Seite 1/12
KKPro3D66SS
KKPro2D49SS
KKPro1D23SS
Stainless Steel Reach-In
Convertible
Freezer/Refrigerator
03/2025-v6 H1S422
Congélateur / réfrigérateur
convertible
en acier inoxydable
WARRANTY / GARANTIE
2
Limited Warranty
Year
2
Garantie limitée
Ans
FOR
TWO YEARS from the date of sale this product is warranted against defects in material
or w
orkmanship.
WITH PROOF OF SALE a defective product will be repaired or replaced free of charge.
The Kenmore br lic Direc c f warrant service tand is used under ense. t all laims or y o Koolatron
Customer Assistance, call 1-800-265-8456 or email service@koolatron.com
This warranty covers manufacturer’s defects including electrical and mechanical defects
provided the appliance is correctly assembled, operated and maintained according to the
supplied instructions. It does not cover damage caused by accident, misuse or abuse
including overheating, unauthorized repairs or alterations, or use with a voltage converter
or aftermarket accessories, and it does not apply to scratches, stains, discoloration or
other surface damage that does not impair the product function.
PENDANT DEUX
ANS à compter de la date d’achat d’origine ce produit Kenmore sera
e
xempt de défauts de matériaux ou de fabrication.
Un produit défectueux sera réparé ou remplacé gratuitement, AVEC PREUVE DE VENTE.
Le nom de marque Kenmore est utilisé sous licence. Adressez toutes les demandes de
service de garantie à Service à la clientèle du Koolatron, au 1-800-265-8456 ou en envoyant
un courriel à service@koolatron.com
La présente garantie couvre les défauts de fabrication, y compris les défauts électriques et
mécaniques, à condition que l’appareil soit correctement assemblé, utilisé et entretenu
conformément aux instructions fournies. La présente garantie ne couvre pas les dommag-
es causés par un accident, une mauvaise utilisation ou un abus, y compris la surchauffe, les
réparations ou modifications non autorisées, ou l’utilisation avec un convertisseur de
tension ou des accessoires de rechange, et elle ne s’applique pas aux rayures, taches,
décoloration ou autres dommages de surface qui n’affectent pas le fonctionnement du
produit.
Koolatron Corporation
4320 Federal Drive, Batavia, NY 14020 U.S.A.
139 Copernicus Blvd., Brantford, ON N3P1N4 Canada
Kenmore and the Kenmore logo are registered trademarks to Transform SR Brands Management LLC
and are used under license by Koolatron Corporation
Kenmore et le logo Kenmore sont des marques déposées de Transform SR Brands Management LLC et
sont utilisées sous licence par Koolatron Corporation
Use & Care Guide
Guide d'utilisation et d'entretien
Customer Assistance
Service à la clientèle
1-800-265-8456
www. koolatron.com
2 3
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
ELECTRICAL SAFETY PRECAUTIONS
1. Always use a dedicated outlet that is properly grounded. DO NOT attempt to
alter the plug in any way to make it fit into an ungrounded outlet.
2. Ensure that the plug is tightly connected to the outlet before using the unit.
3. Do not attempt to operate the appliance if there is damage to the cord or plug.
Have it immediately replaced by a qualified technician.
4. Do not insert or remove the power plug if there is any indication of flammable
gasses present.
5. Do not repeatedly cycle the power button as this could lead to electric shock or
short-circuiting of the unit.
6. Always unplug the power cord before cleaning or during a power interruption.
Wait at least 5 minutes before plugging the power cord back in to avoid damage
to the compressor.
OTHER SAFETY PRECAUTIONS
1. Never store flammable, explosive or corrosive items in the unit.
2. Do not store items on the top of the unit.
3. Never expose the unit to water or place the unit in a wet location.
4. Be careful not to touch hot surfaces when cleaning the condenser.
PLACEMENT PRECAUTIONS
1. STABLE SURFACE: Unit should be installed on a flat surface capable of support-
ing the full weight combined weight of the unit and its contents. If any material is
used to support the unit, ensure that the material is not flammable.
