Usage of iOS devices

Support iOS non jail-breaking devices. Could play games which download from Apple APP Store.

Searching "iCade" from APP Store will come out vast of iCade games for playing.

(Support parts of games under iCade mode as game devices is limited for iOS system.)

1.Firstly, you need to set keyboard input in English. Pic1

2.Press and hold B button + HOME button for 2's, then release two buttons until LED3 flash

quickly. Pic2

3.Open the Bluetooth on iOS device, click searching.

4.Find and select “PG-9033” for Bluetooth pairing. Pic3

5.LED3 lit on after Bluetooth connected. Pic4

Support parts of games under iCade mode:

Applicable instructions

Introduction for key functions:

iOS system Windows system

HID Mode (GamePad)

X+Home

No Bluetooth function PC,

need buy a Bluetooth Dongle

iCade Mode

B+Home

Default English

keyboard input

1.Working voltage DC3.7V：

2.Working current 30 mA：

3.Continouse gameplay time: 10H

4.Static current: <35uA

5.Charging voltage/current DC5V/500mA：

6.Bluetooth transmission distance：≤8M

7.Battery capacity：380mAh

8.Standby time：up to 30days once fully charged

Electrical Parameters：

Android system

Bluetooth pairing buttons

(Press and hold on 2's)

Indicator

Remark

Bluetooth pairing buttons

(Press and hold on 2's)

Indicator

Remark

HID Mode(GamePad)

X+Home

LED1

Keyboard Mode

A+Home

LED2

Mouse Mode

Y+Home

LED1 or LED2

LED3 LED1

Freely dynamic swift to mouse mode from HID or keyboard mode

Operation instructions:

Charge/ Sleep/ Wake up function of Gamepad:

1.LED4 indicator will lit on while charging and will turn

off after fully charged.

2.Sleep/Wake up function: Gamepad will enter into

sleeping mode if not in use for 5 minute, and press

HOME button for wake up and reconnect automatically.

3.LED4 indicator flashing quickly for low battery remind.

1.Thanks for purchasing iPega developed Bluetooth Gamepad.

2.This Gamepad support playing games on Bluetooth enabled Android 3.2v+ tablet / smart phone

/ TV box / smart TV / VR, IOS7+ mobile phone / tablet , MAC OSX PC and Win7 / Win8 / Win10/

Win XP PC without any drivers.

3.Ergonomic streamlining and comfortable hand hold feelings.

Due to the official game platform software upgrades or source code changes and other not

resist factors caused some of the game can not be played or connected with our Gamepad,

iPega company has no responsibility.iPega reserve the right of final interpretation for this.

Usage of Android device

It supports the vast majority of games, such as: Shadowgun/Modern Warfare 5/Asphalt/Contra/-

metal Slug, and emulator games (such as MC4, Wild blood, Dungeon Hunter, Zombie, FC

emulator, GBA emulator, arcade emulator, SFC emulator, N64 emulator, Shadowgun,sonic CD,

Cordy, Soulcraft, zenonia4, 9 Innings 2013,Riptide GP, etc.). Or you can scan QR code to

download Android Game Center and download games from Android Game Center for playing.

1.Press and hold X button + HOME button for 2's, then release two buttons until LED1 flash

quickly. Pic1

2.Open the Bluetooth on Android device, click searching.

3.Find and select “PG-9033” for Bluetooth pairing. Pic2

4.LED1 lit on after Bluetooth connected. Pic3

5.Support kinds of games which download from Google Play Store, such as: SHADOWGUN/

Need for Speed 18/ Call of Duty/ Dead of Trigger/ CS: Counter Striker/ Overkill/ Street Fighter

How to connect PC device for playing games by using USB data cable:

How to connect PC device with Bluetooth:

1.USB cable is required to connect the USB port of the

PC device with the gamepad. When the WIN7 or above

system is connected by default, the indicator light is on,

and showing the operation mode of X-INPUT.

2.In X-INPUT wired mode, it can support the operation

of vast majority of classic large-scale games in PC

version.

