Seite 1/17
FRONTFRONTFRONTFRONT
BACKBACKBACKBACK
1.
Power button (with integrated power indicator light)
1.
Cabling exit from secure USB compartment
2.
Flash drive activity indicator light
2.
WIFI antenna connector (depends on model)
3.
Audio connector (headphone/speaker out)
3.
Ethernet RJ-45 connector
4.
Audio connector (mic in)
4.
USB connectors (four)
5.
USB connectors (two)
5.
DisplayPort monitor connector
6.
Removable stand for vertical orientation
6.
VGA monitor connector
7.
Mounting points for HP Quick Release or other VESA mount
7.
PS/2 keyboard connector
8.
Secure USB compartment cover
8.
PS/2 mouse connector
9.
Cable lock slot (secures unit and secure USB compartment)
9.
Serial connector
10.
+19V DC power input
11.
Power cable retention slot
12.
Mounting location for four (4) horizontal mounting feet
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 10 — December 9, 2011
Page 1
TOP
TOPTOP
TOP
1.
Cable lock slot - secures unit and secure USB compartment
2.
Secure USB compartment with cover removed - 2 USB
connectors
With optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
With optional HP t5740/t5745 PCIe x4/PCI Expansion Module KitWith optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
With optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
FRONTFRONTFRONTFRONT
BACKBACKBACKBACK
1.
Power button (with integrated power indicator light)
1.
Cabling exit from secure USB compartment
2.
Flash drive activity indicator light
2.
WIFI antenna connection (depends on model)
3.
Audio connector (headphone/speaker out)
3.
Ethernet RJ-45 connector
4.
Audio connector (mic in)
4.
USB connectors (four)
5.
USB connectors (two)
5.
DisplayPort monitor connector
6.
Removable stand for vertical orientation
6.
VGA monitor connector
7.
Mounting points for HP Quick Release or other VESA mount
7.
PS/2 keyboard connector
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 10 — December 9, 2011
Page 2
8.
Secure USB compartment - 2 USB connectors
8.
PS/2 mouse connector
9.
Cable lock slot (secures unit and secure USB compartment)
9.
Serial connector
10
+19V DC power input
11.
Power cable retention slot
12.
Mounting location for four (4) horizontal mounting feet
13.
Second serial connector
14.
PCIe x4/PCI expansion module slot
15.
Parallel connector
At A Glance
At A GlanceAt A Glance
At A Glance
Hardware features
Hardware featuresHardware features
Hardware features
:
Intel Atom N280
*
processor, with Intel GL40 chipset.
*Intel's numbering is not a measurement of higher performance
4 GB flash memory provides ample storage for drivers and applications
2 GB DDR3/667MHz system memory (64 MB minimum reserved for graphics memory)
Available empty DDR3 SODIMM slot (and RAM upgrade options) for dual-channel system memory expansion
NOTE:NOTE:NOTE:NOTE:
Minimum of 1GB and a maximum of 4GB* (2 X 2GB) can be supported (*Up to 1 GB may not be available w
bit operating systems due to system resource requirements.)
Built in dual monitor support (VGA and DisplayPort native)
Integrated wireless (802.11 a/b/g/n
*
) technology (select models).
*Wireless access point and Internet required.
Optional Expansion Module with PCIe x4/PCI slot for installing a wide range of devices (includes a parallel and second s
port)
Optional enhanced performance technology
Optional dual and quad digital monitor support
Secure USB compartment is ideal for protecting USB wireless and USB Flash devices as well as for protecting USB keyboa
and mouse connectors
Additional SATA II connector for adding optional secondary solid state Flash drive
8 USB 2.0 ports
Legacy support includes parallel (via Expansion Module), serial, and PS/2 connections
Software features
Software featuresSoftware features
Software features
:
Preinstalled with new Microsoft® Windows® Embedded Standard 7 SP1 with support for Remote FX and local applications
Excellent rich multimedia experience and enhanced USB device support in VDI environments
Enhanced Write Filter and File-Based Write Filter provide complete flexibility to protect the entire Flash disk, or configure a
of the disk for persistent access by local applications
Microsoft Firewall for enhanced data security
HP TeemTalk Terminal Emulator enables connection and communication with applications on mainframes and midrange
systems
HP ThinState Tools offers in-box, easy-to-use image deployment and recovery tools
Enterprise class HP Device Manager lets you remotely manage devices from a central location
Support for HP Client Automation and Microsoft System Center Configuration Manager for easy management
HP Universal Print Driver (available as an add-on) provides instant access to a range of HP print devices without downloa
separate drivers. Additional information can be found at:
http://www.hp.com/go/upd
.
Warranty
WarrantyWarranty
Warranty
:
HP Total Care Warranty and Services: limited three-year hardware warranty in most regions. HP Care Pack Services extend servi
contracts beyond your standard warranties. For more details visit:
http://www.hp.com/go/lookuptool
.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 10 — December 9, 2011
Page 3
Produktspezifikationen
| Marke: | HP |
| Kategorie: | Thin Client |
| Modell: | H0E49AA |
| Installiertes Betriebssystem: | Windows 7 Embedded |
| Gewicht: | 1580 g |
| Anzahl USB 2.0 Anschlüsse: | 8 |
| Fernbedienung enthalten: | Nein |
| Unterstützte Netzwerkprotokolle: | TCP/IP, PPP, PPPoE, PPTP, L2TP, WOL, PXE, SNTP, SNMP |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45): | 1 |
| Ursprungsland: | China |
| Stromversorgung: | 65 W |
| Energiebedarf: | 100-240 VAC, 50-60 Hz |
| Grafikkarte: | FirePro 2460 |
| Prozessor-Taktfrequenz: | 1.66 GHz |
| Prozessorfamilie: | Intel Atom® |
| Prozessor: | N280 |
| Abmessungen (BxTxH): | 44 x 222 x 255 mm |
| Speicherkapazität: | 2 GB |
| Anzahl VGA (D-Sub) Anschlüsse: | 1 |
| Maximaler Grafikkartenspeicher: | 512 MB |
| Anzahl PS/2 Anschlüsse: | 2 |
| Mitgelieferte Software: | Microsoft RDP 7\nCitrix Online Plugin 12.0\nWindows Media Player 12\nHP TeemTalk Terminal Emulator 7\nAdobe Flash Player 10.1 |
| Nachhaltigkeitszertifikate: | ENERGY STAR |
| Version des Betriebsystems: | Standard |
| Anzahl serielle Anschlüsse: | 1 |
| Gesamtspeicherkapazität: | 4 GB |
| SmartCard-Slot: | Nein |
| Anzahl DisplayPort Anschlüsse: | 1 |
| Anzeige enthalten: | Nein |
| Grafikkarte-Familie: | AMD |
| CardBus PCMCIA Slot-Typ: | Nein |
| Netzwerkfunktionen: | Gigabit Ethernet |
