Seite 1/6
1
undEr countEr
Glass
door Refrigerator
DETAILED PLANNING DIMENSIONS GUIDE
JUGFR242HL, JUGFL242HL, JUGFR242HM, JUGFL242HM, JUGFL242HX, JUGFR242HX
23⁄" (W) x 34⁄" (H) x 23⁄" (Depth without door panels/handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
Choose one of following configuration to match your kitchen design.
Base Unit
(Panel Ready)
RISE™ Model NOIR™ Model
LH: JUGFL242HX
RH: JUGFR242HX
LH: JUGFL242HL
RH: JUGFR242HL
LH: JUGFL242HM
RH: JUGFR242HM
OPTIONAL ACCESSORIES FOR CUSTOM OVERLAY DESIGNS
RISE™ STAINLESS HANDLE KIT
W11231237
For use with Custom Overlay panels
Quantity - One handle per kit
NOIR™ STAINLESS HANDLE KIT
W11231236
For use with Custom Overlay panels
Quantity - One handle per kit
W11356583B
2
undEr countEr
Glass
door Refrigerator
DETAILED PLANNING DIMENSIONS GUIDE
JUGFR242HL, JUGFL242HL, JUGFR242HM, JUGFL242HM, JUGFL242HX, JUGFR242HX
23⁄" (W) x 34⁄" (H) x 23⁄" (Depth without door panels/handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
PRODUCT DIMENSIONS
23⁄"
(60.72 cm)
Depth
(no handle)
34⁄"
(87.32 cm)*
†
30⁄"
(77.5 cm)**
3⁄"(9 cm)*
*Add 5/8" (1.6 cm) to the height dimension when leveling legs are fully extended.
**For custom panel models, this will vary.
†Add 1/4" (6.4 mm) to the height dimension for height with hinge covers.
VARIANT
DEPTH
(NO HANDLE)
RISE™ Model
23⁄" (60.4 cm)
NOIR™ Model
23⁄" (60.8 cm)
Panel ready models
(with 3/4" panel)
23⁄" (60.2 cm)
3
undEr countEr
Glass
door Refrigerator
DETAILED PLANNING DIMENSIONS GUIDE
JUGFR242HL, JUGFL242HL, JUGFR242HM, JUGFL242HM, JUGFL242HX, JUGFR242HX
23⁄" (W) x 34⁄" (H) x 23⁄" (Depth without door panels/handles)
Because Whirlpool Corporation policy includes a continuous
commitment to improve our products, we reserve the right to
change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details,
see Installation Instructions packed with product. Specifications
subject to change without notice.
DIMENSION DESCRIPTION RISE™ Model NOIR™ Model
Panel ready models
(with 3/4" panel)
AWidth of door 23⁄" (60.3 cm)
BWidth of the grille 23⁄" (60.5 cm) 23⁄" (60.5 cm) 23⁄" (60.5 cm)
CHeight to top of handle 28⁄" (71.3 cm) 28⁄" (71.3 cm) **
D
Width from side of
refrigerator to handle –
door open 90°
2⁄" (6.2 cm) 1⁄" (5 cm) **
EDepth without door 21⁄" (55.1 cm)
FDepth with door 23⁄" (60.4 cm) 23⁄" (60.8 cm) 23⁄" (60.2 cm)
GDepth with handle 26⁄" (67.5 cm) 26⁄" (66.3 cm) **
HDepth with door open 90° 48" (121.9 cm) 47⁄" (121.8 cm)
**For custom panel models, this will vary.
A
B
C
D
E
F
G
H
FRONT VIEW SIDE VIEW
22⁄"
(56.8 cm)
TOP VIEW
