Seite 1/24

GWHD101KIT

PART NO. Q1590-a

www.iogear.com

STEP 1

Turn on both the video source and the display (TV or projector). Make

sure that the input source on your display corresponds to the HDMI

port that the transmitter is connected to.

STEP 2

Insert the transmitter into the HDMI port of your video source device.

Quick Start Guide

Share Pro™ Expandable Wireless Presentation System

Guide de démarrage rapide

Share Pro™ Système de présentation sans fil extensible

Guía de conﬁguración rápide

Share Pro™ Mini Transmisor de Video HD Inalámbrico y

Kit de Receptor

STEP 3

Use one of the USB charging cables to connect to the micro USB port

of the transmitter to a type USB-A port on the source device to obtain

power. In a rare case that the source device has no USB port, please

use a 5V USB power adapter with a minimum of 500mA output (not

included in the package). At this time both the power LED (blue) and

the wireless LED (red) will light up solid and then the wireless LED

(red) will go out and come back on and both will remain solid.

In case the space around the HDMI port is too tight or the position is

too awkward and could cause a connection issue, use the HDMI cable

extender or the 90 degree HDMI adapter included in the package to

correct this issue or to increase the spacing.

STEP 4

Connect the receiver into a free HDMI port of your video display

device (TV, projector, etc.) using the provided HDMI cable and switch

your TV Input to the HDMI input source it is connected to.

STEP 5

The connection LED (green) will come on solid and

a message will be displayed on your TV/projector

stating it is waiting for connection. After

approximately 30 seconds the wireless

LED (green) the receiver will come on,

the connection LED on the

receiver will start to blink once

every second. The

transmitter wireless

LED (red) will also blink

every second. The

connection is now

established.

The LED around the

transmitter swtich button will

also turn from red to blue. For

the next transmitter to be

connected to the receiver, simply

press the transmitter button and the

red LED will turn to blue and the

previously connected transmitter LED

will change from blue LED to red indicating that the transmitter is now

disconnected.

STEP 6

Video from your source device will now be duplicated on your TV/projector.

NOTE: We recommend that this device is used for line-of-sight only as it is

designed as a short range device.

Produktspezifikationen

Marke:	Iogear
Kategorie:	Nicht kategorisiert
Modell:	GWHD101KIT
AC-Netzadapter:	Ja
Mitgelieferte Kabel:	HDMI, USB Type-A
Produktfarbe:	Schwarz
Energiequelle:	DC, USB
Gleichstrom-Anschluss (DC):	Ja
Antennentyp:	Intern & extern
Relative Luftfeuchtigkeit in Betrieb:	0 - 90 %
Schnellstartübersicht:	Ja
Stromverbrauch (Standardbetrieb):	2.5 W
LED-Anzeigen:	Ja
Luftfeuchtigkeit bei Lagerung:	0 - 90 %
Unterstützte Video-Modi:	480p, 576p
Frequenzband:	5.8 GHz
Schnittstelle:	HDMI
Formfaktor:	Dongle
HDMI-Version:	1.3
Eingangsspannung:	5 V
Eingangsstrom:	2 A
