KNX Stetigregler
Art.-Nr.: ..2178..
Continuous-action regulator
1. Safety instructions
Electrical equipment must be installed and fitted by qualified
electricians only.
Failure to observe the instructions may cause damage to the device
and result in fire or other hazards.
These operating instructions are part of the product and must be left
with the final customer.
2. Device layout
(Fig. 1)
(1) Presence button
(2) Adjusting wheel
(3) Status LED
3. Function
System information
Stand: Sep-07 825 629 03
KNX Stetigregler
Art.-Nr.: ..2178..
This device is a product of the KNX system and complies with KNX
directives. Detailed technical knowledge obtained in KNX training courses
is a prerequisite to proper understanding.
The functionality of this device depends on the software. Detailed
information on software versions and attainable functionality as well as
the software itself can be obtained from the manufacturer‘s product
database.
Planning, installation and commissioning of the unit is effected by means
of KNX-certified software. The full functionality with KNX commissioning
software is available from version ETS3.0d onwards.
The product database, technical descriptions, conversion programs and
other utilities are always available in their latest versions in the Internet
under www.jung.de.
Designated use
Single-room temperature regulation in KNX installations.
Flush-mounted installation in hollow or in solid walls.
Product features
Measurement of the room temperature and comparison with the
temperature reference value)
Reference value preset by selecting the mode of operation
Operating modes ‚comfort‘, ‚standby‘, ‚night-time‘,frost/heat protection‘
Heating and cooling
Heating and cooling at basic and backup levels
Adjusting wheel zur Sollwert-Korrektur
Presence button
Status LED
4. Operation
Operating modes and status LED
The regulator compares the actual room temperature to the preset
reference temperature and adjusts heating and cooling installations in
accordance with the respective energy requirements. The temperature
reference value depends on the respective operating mode and can be
varied with the adjusting wheel (Fig. 1, 2). The operating modes and the
current regulator status are indicated by means of status LEDs (Fig. 1, 3)
Comfort mode
Standby mode
Night-time mode
Frost/heat protection mode
Comfort prolongation mode(night)
Comfort prolongation mode (frost/heat protection)
2
KNX Stetigregler
Art.-Nr.: ..2178..
Heating/cooling active indicator
Heating mode indicator
Cooling mode indicator
Controller locked indicator (dew-point mode)
L The indication of the controller status can last up to 30 s.
Setting the mode of operation
Control elements for setting the operating mode are installed, e.g. touch
sensors, control panels, etc.
Activate the desired mode of operation with the corresponding control
element.
The new operating mode is indicated by means of status LEDs (Fig. 1,
3).
The reference temperature for the room is set in accordance with the
selected operating mode.
Changing the room temperature
To increase the reference temperature:
turn the adjusting wheel clockwise.
To lower the reference temperature: turn the adjusting wheel counter-
clockwise.
Activating the comfort prolongation
It is desired to prolong the comfort mode for a certain time beyond the
preset automatic switch-over of the operating mode. This can be ensured
by the comfort prolongation. The time for which the comfort prolongation
mode can be prolonged is limited.
Komfortverlängerung aktivieren
The regulator is in the night-time mode or in the frost/
heat protection mode.
Press the presence button (Fig. 1, 1)
The LEDs
or are lit up.
The reference temperature of the comfort mode is now active for the
pre-programmed time.
After the end of the programmed time span, the originally set night-
time or frost/heat protection mode is resumed
L The comfort prolongation can also be activated
L automatically, e.g. from a presence detector.
L Information for qualified electricians
L DANGER!
Electric shock in case of accidental contact
with live parts. Electric shocks may
3
