Seite 1/8
Installer: Manual must remain
with owner/operator.
Record information:
Model:
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 1-800-543-2550
fax: 1-585-494-1839
www.LibertyPumps.com
Keep this manual handy for future reference.
For replacement manual, visit LibertyPumps.com,
or contact Liberty Pumps at 1-800-543-2550.
Retain dated sales receipt for warranty.
Serial:
Mfg Date:
Install Date:
60 Hz
Installation Manual
5488000B
Copyright © Liberty Pumps, Inc. 2024
All rights reserved.
Model 406 Drain Pump
Features
•Appliance-style design
•Compact size
•Bottom inlets accommodate shower plumbing
•Maximum fluid temp 140°F (60°C)
•Integral discharge check valve
•Integral side inlet check valve
•Discharge size options via single adapter
•Serviceable float switch and pump cartridge
Meets UPC
ASME A112.3.4
CSA B45.9
2 | EN Copyright © Liberty Pumps, Inc. 2024
All rights reserved. 5488000B
Contents
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 | EN
Model Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 | EN
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 | EN
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 | EN
Test System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 | EN
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 | EN
Maintenance and Troubleshooting . . . . . . . . . . . . . . . 6 | EN
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 | EN
Safety Guidelines
Safety Precautions
Accidental contact with electrically live parts, items, fluid, or
water can cause serious injury or death.
Always disconnect the pump from power source before
attempting to service the pump. Fatal electrical shock could
occur.
All installation and maintenance of pumps, controls,
protection devices, and general wiring shall be done by
qualified personnel.
The pump shall be plugged into a properly fused electrical
outlet with a ground fault circuit interrupter (GFCI) that
conforms to current National Electric Code (NEC) and all
applicable local codes. All wiring must be performed by
qualified personnel.
All electrical and safety practices shall be in accordance with
the National Electrical Code
®
, the Occupational Safety and
Health Administration, or applicable local codes and
ordinances.
Pump shall be properly grounded using its supplied
grounding conductor. Do not bypass grounding wires or
remove ground prong from attachment plugs. Failure to
properly ground the pump system can cause all metal
portions of the pump and its surroundings to become
energized.
Do not handle or unplug the pump with wet hands, when
standing on damp surface, or in water unless wearing
Personal Protective Equipment.
Always wear dielectric rubber boots and other applicable
Personal Protective Equipment (PPE) when water is on the
floor and an energized pump system must be serviced, as
submerged electrical connections can energize the water. Do
not enter the water if the water level is higher than the PPE
protection or if the PPE is not watertight.
Do not lift or carry the pump by its power cord. This will
damage the power cord, and could expose the electrically live
wires inside the power cord.
The electrical power supply shall be located within the length
limitations of the pump power cord, and for below grade
installations it shall be at least 4 ft (1.22 m) above floor level.
Do not use this product in applications where human contact
with the pumped fluid is common (such as swimming pools,
fountains, marine areas, etc.).
Protect the power and control cords from the environment.
Unprotected power and control (switch) cords can allow water
to wick through ends into pump or switch housings, causing
surroundings to become energized.
Do not use an extension cord to power the product. Extension
cords can overload both the product and extension cord
supply wires. Overloaded wires will get very hot and can catch
on fire.
This safety alert symbol is used in the manual
and on the pump to alert of potential risk for
serious injury or death.
This safety alert symbol identifies risk of
electric shock. It is accompanied with an
instruction intended to minimize potential
risk of electric shock.
This safety alert symbol identifies risk of fire.
It is accompanied with an instruction
intended to minimize potential risk of fire.
This safety alert symbol identifies risk of
serious injury or death. It is accompanied
with an instruction intended to minimize
potential risk of injury or death.
Warns of hazards which if not avoided will
result in serious injury or death.
Warns of hazards which if not avoided could
result in serious injury or death.
Warns of hazards which if not avoided could
result in minor or moderate injury.
Signals an important instruction related to
the pump. Failure to follow these instructions
could result in pump failure or property
damage.
Read every supplied manual before using
pump system. Follow all the safety
instructions in manual(s) and on the pump.
Failure to do so could result in serious injury
or death.
