Seite 1/12
Operating instructions
Capacitive sensors
KG (M18)
80005165 / 00 09 / 2013
UK
2
Content
1 Preliminary note 3 ��������������������������������������������������������������������������������������������������
1�1 Symbols used 3 ������������������������������������������������������������������������������������������������
2 Safety instructions 3 �����������������������������������������������������������������������������������������������
3 Functions and features 3 ����������������������������������������������������������������������������������������
4 Installation������������������������������������������������������������������������������������������������������������4
4�1 Notes on flush and non-flush installation 4 �������������������������������������������������������
5 Electrical connection 5 ��������������������������������������������������������������������������������������������
5�1 Wiring�������������������������������������������������������������������������������������������������������������5
6 Operating and display elements 6 ��������������������������������������������������������������������������
7 Settings ����������������������������������������������������������������������������������������������������������������7
7�1 Basic teach empty state 7 ��������������������������������������������������������������������������������
7�2 Adjustment teach full state 7 �����������������������������������������������������������������������������
7�3 Modified basic teach empty state 8 ������������������������������������������������������������������
7�4 Locking / unlocking 9 ����������������������������������������������������������������������������������������
7�5 IO-Link ���������������������������������������������������������������������������������������������������������10
7�5�1 General information 10 ����������������������������������������������������������������������������
7�5�2 Device-specific information 10 �����������������������������������������������������������������
7�5�3 Parameter setting tools 10 �����������������������������������������������������������������������
8 Operation �����������������������������������������������������������������������������������������������������������10
9 Maintenance, repair and disposal 10 ����������������������������������������������������������������������
10 Definitions �������������������������������������������������������������������������������������������������������� 11
3
UK
1 Preliminary note
1.1 Symbols used
• Operating elements are indicated as follows:
Example: = pushbutton "OUT OFF"[OUT OFF]
• Aninstructionisindicatedby"►":
Example:►Checkwhethertheunitoperatescorrectly.
• A reaction to the action is indicated by ">":
Example: > yellow LED lights�
Important note
Non-compliance can result in malfunction or interference�
2 Safety instructions
• Please read the operating instructions prior to set-up of the unit� Ensure that
the product is suitable for your application without any restrictions�
• The unit conforms to the relevant regulations and EC directives�
• Improper or non-intended use may lead to malfunctions of the unit or to unwan-
ted effects in your application�
• Installation, electrical connection, set-up, operation and maintenance of the
unit must only be carried out by qualified personnel authorised by the machine
operator
3 Functions and features
• Capacitive sensor for monitoring levels of liquids and dry bulk material�
• Automatic adjustment to the medium to be detected by means of programming
buttons�
