Light Management Radio-control pushbutton and pilot lamp

Ref.-no.: ..1561.07FKO..

Operating Instructions

Radio-control pushbutton and pilot lamp

1. Function

The radio-contol pushbutton permits radio-controlled or manual switching

and dimming of lamps.The starting brightness can be stored in the device

as memory brightness. The pushbutton with radio-control receiver is

plugged onto one of the following inserts:

Universal touch dimmer 1254 UDE

Standard touch dimmer 1225 SDE

Relay insert single-channel 1201 URE

Relay insert two-channel 1202 URE

Tronic switching insert 1254 TSE

LV triac switching insert 1244 NVSE

Touch control unit 1240 STE

Relay insert with potential-free contact 1201-1 URE After reception of a

data telegram from a programmed radio-control detector and

corresponding darkness, the radio-contol pushbutton is switched on for

about 1 minute with the preset memory brightness. The radio-contol

pushbutton can be programmed to identify up to 30 radio channels.

Lightscapes

The radio-contol pushbutton can be included in up to five lightscapes

which are activated with the corresponding radio-control transmitters (e.g.

hand-held transmitter ‘Komfort’) and stored. The desired lightscape key

must be programmed beforehand into the radio-contol pushbutton.

All-ON / All-OFF

The programming of a radio channel (e.g. hand-held transmitter

‘Komfort’) always includes the simultaneous and automatic storage of the

functions of the All-ON or All-OFF key.The All-ON or All- OFF key of a

radio-control transmitter switches the load connected to the switching

actuator on or off.

Light control

In combination with a programmed radio-control presence detector, the

radio-contol pushbutton can be used for lighting control functions. For

more information, refer to the operating instructions of the radio presence

detector.

Stand: Mai-07 325 276 53