RISK OF ELECTRIC SHOCK
RISK OF FIRE
5488000B Copyright © Liberty Pumps, Inc. 2024
All rights reserved. 3 | EN
Do not use this product with or near flammable or explosive
fluids such as gasoline, fuel oil, kerosene, etc. If rotating
elements inside pump strike any foreign object, sparks may
occur. Sparks could ignite flammable liquids.
Ordinary location pumps are not to be installed in locations
classified as hazardous in accordance with the National
Electric Code
®
, ANSI/NFPA 70.
This product requires a separate, properly fused and
grounded branch circuit, sized for the voltage and amperage
requirements of the pump, as noted on the nameplate.
Overloaded branch circuit wires will get very hot and can
catch on fire. When used, electrical outlets shall be simplex of
the appropriate rating.
Applicable to Models 406-120_60-CM, 406-230_60-CM, and
406-230_50-CM with Molex® connection or equivalent:
connect the high-level alarm connection to an NEC, CEC Class
2 circuit or SELV circuit with available output power not
exceeding 10 watts.
Do not modify the pump/pump system in any way.
Modifications may affect seals, change the electrical loading
of the pump, or damage the pump and its components. If the
supply cord is damaged, it shall be replaced by Liberty Pumps
or its authorized service centers to ensure the safety of the
product.
All pump/pump system installations shall be in compliance
with all applicable Federal, State, and Local codes and
ordinances.
Do not allow children to play with the pump system.
Do not allow any person who is unqualified to have contact
with this pump system. Any person who is unaware of the
dangers of this pump system, has not read this manual or has
not have been given supervision or instruction concerning
use of the product by a person responsible for their safety can
easily be injured by the pump system.
Do not remove any tags or labels from the pump or its cord.
Keep clear of suction and discharge openings. To prevent
injury, never insert fingers into pump while it is connected to
a power source.
Do not use this ordinary location product with flammable,
explosive, or corrosive uids. Do not use in a flammable and/
or explosive atmosphere as serious injury or death could
result.
This product contains chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm. www.p65warnings.ca.gov.
Applicable to Model 406-230_50-CM with Molex connection
or equivalent: a means for disconnection shall be
incorporated in the fixed wiring in accordance with all
applicable Federal, State, and Local codes and ordinances
regarding wiring rules.
This pump has been evaluated for use with water only.
Do not use pumps with uid over 140°F (60°C). Operating the
pump in fluid above this temperature can overheat the pump,
resulting in pump failure.
Do not dispose of materials such as paint thinner or other
chemicals down drains. Doing so could chemically attack and
damage pump system components and cause product
malfunction or failure.
Do not use pump system with mud, sand, cement,
hydrocarbons, grease, or chemicals. Pump and system
components can be damaged from these items causing
product malfunction or failure. Additionally, flooding can
occur if these items jam the impeller or piping.
Do not use an air admittance valve or a mechanical
spring-loaded venting device, as these devices are one-way
valves. The air pressure in and outside the pump unit must be
equal and a “cheater” vent will obstruct the airflow in one
direction and prevent proper function.
Do not run dry.
Use of a lint trap on a washing machine drain is
recommended for proper check valve performance.
Model Specifications
For complete listing of models and their specifications, refer to
https://www.LibertyPumps.com/About/Engineering-Specs.
Product nameplate provides a record of specific information.
General Information
The sleek Model 406 is an appliance grade product with a refined
look and feel. This unit can handle an indirect connection (via a
laundry sink) to a washing machine, indirect connection (through a
drain trap) to a dishwasher, and a direct connection to a number of
other fixtures including sinks and showers. There are (3) inlet
locations with provisions for 2 inlets included; a kit is available for
third connection, (1) vent, and (1) stepped discharge adapter with
integral check valve that can adapt to 1”, 1.25”, and 1.5” pipe sizes.
Additionally, the 406 features an integral float switch/wiring
harness assembly, a pump power “cartridge” that can be easily
removed for servicing, and a bottom/side inlet adapter with a
preinstalled check valve.
Features
•Ability to remove both the float switch and pump “cartridge”
through the access area, without removing the main chassis
•Three discharge options [1”, 1.25”, 1.5”] accomplished with a
single stepped discharge adapter
•Integral side inlet check valve adapter can be used on either
side of tank
RISK OF SERIOUS INJURY OR DEATH
