P/N: 2900-300846 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX
12G SDI Matrix Switcher
Kramer Electronics Ltd.
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX Contents –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Dening ASPEN-32UFX, ASPEN-1616UX, VS-8UFX 12G SDI Matrix Switcher 4
Installing in a Rack 7
Connecting ASPEN-32UFX, ASPEN-1616UX, VS-8UFX 8
Connecting ASPEN 32UFX, ASPEN 1616UX 8
Connecting VS-8UFX 9
Conguring ASPEN-32UFX, ASPEN-1616UX, VS-8UFX 10
Conguring Web Pages –10
Conguring Front Panel –20
Operating ASPEN-32UFX, ASPEN-1616UX, VS-8UFX 21
Operating Web Pages –21
Operating Front Panel Buttons –23
Technical Specications 25
Default Communication Parameters 27
Resetting the Unit 28
Protocol 3000 29
Understanding Protocol 3000 30
Kramer Protocol 3000 Syntax 30
Extended Protocol 3000 31
Other Rules 33
Protocol 3000 Commands 34
Kramer Electronics Ltd.
ASPEN-32UFX, ASPEN-1616UX, VS-8UFX Introduction –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/ASPEN-32UFX to check for up-to-date user manuals,
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving the Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer ASPEN-32UFX, ASPEN-1616UX, VS-8UFX away from moisture,
excessive sunlight and dust.
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
Safety Instructions
Caution: There are no operator serviceable parts inside the unit.
Warning: Use only the power cord that is supplied with the unit.
Warning: Do not open the unit. High voltages can cause electrical shock! Servicing by
qualied personnel only.
Warning: Disconnect the power and unplug the unit from the wall before installing.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landll or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