2. HEAT SOURCES: For optimal refrigeration performance, unit should be kept
away from all heat sources and not placed in direct sunshine.
3. VENTILATION: Unit should be installed in a well-ventilated area with a minimum
of 1.5 inches (3.8 cm) clearance on the sides and back.
4. EXTERNAL ELEMENTS: Unit should not be installed anywhere with an ambient
temperature below 41°F (5°C). The unit must always be protected from dust, rain,
and direct sunlight and is not recommended for outdoor use.
KNOW YOUR FREEZER
1. Thermostat
2. Power switch
3. Lock
4. Light and fan switch
5. Shelf
6. Shelf support rail
7. Door
8. Caster
SAVE THESE INSTRUCTIONS
4 5
KNOW YOUR FREEZER
KNOW YOUR CONTROL PANEL
BEFORE FIRST USE
1. Carefully remove the unit from the pallet. Remove all cardboard packaging, plastic bags
and tape from the outside of the unit.
2. Remove any packaging material, keys and any other accessories from the inside of the
unit.
3. Check the unit for any broken or missing parts. Contact the seller with any questions.
4. Place the unit in a suitable location per the safety instructions on the previous pages.
5. Clean the inside and outside of the unit and check the operation of the door(s) before
plugging the unit in.
6. Let the unit cool down to proper operating temperature before storing products inside.
CLEANING PROCEDURES
INSIDE AND OUTSIDE SURFACES
1. Clean the interior and exterior surfaces of the unit with a soft cloth and gentle, non-abra-
sive cleaning agent. Do not use any corrosive cleaning agents.
2. Clean the door gasket on a regular basis to help maintain an airtight seal between the
door and the cabinet.
3. Dry all surfaces with a clean, soft cloth.
CONDENSER COIL
1. Check the condenser coil once a month for visible dirt and dust as a dirty condenser coil
will affect refrigeration performance.
2. Turn off power to the unit before cleaning the condenser coil.
3. Using a soft brush, gently brush vertically along the fins to remove any built up dust. Do
not horizontally against the fins as this could damage them and negatively impact refriger-
ation performance.
NOTE – After cleaning, check to ensure that all parts that were removed have been properly
reinstalled and the unit is safe to use.
CONTROL PANEL TECHNICAL SPECS
Technical Specification Wiring Diagrams
Technical Datasheet
Model
KKPro1D23SS
KKPro2D49SS
KKPro3D66SS
Model
KKPro1D23SS
KKPro2D49SS
KKPro3D66SS
The above specifications are tested in an ambient temperature of 90°F (32°C).
Frequency
(Hz)
60
60
60
Dimension
(L×D×H)
27”x31.5“x83.25”
54.5”x31.5“x83.25”
81.5”x31.5”x83.25”
Net Volume
(cu. ft.)
19.32
43.50
68.30
Temperature
(°F)
33~41 / -13~-5
33~41 / -13~-5
33~41 / -13~-5
Working power
(W)
500
800
1050
Net weight
(lb)
252.4
390.2
563.3
Rated Voltage
(V)
115
115
115
Function
compressor
fan
defrost
auxiliary
alarm
digits
Remark
E0/E1/dr/Lo/HI alarm
No.
1
2
3
4
5
6
2
Indicator Lights State
display value and code
ON
on
on
on
on
alarm
OFF
off
off
off
off
no alarm
FLASH
call
call
call
-
-
Connector:
Power supply:
Power consume:
Display:
Fixed terminal
115VAC±10%, 50/60Hz
7.0VA max
Three-digit digital tube
and symbol light
Input:
Outputs:
Working temp.:
Storage temp.:
Relative humidity:
2 NTC probes and
1 single input
Refer to the wiring diagram
-10°C ~ 55°C
-25°C ~ 75°C
20% ~ 85% (no frost)
3
1
4 6
5
