190

FLOOR SCRUBBER DRIERS

STANDARD EQUIPMENT

RIDE ON WITH SWEEPING AND SCRUBBING SYSTEM

Equipped with:

• Comfort Duotech it is a 3 in 1 machine: it sweeps, washes, and dries

• Ultra compact dimensions and great handling like a walk behind scrubber dryer, ideal for maintenance cleaning

• Complete right/left side brush (1060 mm working width)

• Great battery autonomy (up to 4h) thanks to the very low consumption of washing solution and tanks large capacity

• Very precise detergent dosing system, proportional to the water supply, which determines a reduced

number of stops and maximum use of the battery charge for the effective operation of the machine

• Ergonomic steering wheel of new conception with very small turning radius (860mm) which allows it to

rotate practically on itself both to the right and to the left

• Self-leveling central brush that allows perfect work even on uneven surfaces

• Forced air flows keep the solution always within the washing track patended

• Sweeping, up to 1060mm, thanks to large diameter and intelligent side brushes (Active) which retract

automatically both in the event of an impact and when cornering to allow the perfect collection of all the material.

• Up to 30 L solid debris tank

• Double floor drying process that allows the rear wheels to travel without slipping on wet surfaces.

• Green feature: very low water consumption

• Seat hight kit available

Comfort Duotech 65 CSComfort Duotech 85 CS

code0.061.00610.061.0062

power supply

24V24V

cleaning width with right side brush880 mm880 mm

cleaning width with two side brushes1060 mm1060 mm

scrubbing width/squeegeewidth650/670 mm850/900 mm

turningradius860 mm860 mm

cleanwatertankcapacity90 l/23,77 gal90 l/23,77 gal

dirtywatertankcapacity100 l/26,41 gal100 l/26,41 gal

chemicaltankcapacity3 l/0,79 gal3 l/0,79 gal

solid wastecontainercapacity23 l/6,07 gal30 l/7,92 gal

main brush sizeØ300 x L 650 mmØ300 x L 850 mm

main brush speed900 RPM/min900 RPM/min

main brush pressureadjustable from the control paneladjustable from the control panel

dimensions/weight140x78x130 cm/350 kg140x105x130 cm/374 kg

Comfort Duotech

NEW

•

0.961.1187 Main brush

PPL/Tynex Duotech 65

•

0.961.1188 Main brush

PPL/Tynex Duotech 85

•

2 x 0.961.1189 PPL

side brush dx/sx

•

0.961.1191 Front

squeegee blade Duotech 65

•

0.961.1190 Rear

squeegee blade Duotech 65

•

0.961.1193 Front

squeegee blade Duotech 85

LINATEX®/AIROFLEX

0.961.1192 Rear squeegee

blade Duotech 85 LINATEX