Such as: Need for Speed / SHADOWGUN /

Street Fighter 5 / Dead of Trigger

1. With the gamepad off, press and hold gamepad button HOME + X simultaneously for searching

the Bluetooth device.

2. Insert Bluetooth 2.1 receiver into the USB interface on PC device; Windows system will

automatically install the driver.

2.1 After the driver is installed successfully, the symbol of the Bluetooth device will be displayed

in the lower right corner of the computer.

2.2 Move the mouse to the Bluetooth symbol, click the right mouse button and select "Add Device";

2.3 After selecting "Add Device", the icon of the model of the device (PG-9033) will be searched

in the dialog box;

2.4 Click "Next" and select "Do not use the code to match", it will be automatically added after

confirming, then remind the Bluetooth is connected successfully! After connected, the indicator

light is always on!

2.5 It will be D_INPUT mode after the Bluetooth is connected successfully, and can support the

games running in simulator way.

Notes:

1. Please do not store this product in wet or high-temperature areas.

2. Don't knap, beat, drub, pierce, or try to decompose this product, to avoid unnecessary damage

to the product.

3. The product has built-in batteries, and please don’t discard them together with the garbages.

4. Don't charge the controller in a place near the fire or other heat source.

5. Non professional personnel should not disassemble the product, otherwise it will not be

covered in the after-sales warranty service.

Android Game Center

Patent NO. : ZL2014303107410

1.工作电压：DC3.7V

2.工作电流： 30 mA

3.持续使用时:10H

4.静态电流: <35uA

5.充电电压/电流：DC5V/500mA

6.蓝牙传输距离：≤8M

7.电池容量：380mAh

8.待机时间：满电放置30天

电性参数：

iOS 系统

LED1.LED2

X_Keyboard模式

Y+Home

Windows系统

HID模式(GamePad)

X+Home

LED1

需蓝牙适配器

LED3

iCade 模式

B+Home

默认为键盘英文输入法

Android 系统

模式配对

(长按2秒)

指示灯

备注

模式配对

(长按2秒)

指示灯

备注

HID模式(GamePad)

X+Home

LED1

键盘模式

A+Home

LED2

鼠标模式

Y+Home

LED1或LED2

在HID或键盘模式下均可动态切换成鼠标模式

支持iOS非越狱设备

操作使用模式：

1.非常感谢您购买ipega公司开发生产的蓝牙游戏手柄;

2.产品主要适用于在Android/iOS/MAC OSX/Win XP/7/8/10系统上蓝牙连接时,进行游戏操作时使用!

3.适用设备:智能手机/平板电脑/智能电视机、机顶盒/PC电脑(Windows和MAC OSX系统均支持);

4.结构符合人体工程学,手感舒适!

适用说明:

功能按键图示:

因官方游戏平台软件升级或源代码变更等不可抗拒的因素造成部分游戏无法与本产品连接操作，

我公司不负任何责任。对此我公司保留最终解释权。

https://pan.baidu.com/s/1hsi75FA

如还未下载手机游戏厅,请输入下方

网址或扫描右方二维码选择下载

艾派格官方微信公众号

技术支持QQ群：144981572

客服电话：400-806-300 6

在线时间：周一至周五9:30-17:30

安卓游戏平台下载二维码

蓝牙手柄

产品说明书(PG-9033)中文版

安卓设备使用说明:

安卓系统绝大多数游戏支持HID模式(在电脑上使用时Hid键值一样，支持绝大多数此类游戏；

在相关手机游戏厅或模拟器下载的游戏同样支持，如”葡萄游戏厅”)

1.同时按住X键和HOME键2秒,此时LED1指示灯快闪; 图1

2.将Android设备端的蓝牙功能打开,点击“扫描”

3.当搜索到蓝牙名为“PG-9033”的设备名时,选择配对连接；图2

4.连接成功，LED1指示灯常亮！图3

5.进入游戏(游戏厅或模拟器下载的游戏可以直接玩)

