Before using your new product, please read these instructions to prevent any damage.
Full Motion Mount for
TVs 47" - 90"
NS-HTVMM1703-C
I N S TA L L AT I O N G U I D E
For VESA patterns:
• 7.9 × 7.9" (200 × 200 mm)
• 11.8 × 7.9" (300 × 200 mm)
• 11.8 × 11.8" (300 × 300 mm)
• 15.7 × 7.9" (400 × 200 mm)
• 15.7 × 11.8" (400 × 300 mm)
• 15.7 × 15.7" (400 × 400 mm)
• 19.7 × 15.7" (500 × 400 mm)
• 23.6 × 15.7" (600 × 400 mm)
2
www.insigniaproducts.com
Safety information and specifications
IMPORTANT
SAFETY
INSTRUCTIONS
- SAVE THESE
INSTRUCTIONS
CAUTION: Do
not use this product for any purpose
not explicitly specified by Insignia.
Improper installation may cause
property damage or personal injury.
If you do not understand these
directions, or have doubts about the
safety of the installation, contact
Customer Service or call a qualified
contractor. Insignia is not responsible
for damage or injury caused by incorrect installation or use.
The weight of your TV must not exceed 130 lbs. (59 kg). The wall must be capable of supporting five times
the weight of your TV and wall mount combined.
This product contains small items that could be a choking hazard if swallowed. Keep these items away
from young children!
Maximum TV weight: 130 lbs. (59 kg)
Screen size: 47 in. to 90 in. diagonal
Overall dimensions (H × W ):
16.9 × 28 in. (42.9 × 71.1 cm)
Wall-mount weight: 22 lbs. (10 kg)
We’re here for you
www.insigniaproducts.com
For customer service, call:
1-877-467-4289
28 in. (71.2 cm)
25.2 in. (6
4.1 cm)
16.9 in. (43.0 cm)
17.6 in. (47.7 cm)
3
www.insigniaproducts.com
Full Motion Mount for TVs 47" - 90"
Tools needed
You will need the following tools to assemble your new TV wall mount:
ardware
Package contents
Make sure that you have all the hardware necessary to assemble your new TV wall mount:
Edge-to-edge
stud finder
Phillips screwdriver
Measuring tape
Drill
3/16 in. (5 mm) wood drill
bit (for wood stud wall)
OR
3/8 in. (10 mm) masonry
drill bit (for concrete wall)
Hammer
Tape
Pencil
Wall Mount (1)
Wall Plate Template (1)
TV Brackets
(2)
