Seite 1/2

3-7/8"

98mm

5-1/8"

129mm

3-3/16"

80mm

4-3/4"

120mm

2-1/4"

57mm

9/16"

29mm

1-3/4"

44mm

REFERENCE

5032i

5032cf

5032gr

Designed and engineered in the USA.Conception et design aux É.U.A.

A valid serial number is required for warranty coverage.Un numéro de série valable est exigé pour la couverture de la garantie.

Features, specifications and appearance are subject to change without notice.

Les dispositifs,les caractéristiques et l’aspect sont sujets au changement sans communication préalable.

Harman International, Consumer Division, 8500 Balboa Boulevard, Northridge, CA 91329 USA

www.infinitysystems.com

Infinity is a trademark of Harman International Industries,Incorporated, registered in the United States and/or other countries.

Infinity est une marque commerciale de Harman International Industries, Incorporated,déposée aux États-Unis et/ou dans d’autres pays.

Declaration of Conformity

We,Harman Consumer Group, Inc.

2, route de Tours

72500 Château du Loir

France

declare in own responsibility that the products described in this owner’s

manual are in compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Klaus Lebherz

Harman Consumer Group, Inc.

Château du Loir, France 1/09

5032i 5032cf

BL (T-m) 3.25 3.25

DCR (ohms) 2.30 2.30

Mms (g) 10.22 10.22

Sd (sq cm) 103.9 103.9

Cms (μm/N) 521 521

Vas (l) 7.89 7.89

Fs (Hz) 69.0 69.0

Qes 0.96 0.96

Qms 6.94 6.94

Qt 0.85 0.85

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at

www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product,please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf” version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf” version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf” version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf” version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Y

our local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit

us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your

local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us

at www.infinitysystems.com.

SPECIFICATIONS

5032i 5032cf 5032gr

Type: 5-1/4" (130mm) 5-1/4" (130mm) GRILLE ONLY

2-Way 2-Way for 5-1/4" (130mm)

NO GRILLE

Impedance: 2 Ohms 2 Ohms

Power Handling,RMS: 45W 45W

Power Handling,Peak: 135W 135W

Frequency Response: 67Hz – 21kHz 67Hz – 21kHz

Sensitivity (2.83V, 1m): 92dB 92dB

Grilles are included with the “i” version; they are optional for the “cf”version

(use Reference model 5032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased.Your local Infinity car audio retailer can help you determine the length

of your warranty.To register your product, please visit us at www.infinitysystems.com.

Produktspezifikationen

Marke:	Infinity
Kategorie:	Lautsprecher
Modell:	REF5032CF
Impedanz:	2 Ohm
Frequenzbereich:	67 - 21000 Hz
Empfindlichkeit:	92 dB
Lautsprechertyp:	2-Wege
Bemessungsleistung:	45 W
Spitzenstrom:	135 W
