USER MANUAL
USER MANUAL
UNPACKING THE BIKE
Carefully remove the bike from the cardboard box. Lay out all the components and check to assure
all parts are present and undamaged. If parts are missing or damaged contact your local dealer,
distributor or Keiser Corporation Service Department. After unpacking and verifying parts, you are
ready to start your assembly. You need an area that is free of dirt, dust or other foreign material that
could impair the assembly of your bike.
BEFORE ASSEMBLING
Always follow the steps in this manual as you assemble your bike. Do not skip, substitute or modify
any steps or procedures of this assembly, as doing so could result in personal injury and will void your
warranty. We have put a number of precautions in this manual.
NOTE: Informs you about things we recommend you do or are aware of, before
performing the assembly. These notes are placed in the manual to aid you during a
certain procedure or to make you aware of any general mandatory actions or information.
WARNING: This symbol appearing throughout this manual means PAY ATTENTION! BE
ALERT! When you see this warning symbol, your safety is involved. It is being used to
call attention to POTENTIAL hazards that could result in personal injury or loss of life.
1
PRE-ASSEMBLY INSTRUCTIONS .....................................................
ASSEMBLY INSTRUCTIONS ..............................................................
M3 HANDLEBAR INSTALLATION ......................................................
M3
+
HANDLEBAR INSTALLATION ..................................................
FLYWHEEL GUARD INSTALLATION ..................................................
CHECKING FOR PROPER OPERATION ............................................
SAFETY INFORMATION AND INSTRUCTIONS .................................
BIKE FITTING .....................................................................................
RESISTANCE/COMPUTER OVERVIEW .............................................
CALIBRATION INFORMATION ...........................................................
PREVENTITIVE MAINTENANCE CHART ...........................................
WARRANTY TERMS ...........................................................................
1
4
6
7
9
11
11
12
15
17
18
19
TABLE OF CONTENTS
Torque wrench (Minimum 45 Nm / 35 ft-lb) 16mm, or 5/8” crowfoot
4” extension 5mm Allen Wrench
15mm open-end wrench 6mm Allen Wrench
16mm, or 5/8” open-end wrench Paste or spray wax (used to clean after assembly)
#2 Phillips screwdriver Clean cloth
15mm crowfoot LPS #3 Heavy Duty Rust Inhibitor w/straw
2 - 10mm Wrenches
TOOLS YOU WILL NEED
NOTE: The substitution or modification of any part or component,
other than what is approved by Keiser, will void your warranty.
PARTS INVENTORY
A - M3 Handlebar Assembly (550815) I - 5 Socket Head Cap Screws M6x1 X 20 SS (9502)
B - Base Frame (550814) J - 2 Socket Head Cap Screws M8x1.25 X 12 SS (9513)
C - Bike Frame (550819/550820) K - Computer (models with computer only)
D - Flywheel (555003) L - Flywheel Guard
E - 2-Pedals / 1- Loctite 242 (540831) M - Flywheel Guard Clamp (555025)
F - Hubcap (555005) N - Hex Head Screw M6x1 X45 SS (9525)
G - 4 Acorn Nuts (555022) O - Hex Nut M6x1SS (9508)
H - 4 Washers (9384)
P - Hub Cover Decals
B
C
E
F
G
H
J
I
A
K
Transport Wheels
L
N
P
O
M
2
NOTE: The M3
+
Parts Inventory will not include item A - M3 Handlebar Assembly (550815).
It will include items A1-A5, and will require following the M3
+
Handlebar Assembly procedure.
Item P - Hub Cover Decals, will be shipped with, and are to be installed on M3/M3
+
sold
within the European Union only.
M3
+
HANDLEBAR
PARTS INVENTORY
A1 - M3
+
Handlebar Assembly (550835)
A2 - Sweat Guard Cover (555080)
A3 - Bottom Slide (555026)
A4 - Handlebar Spacer (555031)
A5 - L-Handle Assembly (550828)
A1
A3
A2
A5
A4
