AMI 310
Quick Start Guide
EN FR ES IT ZH
www.sauermanngroup.com
DE
English
Quick start guide
Operating temperature, protection of the instruments and information about storage and the battery
1 Device description
•
Operating temperature: 0 to +50 °C (+32 to +122 °F)
• IP 54
• Storage temperature: -20 to +80 °C (-4 °F to +176 °F)
The AMI 310 measures simultaneous parameters including pressure, temperature
(Pt100 and thermocouple), humidity, air quality (CO/CO
2
), air velocity, airow
(vane probes and hotwire), and tachometry.
If the instrument is stored outside the operating temperature (for example in a van, a
warehouse,...) please wait for 10 minutes in its operating temperature before starting and using it.
Rechargeable Li-ion battery inside the instrument, 16 h battery-life with a pressure module or 14h
a hotwire probe. The instrument is supplied with a 5 V, 1 A power adapter to load the internal
battery. The current loading is indicated by a battery symbol on the top left of the screen.
The orange led on the bottom of the instrument is also on until the full loading of the battery
(the led turns green).
1. Battery level
2. USB connection indicator
3. Battery level
4. Date and time
5. Home screen
6. Measurement menu
7. Dataset menu
8. Conguration menu
9. Information menu
10. Function keys
11. OK button
12. Navigation arrows
13. ESC button
14. On/Off button
1
2 3
4
5
6
7
8
9
10
11
12
13
14
Directive 2014/53/EU
Hereby, Sauermann Industrie SAS declares that the radio equipment type AMI 310 is in compliance
with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the
following internet address: www.sauermanngroup.com
Add a wireless probe
With arrow
keys, go to
“Information”
menu
OK OK
In “Information”
menu go to
“Wireless probe”
On the bottom
of the screen
press the
function key
“Create”
Turn on the wireless
probe and keep it press
until the light blinks
Pairing is in
progress
The probe information is displayed with
the function key “Meas.” It is possible
to back to the measurement screen. It is
also possible to delete the wireless probe
pressing the function key “Delete”.
The instrument in on.
Select with arrows keys menu. Press “Measurement” OK.
Select with arrows keys the measurement in which the dataset will be
performed.
Press “Functions” key then select “Dataset” with arrow keys and
press OK.
Dataset menu is displayed.
Go to line with arrow keys and press “Name” OK.
A keypad is displayed on the bottom of the screen.
Select the letters with arrow keys then press OK.
To go from the lower case keypad to the upper case keypad then to
the numeric keypad, press the function key:
To delete a letter press the function key “Delete”.
Press the function “Validate” to validate the name of the dataset.
A dataset is composed of several dated measuring points.
You can choose between an automatic dataset or a manual dataset.
Go to “Type” with arrow keys then press OK.
Select “Manu.” for manual or “Auto.” for automatic.
Go to then press “Start” OK.
4 Start and record datasets
