Seite 1/4
SF20191 — June 2018 — For latest specs visit www.legrand.us/radiant
• Overall 3.1A USB charging capability.
• AC receptacles available in 15A, 125V.
• Back and side wire termination options accommodate
#14 AWG – #10 AWG stranded and solid copper wire.
• Multiple color options available.
Power up mobile devices quickly,
reliably and without the need for
bulky AC adapters.
TM826USB
radiant
®
Tamper-Resistant Duplex Receptacles with USB
charging capabilities are designed to upgrade existing
receptacles for charging power. This device features an overall
3.1A USB charging capability in two USB charging ports coupled
with two AC receptacles, and as part of the radiant
®
collection,
now offers a better fit, form and finish. The external brass back-
wire pressure-plate and posted side-wire terminal screws make
installation fast and easy.
3rd Party Compliance
PASS & SEYMOUR
®
radiant
®
USB Chargers with Duplex
Tamper-Resistant Receptacles 15A, 125V
ETL and cULus Listed
Features & Benefits
Combination AC duplex receptacles
include two 5-volt DC USB ports
that work with USB 2.0 & 3.0
compatible devices.
AC receptacles are tamper-resistant to
meet NEC. Patented shutter system —
now with black “invisi-shutters” for
an invisible effect preferred by end
users — helps prevent improper
insertion of foreign objects.
TM826USBLA
SF20191 — June 2018 — For latest specs visit www.legrand.us/radiant
2
PASS & SEYMOUR
®
radiant
®
USB Chargers with Duplex
Tamper-Resistant Receptacles 15A, 125V
Warranty
1 Year
TM826USBLA
Performance
Electrical
Dielectric Withstand Voltage Withstands 1500V minimum
Maximum Working Voltage 125V
Current Interrupting Certified for current interrupting at full-rated current
(receptacle only)
Maximum Temperature Rise 30°C after 50 cycles at full-rated current after
50 cycles of overload are 150% of rated current
with direct current
Mechanical
Terminal Accommodation
Back and side wire termination options accommodate
#14 AWG - #10 AWG stranded and solid copper wire.
Product Identification Ratings are a permanent part of the device
Environmental
Flammability
UL94 V2 (for device cover) 5V (for device body
and frame)
Operating Temperature Maximum continuous +60°C, minimum -40°C
without impact
RoHS Compliant
Materials
Face Polycarbonate
Back Body Nylon
Line Contacts CDA 260 Brass
Mounting Strap .049" Zinc-Plated Steel
Terminal Screws
Tri-Drive Zinc-Plated Steel with Either Clear or Black
Chromate for Color Identification
Ground Screw Tri-Drive Steel with Green Chromate
Mounting Screws Tri-Drive Steel
Technical Information
4.18"
2.677"
1.35"
1.693"
SF20191 — June 2018 — For latest specs visit www.legrand.us/radiant
3
PASS & SEYMOUR
®
radiant
®
USB Chargers with Duplex
Tamper-Resistant Receptacles 15A, 125V
Ordering Information
NEMA
5-15R
USB Chargers with Duplex Tamper-Resistant Receptacles
Catalog Number
Rating
Color
Total Charging
Capacity
3rd Party Compliance
A V
UL498
UL1310
C22.2 No. 42
C22.2 No. 223
TM826USBI
15 125 Ivory • • •3.1 Amp
TM826USBW
15 125 White • • •3.1 Amp
TM826USBBK
15 125 Black • • •3.1 Amp
TM826USBLA
15 125 • • •Light Almond 3.1 Amp
TM826USBNICC6
15 125 Nickel • • •3.1 Amp
TM826USBGCCV4
15 125 Graphite • • •3.1 Amp
TM826USBDBCCV4
15 125 Dark Bronze 3.1 Amp
• • •
