4-1/4"
110mm
6-1/4"
159mm
3-9/16"
90mm
5"
127mm
2-1/16"
52mm
3/4"
19mm
1-3/4"
44mm
4-1/4"
110mm
6-1/4"
159mm
3-3/16"
80mm
5"
127mm
1-15/16"
49mm
7/16"
11mm
1-3/4"
44mm
6032i/6032cf6032si
REFERENCE
6032i
6032cf
6032si
6032gr
Declaration of Conformity
We, Harman International, Consumer Division
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 1/09
6032i 6032cf 6032si
BL (T-m) 4.00 4.00 4.30
DCR (ohms) 2.30 2.30 2.30
Mms (g) 12.98 12.98 12.69
Sd (sq cm) 132.7 132.7 132.7
Cms (μm/N) 277 277 221
Vas (l) 6.85 6.85 5.47
Fs (Hz) 83.9 83.9 95.0
Qes 0.98 0.98 0.94
Qms 6.16 6.16 7.89
Qt 0.85 0.85 0.84
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage. Un numéro de série valable est exigé pour la couverture de la garantie.
Features, specifications and appearance are subject to change without notice.
Les dispositifs, les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division, 8500 Balboa Blvd., Northridge, CA 91329 USA
www.infinitysystems.com
¥(ARMAN)NTERNATIONAL)NDUSTRIES)NCORPORATED!LLRIGHTSRESERVED4OUSDROITSRÏSERVÏSs0ART.O2%&/-
Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries, Incorporated, déposée aux États-Unis et/ou dans d’autres pays.
Produktspezifikationen
| Marke: | Infinity |
| Kategorie: | Autofreisprechanlage |
| Modell: | Reference 6032I |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Infinity Reference 6032I benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Autofreisprechanlage Infinity
Infinity Kappa 682.7CF Bedienungsanleitung Infinity Kappa 652.1I Bedienungsanleitung Infinity Reference 4622CFP Bedienungsanleitung Infinity Reference 5032I Bedienungsanleitung Infinity Kappa 63.5I Bedienungsanleitung Infinity Reference 105t Bedienungsanleitung Infinity Reference 5752CF Bedienungsanleitung Infinity Kappa 57.1cs Bedienungsanleitung
Alle Infinity Autofreisprechanlage Bedienungsanleitungen
Beliebt in Autofreisprechanlage
Infinity Reference 1240SE Bedienungsanleitung Infinity Reference 6002I Bedienungsanleitung Infinity Reference 5020cs Bedienungsanleitung
Bedienungsanleitung Autofreisprechanlage
Neueste Bedienungsanleitungen für Autofreisprechanlage
Philips TAC7306 Bedienungsanleitung PowerBass XPRO-10 Bedienungsanleitung PowerBass 4XL-80-94 Bedienungsanleitung PowerBass XPRO-65 Bedienungsanleitung Axxess AX-ALOC618 Bedienungsanleitung Audison Voce AV 3.0 II Bedienungsanleitung Audison Voce AVX 6.5 Bedienungsanleitung Audison Voce AVK 6 S II Bedienungsanleitung Audison Prima AP 6.5P Bedienungsanleitung Audison Voce AV 6.5 P II Bedienungsanleitung
