Seite 1/30
ČeskySvenskaSuomiMagyar
Español
ItalianoNederlandsFrançaisDeutschEnglish
CMP-PSUTESTER5
Power supply tester
MANUAL
MODE D’EMPLOI
MANUALE
HASZNÁLATI ÚTMUTATÓ
BRUKSANVISNING
ANLEITUNG
GEBRUIKSAANWIJZING
MANUAL DE USO
KÄYTTÖOHJE
NÁVOD K POUŽITÍ
Česky Svenska Suomi Magyar Español Italiano Français Deutsch English
1
Nederlands
A must have tool for anyone with PCs to test power supplies before putting them into
a PC. A bad power supply could damage system components if the voltages are not
correct, and do not assume that a brand new supply will always operate correctly.
Instructions:
BE AWARE: NEVER PLUG IN 2 CONNECTORS AT THE SAME TIME (NOT INCLUDING
THE 24/20 PIN CONNECTOR)
1. Plug in your 24/20 pin power supply connector to the tester.
2. Turn on your power supply.
3. LCD shows each voltage and P.G. value on the screen automatically and two beeps
can be heard.
4. The ATX power output connectors will be checked one by one. If the power output is
working properly the LED will come on, when it’s not working properly the LED light
will not come on.
5. Plug in the HDD and afterwards the Floppy connector and check the LED light
(+12V1 and +5V).
6. Plug in the SATA connector and check the LED light (+12V1, +5V and +3.3V).
7. Remove the connectors after checking (accept 24/20 PIN).
8. When abnormal voltage is detected it will not be displayed on the screen.
9. When no voltage is detected the screen will show “LL”.
10. When a voltage below minimum is detected it will show “LL”.
11. When a voltage higher than maximum is detected it will show “HH”.
12. When a voltage is detected which is lower or higher than the value shown in the
table below an alarm will sound.
13. When a P.G. value is detected which is lower than 100ms or higher than 900ms an
alarm will sound.
14. With any abnormality an alarm will sound and the related digit will blink.
2
ČeskySvenskaSuomiMagyar
Español
ItalianoNederlandsFrançaisDeutschEnglish
Normal Voltage range Display Voltage range
Lower (A) Higher (B) Min. ( C) Max. (D)
+5V 5V +4.75V +5.25V 4V 6.0V
-12V -12V -11V -13V -10V -14V
+12V1 12V 11V +13V 10V 14V
+12V2 12V 11V +13V 10V 14V
+3.3V 3.3V +3.14V +3.47V 2.0V 4.5V
+5VSB 5V +4.75V +5.25V 4.0V 6.0V
PG 0ms 990ms
Warning: This product is designed only for power supply output tests. Do not leave the
tester connected to the power supply unattended. It generates heat and could possibly
damage your power supply.
All brands and registered trademarks are property of the respective possessors.
Safety precautions:
To reduce risk of electric shock, this product should ONLY be opened by an authorized
technician when service is required. Disconnect the product from mains and other
equipment if a problem should occur. Do not expose the product to water or moisture.
Warranty:
No guarantee or liability can be accepted for any changes and modifi cations of the
product or damage caused due to incorrect use of this product.
General:
Designs and specifi cations are subject to change without notice.
All logos brands and product names are trademarks or registered trademarks of their
respective holders and are hereby recognized as such.
Attention:
This product is marked with this symbol. It means that used electrical and
electronic products should not be mixed with general household waste. There
is a separate collections system for these products.
Copyright ©
