperature
°C
Wash cycle
Temperature
Maximum
spin
(r.p.m.)
Max.
load
(kg)
Duration
(h : m)
Wash
Fabric
softener
PowderLiquid
SettingRange23
Mixed40°C
- 40°C14007,0**
–
––––
Eco 40-60 (1)40 °C 40°C
13517,03:25
531,044838
13513,52:40
530,684536
13511,752:10
530,523936
Cotton (2)40°C
- 60°C14007,03:40
500,987545
Synthetics (3)40°C
- 60°C12004,02:55
350,866043
Delicates40°C
- 40°C10004,0**
–
––––
Wool40°C
- 40°C8001,5**
–
––––
Anti Allergy60°C40°C - 60°C14004,0**
––––
Spin & Drain *––14007,0**––––––––
Rinse & Spin ––14007,0**–
––––––
Baby40°C
- 40°C8003,0**
–
––––
20°C20 °C
- 20 °C14007,01:50
–
520,166422
Duvet30°C
- 30°C10003,0**
–
––––
White40°C
- 90°C14007,01:40
–52,10,656642
30 min30°C
- 30°C8003,50:30
–
730,193127
Full Load 45 min40°C
- 40°C12007,0**
–
––––
Anti Stain 40°40°C
- 40°C14007,0**
–
––––
Required dosage Optional dosage
Eco Cotton (4)
60 °C60 °C14007,04:30
531,0044–
40 °C40 °C14007,03:40
500,9875–
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition (supplied) should be used for proper A
dosage.
If powder detergent is used, place the partition
into slot .B
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
1
10
2
DISPLAY
4
5
6
7
8
9
3
