Installation Instructions
Inductive sensor
IDC
704291 / 00 09 / 2007

2
Function and features
This sensor detects metals without contact and indicates their presence by provi-
ding a switched signal.
Nominal sensing range (Sn): 50 mm;
Operating distance (Sa): 40mm (flush and over flush installation); 35mm (non-
flush installation).
(Values based on standard measurement with mild steel; a shorter sensing range
for other metals).
Installation
Mount the unit on a DIN rail or by means of a mounting fixture.
Three ways of mounting:
non-flush flush overflush
Open space around the sensing face when mounted in metal
3 x Sn
3-4mm
3-4mm
5mm
For all ways of mounting In addition for overflush mounting
•
•

3
UK
Minimum distance when several sensors of the same type are mounted:
8 x Sn
aa a
Electrical connection
Disconnect power before connecting the sensor.
The plug adapter of units with plug and socket connection can be rotated (45°
steps).
LEDs
loosen fastening nut turn plug adapter tighten fastening nut
Note: insert a miniature fuse according to the technical data sheet, if specified.
Recommendation: check the unit for reliable function after a short cirucit.
Operation
Check the safe functioning of the sensor:
The green LED is lit when the supply voltage is applied.
The yellow LED is lit when the output is switched.
The operation of the sensor is maintenance free. For perfect functioning make
sure that:
the sensing face and the open space are kept free of metal deposits and
foreign bodies, particularly for installation with the sensing face facing upwards.
EMC: The unit conforms to the requirements of EN 60947-5-2.
•
•
