Seite 1/72
CXi
™
Pool Heater
Installation & Operation Manual
Models: 500, 650, 750
This manual supplies information for the
installation, operation, and servicing of the
appliance. It is strongly recommended that this
manual and the Jandy® CXi™ Pool Heater Service
Manual be reviewed completely before proceeding
with an installation. Perform steps in the order
given. Failure to comply could result in severe
personal injury, death, or substantial property
damage.
⚠WARNING:
Save this manual for future reference.
100320962_2000575058_Rev D
-- Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire department.
-- Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
⚠WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
Contents
Hazard definitions
The following defined terms are used throughout this manual to bring attention to the presence of hazards of various risk levels
or to important information concerning the life of the product.
⚠ DANGER
⚠WARNING
⚠CAUTION
CAUTION
NOTICE
DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate
injury.
CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
NOTICE indicates special instructions on installation, operation, or maintenance that are important but not
related to personal injury or property damage.
2
HAZARD DEFINITIONS ................................................... 2
PLEASE READ BEFORE PROCEEDING ...................... 3
SAFETY INFORMATION ................................................. 4
THE JANDY® CXI™ -- HOW IT WORKS ...................... 5-6
RATINGS........................................................................... 7
1. DETERMINE UNIT LOCATION
Location of Unit .................................................................. 8
Indoor Clearances from Combustible Construction .......... 8
Non-Combustible / Combustible Flooring .......................... 8
Freeze Protection ............................................................... 8
Location .............................................................................. 9
Hydronic Systems Anti-freeze ............................................. 9
Outdoor Pool Heater Installation ........................................ 9
Combustion and Ventilation Air .......................................... 9
Combustion Options .................................................... 9 - 11
2. VENTING
Before You Begin ............................................................. 12
Vent System Options ....................................................... 13
General Venting Information ............................................ 14
Conventional Negative Draft Venting .......................... 15-17
Vertical DirectAire Venting .......................................... 18-20
Sidewall Venting .......................................................... 21-23
Horizontal DirectAire Venting ........................................... 24
Direct Venting .............................................................. 25-31
Outdoor Installation .......................................................... 32
3. GAS CONNECTIONS
Connecting to Gas Supply ............................................... 33
Gas Pressure Test ........................................................... 33
Checking Manifold Gas Pressure .................................... 33
Gas Piping ........................................................................ 33
Gas Connection .......................................................... 33-34
Combination Gas Valves ................................................... 34
Checking Gas Supply Pressure ....................................... 35
4. WATER CONNECTIONS
Circulating Pump .............................................................. 36
Minimum Pump Performance ........................................... 37
Heat Exchanger ............................................................... 37
Auxiliary Mixed Water Limit Control ................................. 37
Piping Diagrams .......................................................... 38-40
Pumped Automatic Bypass .............................................. 41
Outdoor Operation: 3-Way Valve Cover ......................... 41
Automatic Bypass Valve Cover Installation ..................... 41
Manual Operation of the 3-Way Automatic Bypass ......... 41
Relief Valve ...................................................................... 42
Automatic Chlorinator and Chemical Feeders ................. 42
Water Flow Switch ............................................................ 42
Pump Purge Delay ........................................................... 42
Service Indicator Option ................................................... 42
5. ELECTRICAL CONNECTIONS
General Information ......................................................... 43
3-Way Automatic Bypass Valve Wiring .......................... 43
Pool Heater Operating Control Module ....................... 44-46
Wiring of the Cascade ...................................................... 46
6. STARTUP
Pre-Start Checklist ........................................................... 47
Starting the Filter System ................................................. 47
Check for Gas Leaks ....................................................... 47
Check/Control Water Chemistry ....................................... 47
Freeze Protection ........................................................ 47-48
Check Thermostat Circuit(s) ............................................ 48
Placing the Pool Heater in Operation ..........................48-50
7. OPERATING INFORMATION
General ............................................................................. 51
How the Control Module Operates .............................. 51-53
Sequence of Operation .................................................... 54
Jandy®
CXi™ Control Module ...................................... 55-56
Status Display Screens ............................................... 57-58
8. MAINTENANCE ..................................................... 59-63
9. CONNECTION DIAGRAM ...................................... 64-65
10. LADDER DIAGRAM .............................................. 66-67
11. START-UP CHECKLIST .............................................69
Revision Notes .................................................. Back Cover
