Seite 1/17

33210 Rev. R http://www.transition.com/ Page 1 of 17

E-100BTX-FX-05

User Guide

Stand-Alone Media Converter

• Fast Ethernet

• Copper to Fiber

• 100Base-TX to 100Base-FX

• Extended Temperature

Contents

Introduction.................................................................................................................................................... 1

Standard Temperature Models ................................................................................................................. 2

Extended Temperature Models ................................................................................................................ 3

Installation ..................................................................................................................................................... 4

4-Position DIP Switch ............................................................................................................................... 4

AutoCross Jumpers .................................................................................................................................. 5

Installing the Fiber Cable .......................................................................................................................... 6

Installing the Copper Cable ...................................................................................................................... 6

Powering the media converter .................................................................................................................. 7

Operation....................................................................................................................................................... 8

Status LEDs .............................................................................................................................................. 8

Auto-Negotiation ....................................................................................................................................... 8

Pause Control ........................................................................................................................................... 8

Link Pass-Through .................................................................................................................................... 8

Far-End Fault ............................................................................................................................................ 9

Optic and Cable Specifications ............................................................................................................... 10

Cable Specifications ............................................................................................................................... 10

Contact Us................................................................................................................................................... 15

Compliance Information .............................................................................................................................. 16

Declaration of Conformity ....................................................................................................................... 16

Record of Revisions .................................................................................................................................... 17

Introduction

Transition Networks E-100BTX-FX-05 Fast Ethernet media converters connect 100Base-TX shielded or

unshielded twisted-pair copper cable to 100Base-FX fiber-optic cable. The E-100BTX-FX-05 series media

converters include both Standard temperature models and Extended temperature models.

Standard Temperature Models: media converters that can be used in a standard temperature

environment from 0°C to 50°C (32°F to 122°F)

Extended Temperature Models: media converters with the “HT” extension in the part number can be

used in an extended temperature environment from -25°C to 65°C (-13°F to 149°F).
