Operating instructions
Electronic pressure sensor
PI109x
11426174 / 00 11 / 2021
UK

2
Contents
1 Preliminary note 3 ���������������������������������������������������������������������������������������������������
1�1 Symbols used 3 ������������������������������������������������������������������������������������������������
2 Safety instructions 3 �����������������������������������������������������������������������������������������������
3 Functions and features 4 ����������������������������������������������������������������������������������������
3�1 Applications ���������������������������������������������������������������������������������������������������4
4 Function ���������������������������������������������������������������������������������������������������������������4
4�1 Processing of the measured signals 4 ��������������������������������������������������������������
4�2 Pressure monitoring/ analogue function 4 ��������������������������������������������������������
5 Installation������������������������������������������������������������������������������������������������������������6
6 Electrical connection 8 ��������������������������������������������������������������������������������������������
7 Operating and display elements 9 ��������������������������������������������������������������������������
8 Menu ������������������������������������������������������������������������������������������������������������������10
8�1 Menu structure 10 ���������������������������������������������������������������������������������������������
8�2 Menu explanation ��������������������������������������������������������������������������������������� 11
9 Parameter setting 12 ����������������������������������������������������������������������������������������������
9�1 Parameter setting general 12 ���������������������������������������������������������������������������
9�2 Configuring the display (optional) 14 ����������������������������������������������������������������
9�3 Setting the output signal 14 ������������������������������������������������������������������������������
9�3�1 Setting the output function 14 ������������������������������������������������������������������
9�3�2 Scaling the analogue value 15 ����������������������������������������������������������������
9�4 User settings (optional) 16 ��������������������������������������������������������������������������������
9�4�1 Zero-point calibration 16 ��������������������������������������������������������������������������
9�4�2 Setting the damping for the analogue signal 16 ��������������������������������������
9�5 Service functions 16 �����������������������������������������������������������������������������������������
9�5�1 Reading the min�/max� values for the system pressure 16 ����������������������
9�5�2 Reset all parameters to the factory setting 16 �����������������������������������������
10 Operation ���������������������������������������������������������������������������������������������������������17
10�1 Read the set parameter values 17 �����������������������������������������������������������������
10�2 Fault indication 17 ������������������������������������������������������������������������������������������
10�3 Cleaning of the filter cover 17 �������������������������������������������������������������������������
11 Factory setting 18 �������������������������������������������������������������������������������������������������

3
UK
1 Preliminary note
1.1 Symbols used
►Instruction
> Reaction, result
[…] Designation of buttons, switches or indications
→Cross-reference
Important note
Non-compliance can result in malfunctions or interference�
2 Safety instructions
• The device described is a subcomponent for integration into a system�
- The manufacturer is responsible for the safety of the system�
- The system manufacturer undertakes to perform a risk assessment and to
create a documentation in accordance with legal and normative requirements
to be provided to the operator and user of the system� This documentation
must contain all necessary information and safety instructions for the operator,
the user and, if applicable, for any service personnel authorised by the
manufacturer of the system�
• Read this document before setting up the product and keep it during the entire
service life�
• The product must be suitable for the corresponding applications and
environmental conditions without any restrictions�
• Only use the product for its intended purpose (→ Functions and features).
• Only use the product for permissible media (→ Technical data).
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur�
• The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator�
• Installation, electrical connection, set-up, programming, configuration, operation
and maintenance of the product must be carried out by personnel qualified and
authorised for the respective activity�
• Protect units and cables against damage�
Produktspezifikationen
Marke: | IFM |
Kategorie: | Nicht kategorisiert |
Modell: | PI1098 |
