Seite 1/16

Features
• One 10/100/1000 RJ45 port supporting a maximum distance of 100 m (300 ft.)
• One SFP port for 1000Base-X optical transceiver modules and distances up to 120 km (75 mi.)
• Power over Ethernet injector function with output up to 90 watts
• IP30 slim-type metal housing to withstand harsh industrial conditions
• Option for DIN-rail installation
• One DC input (44 - 57 V) with terminal block
For specifications, visit intellinetnetwork.com. Register your product at
register.intellinet-network.com/r/509107 or scan the QR code on the cover.
Placement
Desktop Installation
Prior to use, place/position the device:
• on a level surface that can support the device, with at least 25 mm (approx. 1”) of clearance for ventilation;
• away from sources of electrical noise: radios, transmitters, broadband amplifiers;
• within 100 m (approx. 328’) of RJ45 network devices it’s to be connected to.
DIN-Rail Installation
1 Angle spring of mounting clip over top lip of DIN rail.
2 Push device down till clip clicks onto rail.
3 Ensure installation is stable.
Power
Chassis Ground Column
Located on the side of the power supply connector, a grounding terminal connector is used to provide proper
grounding for your switch. It should be wired to an object that provides earth ground.
Terminal Block Installation (DC Input 44 - 57 V)
NOTE: Ensure all power is off/disconnected before beginning! The wire gauge for the terminal block should be
in the range between 12 – 24 AWG. It is recommended to use a cable with a current capacity of more than 6 A.
1 Loosen appropriate screws. Insert bare power-supply wires into appropriate terminals (positive wire into
positive [V+] terminal, negative wire into negative [V–] terminal, ground wire to ground [
] terminal).
2 Tighten appropriate screws to secure wires.
3 Install block into the device.
3
1
2
V+ V–
2
Instructions
English