6.推荐游戏：

1.CF(穿越火线)

2.死亡扳机2

3.暗影之枪

4.现代战争5

5.王者荣耀

6.使命召唤：突击队

7.死亡效应

1.同时按Y键和HOME键2秒,LED1.LED2指示灯快闪; 图1

2. 图2将iOS设备端的蓝牙功能打开,当搜索到蓝牙名为“Newgamepad N1”的设备名时,选择配对连接；

3.连接成功，LED1.LED2指示灯常亮！图3

4.支持IOS设备9.3.0以上系统；

5.手机扫描二维码下载游戏平台，进入平台下载所需要的游戏。

X_Keyboard模式(支持iOS非越狱设备,支持第三方购买的游戏平台在相关手机游戏厅或模拟器下载的游戏

同样支持,如新游游戏厅和hand joy)(仅限中国大陆地区）

iOS设备X_Keyboard模式

图1 图2

图4

蓝牙连接PC设备操作方法

1.关机状态下，同时按住手柄HOME+X键搜索蓝牙设备；

2.将蓝牙2.1接收器插入 PC设备的USB接口;Windows 系统会自动安装驱动程序;

2.1驱动程序安装成功后,会在电脑的右下角显示蓝牙设备的符号;如下图1：

2.2将鼠标移动在蓝牙符号处,单击鼠标右键,选择“添加设备”;如下图2：

2.3选择“添加设备”后，会在对话框内搜索到设备的型号(PG-9033)图标；如下图3：

2.4点击“下一步”，并选择“不使用代码进行配对”，确认后则会自动添加，提示蓝牙连接成功!

连接OK后，指示灯常亮！如下图4 ：

2.5蓝牙连接成功后为D_INPUT模式; 在D_INPUT模式下，支持以模拟器方式运行的游戏！

iOS设备iCade模式

支持iOS非越狱设备,可以使用苹果商店内“APP Store”下载的游戏，当在“APP Store”

内搜索“iCade”时，会弹出海量的游戏并可以操作；

1.需将键盘输入法设为英文输入,才能正常操作游戏；图1

2.同时按住B键和HOME键2秒,LED3指示灯快闪;图2

3.将iOS设备端的蓝牙功能打开,当搜索到蓝牙名为“PG-9033”

的设备名时,选择配对连接；图3

4.连接成功，LED3指示灯同时常亮！图4

iCade模式下支持的部份游戏:

1.支持iOS第三方游戏平台，如需要更改按键

功能，在游戏厅内操作手柄即可更改；

2.新游游戏厅映射方法：同时按L3+SELECT组

合键调出映射功能；图1

3.Hand Joy游戏厅映射方法:同时按

START+SELECT组合键调出映射菜单；图2

4.将需要映射的按键，拖到相应的触摸功能

键上与之重叠保存后即可操作游戏！

iOS按键映射功能：

调出触摸键盘：

1.iOS系统：在X_Keyboard模式连接状态下,同时按

R3+SELECT组合键，可以调出触摸键盘界面；方便

在游戏中输入文字和字符;(仅限新游）

有线连接PC设备的操作方法：

1.需用USB数据线将手柄和PC设备的USB接口

相连,WIN7以上系统默认连接OK后，指示灯常

亮，表示为X-INPUT的操作模式；

2.X-INPUT有线模式下支持绝大多数PC版的经

典大型游戏的操作!如:极品飞车/ 暗影之枪/

街霸5/ 现代战争5/ 死亡扳机

图3

PG-9033

PG-9033说明书 80g米黄色特种纸,双面折页尺寸：630x142mm

正面

反面

注意事项：

1.请不要把本产品放在潮湿或高温地方存储；

2.不要敲击、摔打、棒打、刺穿、或试图去分解本产品，以免对产品造成不必要的损害；

3.产品内置电池，请勿和垃圾一起丢弃；

4.不要在靠近火或其它热源的地方对手柄进行充电。

5.非专业人员请勿拆卸本产品,否则不在售后保修服务内;

专利号： ZL2014303107410

手柄充电/休眠/唤醒功能:

1.充电时LED4指示灯常亮,充饱后熄灭!

