support@ikancorp.com © 2017 ikan Corporation. All rights Reserved
LYRA DMX
Lyra Bi-Color Studio Lights with DMX
What’s Included
1 x Lyra Bi-Color DMX Studio Light
1 x Power supply
1 x Yoke Mount
1 x Power Cord
LBX15
Lyra 1.5 x 1.5 Bi-Color Studio Light with DMX Control
LBX25
Lyra 2 x 2 Bi-Color Studio Light with DMX Control
LBX15 LBX25
www.ikancorp.com
713.272.8822
QUICKSTART GUIDE
General Information
Thank you for buying the Ikan Lyra Bi-Color DMX LED Lights. This fixture has been designed to perform reliably for years
when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and
throughly before attempting to operate this unit. These instructions contain important information regarding safety during use
and maintenance.
Every fixture has been thoroughly tested. Carefully check the shipping carton for damage that may have occurred during
shipping. If the carton appears to be damaged, carefully inspect your unit for damage and be sure all accessories necessary
to operate the unit have arrived intact. In the event damage has been found or parts are missing, please contact our customer
support team for further instructions. Please do not return this unit to your dealer without first contacting customer support at
the number listed below. Please do not discard the shipping carton in the trash. Please recycle whenever possible.
Safety Instructions
This fixture is an extremely sophisticated piece of electronic equipment. To guarantee a smooth operation, it is important to
follow the guidelines in this manual. The manufacturer of thiss device will not accept responsibility for damages resulting from
the misuse of this fixture due to the disregard of the information printed in this manual. This device falls under PROTECTION
CLASS 1. It’s essential this device be perform all electrical connections.
For proper operation, follow the Installation guidelines described in this manual. Only qualified and certified personnel should
perform installation of this fixture and only the original rigging parts (yoke) included with this fixture should be used for installation.
Any modifications will void the original manufacturer’s warranty and increase the risk of damage and/or personal injury.
Never look directly into the light source of this fixture to prevent risk of injury to your retina, which may induce blindness.
Always disconnect from main power source before performing any type of service and/or cleaning procedure. Only handle the
power supply by the plug end, never pull out the plug by tugging the wire portion of the cord.
Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If the power cord is damaged,
replace it immediately with a new one of similar power rating.
INDOOR USE ONLY!
DO NOT EXPOSE TO RAIN AND/OR MOISTURE!
DO NOT PLUG FIXTURE INTO A DIMMER PACK!
General Guidelines
NEVER OPEN THIS FIXTURE WHEN IN USE!
Please make sure there are NO FLAMMABLE MATERIALS close to the fixture while operating, to prevent any fire hazard.
The fixture must be installed in a location with adequate ventilation, at least 1.5 feet (.5m) from adjacent surfaces. Be sure no
air ventilation slots are blocked.
DO NOT attempt installation and/or operation without knowledge of how to do so.
DO NOT permit operation by persons who are not qualified to operate this type of fixture. Most damages are the result of
operations by nonprofessionals. Consistent operational breaks may ensure the fixture will function properly for many years to
come.
DO NOT shake fixture and avoid using brute force when installing and/or operating the fixture.
Always install the fixture with an appropriate safety cable. When installing the fixture in a suspended environment, always use
correct mounting hardware that can be inserted into the Baby 1/8 in. or Junior 1-1/8 combo pin adapter.
Use the original packaging and materials to transport the fixture in for service.
Fixture Overview
DMX Channel
The DMX channel selection can be made from the back of the fixture using the large yellow knob to dial in the correct DMX
number. When a DMX signal is detected on the fixture, all other controls are closed down and only DMX channel control can
be selected on the rear of the fixture.
Depending on DMX channel selected a bi-color light will require two channels for use on the DMX board.
100% will be the 5600K color output. 0% will be the 3200K color output. The middle position will be 4600K color output.
Fixture Menu
ON-BOARD SYSTEM MENU
The fixture comes with an easy to navigate system menu. The next section will detail the functions of each command in the
system menu.
LCD MENU CONTROL KNOB
The control knob allows for local control as well as control from DMX board. The local control gives the user adjustment from
10%-100% in brightness. All Lyra Studio lights are bi-color fixtures, this allows the user local knob control. It gives the user the
ability to switch from 3200K -5600K just by pressing down on the large yellow dial. The user can also adjust the DMX channels
1 thru 512 by pressing down again on the large yellow dial.
LBX15 LBX25
Channel Brightness Color
5&6 Ch 5 Ch 6
