L100 Classic MkII

3-Way Bookshelf12-inch (300mm) Loudspeaker

Quick Start Guide

Overview

For more information on the set-up and operation of this

product refer to the product page on the jbl.com/specialty-audio/

website. Should further assistance be required feel free to

contact customer support at the numbers below.

Inside the US and Canada:+1 888.691.4171

Outside the US and Canada: +44 1707 668 012

Box Contents

1x L100 Classic Edition LoudspeakersMkII

2x Quadrex Foam Grilles

1x Quick Start Guide (This Document)

Placement and Positioning

●

Before deciding where to place your speakers, survey your room and think

about placement, using the illustration as a guide.

●

Avoid placing the speakers near power amplifiers, heat registers or other objects

that generate large amounts of heat.

●

Avoid placing speakers in humid or dusty locations.

●

Avoid placing speakers in direct sunlight or other intense light.

●

Refer to the illustration for distances from walls, between the speakers, and

angle to the listening position.

●

The speakers should be raised so that the tweeter is approximately at ear level.

The JS-120 or JS-150 speaker stand (sold separately) can be used to achieve

the proper listening height and angle.

●

Angle the speakers towards the listening position closer to the listeners ears for

a stronger center image and away from the listening position further from the

listeners ears for a more spacious image.

Specifications

Type:12-inch (300mm) 3-way Bookshelf Loudspeaker

Low Frequency Driver:12-inch (300mm) cast-frame Pure Pulp cone woofer with Dual

Spider (JW300SW-8)

Mid Frequency Driver:

5-1/4 inch (130mm) Polymer-coated, Pure Pulp cone

(JM125PC-8)

High Frequency Driver:1-inch (25 mm) Titanium dome tweeter mated to acoustic lens

and wave guide (JT025Ti2-4)

Recommended

Amplifier Power:

25-200 Watts RMS

Impedance:4 ohms

Loudspeaker Sensitivity:90dB

Frequency Response:40Hz-40kHz (-6dB)

Crossover Frequency:450Hz, 3.5kHz

Finish:

Natural Walnut veneer with Black, Orange, or Blue Quadrex

Foam Grille

Dimensions (With Grille):

25. x 15.4 x 14.(6mm x 389.mm x 3-inch-inch4-inch 42.99

3mm) 65.1

Controls:Attenuators for MF and HF Drivers

Input Type:Dual sets of Gold-plated Binding Posts

Product Weight (Each):63

lb (2 kg) each8.6

Shipping Weight:7

31 lb (33. kg) each

Shipping Units of Measure:Single Speaker

Recommended stand height:7in (180mm)

Recommended Stand:JBL JS-120 or JS-150 (Sold Separately)

JBL L100 Classic MkII Quick Start Guide | Rev 3. 20230501 | Part No. 950-0624-0010

©2023 Harman International | Features, Specifications, and Appearance subject to change without notice.

Pg 1 of 2

20in

(51cm)

20in

(51cm)

6ft (1.8mm) to

8ft (2.4mm)

Angle speaker to suit

listening preference.

See Postioning Bullet

Listening Position

40° to 60°
