Seite 1/9
STAND FAN
SF161ME
P/N: 40-51692-00
1Year
Warranty
General
3Year
Warranty
On Motor
+
1 800 88 0032
KHIND CARE Mobile App
1-800-88-0032
khind.com.my
Download to register for
E-Warranty & enjoy hassle-
free after-sales services.
U S E R M A N U A L
Please read this manual carefully before operating this product.
Keep this manual handy for further reference.
IMPORTANT
1. Ensure that the fan is switched off from the supply mains before removing the fan guard for
cleaning.
2. Use this fan with specified voltage as stated on the rating sticker. Before connecting fan to
the AC mains, make sure the voltage specified corresponds to the AC supply to your house.
3. Do not insert finger or other objects into the fan guard.
4. Do not attempt to repair the fan. Always return to our authorised service agents for repairs.
5. Do not immerse the motor assembly or any parts of the fan inside the water or other
liquids.
6. This appliance is intended for household use only. Do not use the appliance outdoors or
near windows. Rain drops may cause electrical hazards.
7. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
8. Do not operate this appliance without a fan blade, broken or bent fan blade.
9. Handle fan blade with care during cleaning.
10. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
11. The ventilation holes of rear motor cover must be free of dust & dirt. Please use a soft cloth
or vacuum cleaner to clean it frequently.
WARNING: Do not use this appliance high temperature and high humidity
1. Keep the fan clean. Use it in dry place.
2. Do not bend the blades when installing & maintaining.
3. Wipe away dirt with clean soft cloth, soap & water to clean the fan. Wipe until dry.
4. Do not use the following as cleaning solvents: petrol, thinner or benzene for cleaning.
5. Use mild soap with damp cloth or sponge to clean the plastic parts.
Cleaning & Maintenance
1. Unblock the guard ring lock by removing the safety screw.
2. Remove the front fan guard
3. Remove the blade locking screw.
4. Detach the fan blade.
5. Remove the rear fan guard by removing 4 screws.
6. Wash detached components with soft cloth and mild soap or mild detergent.
7. Wipe dry with a soft cloth. Note that excessive rubbing with a soft cloth may scratch the
components.
8. Clean dust and dirt that have accumulated on the motor shaft.
Clean Fan Guards & Fan Blades
Safety Precaution Information1 2
1. Fan Head
Assembly
2. Blade Nut
3. Fan Blade
4. 4pcs Screw
5. Rear Guard
6. Rear Guard
Screw
7. Motor Housing
8. ON/OFF/Speed
Knob
9. Tilt Adjust Knob
10. Inner Tube
11. Height Adjustment
Screw
12. Outer Tube
13. Base
14. Base Washer
15. Base Small Washer
16. Base Thumb Screw
17. Tilt Range Knob
18. Tilt Adjustment Bolt
19. Tilt Range Screw
20. Fixed Screw
Parts Identification
* Pictures are for illustration purpose only.
16
15
14
12
11
10
9
8
75
4
321
6
13
19
20
17
18
3 4
How to Use
Model SF161ME
Voltage 220-240V ~ 50/60Hz
Power 50W
Blade Size 16 Inches
Blade Type ABS
Blade Quantity 5
Effective Area 20m
Oscillation Degree 70˚
Revolution Per Minutes High Speed: 1133rpm
Low Speed: 870rpm
Air Delivery 64.33m /min ; 2271CFM
Noise Level 58.4dB
Net Weight 6.4kg
Product Dimension (LxWxH) 450 x 400 x 1200mm
Height Adjustment Low: 900mm
Height: 1200mm
Specifications
* Specifications are subject to change without prior notice.
3
2
Assembly
1. Loosen the screw on the base by turning it counter clockwise from
the base pipe, remove it and insert the base pipe into the base.
2. Then secure base pipe by turning the base screw
clockwise to the bottom of the base using the base
washer and the base tightening ring.
3. Loosen the lock regulator of the base pipe, pull the inner tube out, and then tighten again.
When you have completed the assembly or the base of the fan to the base pipe place
the appliance on a flat surface.
4. Loosen the locking regulator located on the small motor shaft and the align the small
motor shaft with the socket on the wood en inner tube. turn the locking regulator until it
locks into place.
Depression
Depression
this side
5. Each side of the post top section has a small
horizontal open slot and horizontal depression as per
shown.
6. Place and position the head assembly on the post
top section matching open slot and depression.
Note: It is important that the post and fan head are
assembled correctly.
7. Slide the Tilt Adjustment Bolt all the way through as
per shown.
8. Screw in the Tilt Range Knob as per shown.
9. Using a screwdriver, screw in the small Tilt Range
Screw and tighten up.
10. Screw on the Tilt Adjustment Knob as per shown.
Open
Slot