2.睡眠/唤醒功能: 游戏手柄在5分钟内不使用会进

入休眠状态,当需要重新使用时需按HOME键唤

醒即可回连;

3.电池电量不足时LED4指示灯快闪提示;

START键

A/B/X/Y功能键

右3D摇杆及下压R3键

十字方向键

左3D摇杆及下压L3键

HOME键

SELECT键

R1/R2键L1/L2键

模式/充电指示灯

图1

图2

图3

图2

图3

图1

图2

图3

图4

Bluetooth Gamepad

Instruction Manual(PG-9033)

START

HOME

SELECT

R1/R2L1/L2

EXTENDABLE TELESCOPE

A/B/X/Y

RIGHT 3D &

Down press R3

MODE/ CHARGING INDICATOR LED1~LED4

D-PAD

Left 3D &

Dowd press L3

Pic 1

Pic 3

Pic 2

EN Pic 1

Pic 4

Pic 3

Pic 2

Temple Run - Imangi Studios, LLC

Super Mega Worm Lite - Deceased Pixel LLC

Emerald Mine - Les Bird

HungryMaster - xionchannel

Jungool - Headsoft

Akane the Kunoichi Lite - Haruneko

Rush City - Acceleroto

lron Frost - YOMEN,Inc.

Guns n'Bottles - Ivanovich Games

Danmaku Unlimited 2 lite - Bullet Hell Shump

Recess Riot - Deceased Pixel LLC

qub - Andrew Brinkhaus

Alien Annihilation-Free retro - space shooter

Heli Apps

Bullet Hell Infinite - Nicolas Bevillard

Retro Dust-Classic Arcade - Asteroids Vs

Invaders

Rl Productions

J-Werewolf LITE - Daniel Novais

Recess Riot Lite - Deceased Pixel LLC

Space Inversion FREE - merlyn lear

Vector Star Brawl - Jorge Arroyo

The Invaders - RI Productions

Towerman - Tomek Szczepanski

Bunny Leap - John Carlyle

Temple Run - Imangi Studios, LLC

Super Mega Worm Lite - Deceased Pixel LLC

Emerald Mine - Les Bird

HungryMaster - xionchannel

Jungool - Headsoft

Akane the Kunoichi Lite - Haruneko

Rush City - Acceleroto

lron Frost - YOMEN,Inc.

Guns n'Bottles - Ivanovich Games

Danmaku Unlimited 2 lite - Bullet Hell Shump

Recess Riot - Deceased Pixel LLC

qub - Andrew Brinkhaus

Alien Annihilation-Free retro - space shooter

Heli Apps

Bullet Hell Infinite - Nicolas Bevillard

Retro Dust-Classic Arcade - Asteroids Vs

Invaders

Rl Productions

J-Werewolf LITE - Daniel Novais

Recess Riot Lite - Deceased Pixel LLC

Space Inversion FREE - merlyn lear

Vector Star Brawl - Jorge Arroyo

The Invaders - RI Productions

Towerman - Tomek Szczepanski

Bunny Leap - John Carlyle

Produktspezifikationen

Marke:	IPEGA
Kategorie:	Regeln
Modell:	PG-9033
Unterstützte mobile Betriebssysteme:	Android 3.2, Android 4.0, Android 4.1, Android 4.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, iOS 4.3, iOS 5.0, iOS 6.0, iOS 6.1, iOS 7.0, iOS 7.1, iOS 7.2, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3
Bluetooth-Version:	3.0+HS
Gewicht:	- g
Produktfarbe:	Schwarz
Übertragungstechnik:	Kabellos
Gerätetyp:	Gamepad
Gamingplattformen unterstützt:	Android, PC, iOS
Geräteschnittstelle:	Bluetooth
Kabellose Reichweite:	8 m
Integriertes Touchpad:	Nein
