Occasional refinements may be made to

existing products without notice but will

always meet or exceed original specifications

unless otherwise stated.

†The maximum recommended amplifier power

rating will ensure proper system headroom to

allow for occasional peaks. We do not recom-

mend sustained operation at these maximum

power levels.

*Dolby and Pro Logic are trademarks of

Dolby Laboratories.

DTS is a registered trademark of

Digital Theater Systems, Inc.

SP5

Frequency Response

45 10dB) – 20kHz (–

Recommended Maximum

Amplifier Power †

60 watts

Impedance

8 ohms nominal

Sensitivity

87dB (2.83V/1m)

Crossover Frequency

3,000Hz

Woofer

5-/1/4

" titanium-laminate cone

w/rubber surround

Tweeter

1"titanium-laminate dome,

w/Elliptical Oblate Spheroidal™

(EOS) waveguide, and swivel

mount

Plate Size (W x H)

7-1/2" x 10" (191mm x 254mm)

Mounting Cutout Size (W x H)

6-1/8" x 8-11/16" (156mm x 221mm)

Mounting Depth

3-3/4" (95mm)

SP6

Frequency Response

38 10dB) – 20kHz (–

Recommended Maximum

Amplifier Power †

80 watts

Impedance

8 ohms nominal

Sensitivity

88dB (2.83V/1m)

Crossover Frequency

2,000Hz

Woofer

6-/1/2

" titanium-laminate cone

w/rubber surround

Tweeter

1"titanium-laminate dome,

w/Elliptical Oblate Spheroidal™

(EOS) waveguide, and swivel

mount

Plate Size (W x H)

8-1/2" x 11" (216mm x 297mm)

Mounting Cutout Size (W x H)

7-1/8" x 9-11/16" (181mm x 246mm)

Mounting Depth

3-7/8" (98mm)

SP6C

Frequency Response

40 10dB) – 20kHz (–

Recommended Maximum

Amplifier Power †

80 watts

Impedance

8 ohms nominal

Sensitivity

88dB (2.83V/1m)

Crossover Frequency

3,000Hz

Woofer

6-/1/2

" titanium-laminate cone

w/rubber surround

Tweeter

1"titanium-laminate dome,

w/Elliptical Oblate Spheroidal™

(EOS) waveguide, and swivel

mount

Plate Size (Diameter)

9-3/16" (233mm)

Mounting Cutout Size (Diameter)

7-7/8" (200mm)

Mounting Depth

4-1/4" (108mm)

Declaration of Conformity

We, Harman Consumer International

2, route de Tours

72500 Chateau-du-Loir

FRANCE

declare in own responsibility, that the products described in this

owner’s manual are in compliance with technical standards:

EN 50081-1:1992

EN 50082-1:1992

Steen Michaelsen

Harman Consumer International

Chateau-du-Loir, FRANCE.9/00

DESIGN GOAL:Combine the superior performance of traditional

JBL loudspeakers with the convenience of in-wall installation.

TWEETER TYPE:Titanium-laminate-dome with EOS

waveguide, and swivel mount

WOOFER TYPE:

Titanium-laminate cone with rubber surround

CROSSOVER NETWORK:Straight-Line Signal Path (SSP)™

PROFESSIONAL REFERENCE:Studio Monitor

OWNER’S GUIDE

PRODUCTLINE:

MODELS:

SP5, SP6 and SP6C

SoundPoint

™

Series

SPECIFICATIONS

©2000 JBL, Incorporated.

JBL is a registered trademark of JBL, Incorporated.

Part No.

170-0021

PRO SOUND

COMES HOME

™

JBL Consumer Products

250 Crossways Park Drive, Woodbury, NY 11797

8500 Balboa Boulevard, Northridge, CA 91329

800-336-4JBL(4525) (USA only)

www.jbl.com

NOTE:For new-construction applications, be sure

to purchase the correct rough-in frame kit.
