Seite 1/4
I N S T A L L A T I O N G U I D E
for the
SB-FIAT-500/10TW3
SKU# 94578
2007 & Up Fiat 500
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your authorized
JL Audio dealer. The installation professionals employed by your dealer have the necessary tools
and experience to disassemble and reassemble your vehicle properly. If you prefer to perform your
own installation, please read this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital that
the Stealthbox ® be properly mounted to the vehicle according to these
instructions. Failure to mount the enclosure properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the enclosure
caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a collision
or sudden deceleration.
Continued on Next Page
SB-FIAT-500/10TW3 INSTR_SKU# 011366
INSTALLATION
D I F F I C U L T Y :
25
OUT
OF
ESTIMATED TIME:
1 HOUR
S P E C I F I C A T I O N S
Enclosure Type: Sealed
Driver Type: 10TW3-D4
Nominal Impedance: 2 ohms
Continuous Power Handling: 400 watts (RMS method)
I N C L U D E D H A R D W A R E
(1) U-Nut
(1) 3/8 - 16 x 2-1/4” Set Screw
(1) 3/8” Fender Washer
(1) 3/8” Lock Washer
(1) 3/8 - 16 Hex Nut
SB-FIAT-500/10TW3 INSTR_SKU# 011366
P O W E R R E C O M M E N D A T I O N
JL Audio recommends high quality ampliers such as the JL Audio XD300/1v2. The diagram below shows the recommended crossover settings for the XD300/1v2. For a detailed description of the amplier settings, con-
sult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
C O N N E C T I O N S
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your Stealthbox® amplier. Other kits
are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for both channels of the amplier. JL Audio
recommends using 12AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page Page 2 • JL Audio, Inc., 2016
Continued on Next Page
SB-FIAT-500/10TW3 INSTR_SKU# 011366
Page 3 • JL Audio, Inc., 2016
S T E P 4
Slide a U-Nut over the brace and align it with the hole drilled
in the previous step. Thread a 3/8 - 16 x 2-1/4” into the U-Nut,
leaving about 1-1/4” exposed as shown.
S T E P 8
Reinstall the subwoofer.
S T E P 3
Measure and mark the center of the brace between the two
factory holes. Drill a 9/16” hole on the mark.
Before drilling, always make sure that you are not
going to be drilling into any gas lines, brake lines,
tires, transmission lines, electrical wiring, exhaust
systems or anything else that might cause a reduction
in your weekly pay.
Always wear eye protection when drilling!
S T E P 7
Slide a 3/8” Fender Washer, a 3/8” Lock Washer, and a 3/8 -
16 Hex Nut over the 3/8 - 16 x 2-1/4” Set Screw, and firmly
tighten. Route the speaker cable as necessary.
S T E P 2
Carefully unclip the rear sill panel, and remove the panel.
For Hatchback Models: Remove shelf and Phillips head
screw below the shelf.
For Convertible Models: Unclip the carpet from the under
the rear deck.
Pull back the trunk liner and locate the brace.
S T E P 6
Attach speaker cable to the terminal cup on the Stealthbox®,
and place it back into position in the trunk, allowing the 3/8 -
16 x 2-1/4” Set Screw to pass through the hole in the back of
the enclosure.
S T E P 1
Empty out the trunk of the vehicle. Remove the woofer from
the Stealthbox® and place the enclosure into position in the
trunk. Mark the trunk liner through the hole in the back of
the enclosure. Remove the enclosure, and cut an “X” on the
mark.
S T E P 5
Reinstall the trunk liner, allowing the 3/8 - 16 x 2-1/4” Set
Screw to pass through the cut made in Step 1. Reinstall the
other trunk parts.
