MMX6x2-HT200

MMX6x2-HT210

MMX6x2-HT220

User’s Manual

Multimedia Matrix Switcher

MMX6x2-HT series – User's Manual 2

Important Safety Instructions

Class I Apparatus Construction.

This equipment must be used with a mains power system with a

protective earth connection. The third (earth) pin is a safety feature,

do not bypass or disable it. The equipment should be operated only

from the power source indicated on the product.

To disconnect the equipment safely from power, remove the power

cord from the rear of the equipment, or from the power source. The

MAINS plug is used as the disconnect device, the disconnect device

shall remain readily operable.

There are no user-serviceable parts inside of the unit. Removal of the

cover will expose dangerous voltages. To avoid personal injury, do not

remove the cover. Do not operate the unit without the cover installed.

The appliance must be safely connected to multimedia systems.

Follow instructions described in this manual.

Replacing the AC fuse

Unplug the AC power cord from the device. Locate the AC fuse on the

rear panel. Replace only the AC fuse as indicated on the rear panel.

Connect the power cord to the switcher and to the AC power source.

Make sure the switcher is working properly.

Ventilation

For the correct ventilation and to avoid overheating ensure enough

free space around the appliance. Do not cover the appliance, let the

ventilation holes free and never block or bypass the ventilators (if any).

WARNING

To prevent injury, the apparatus is recommended to securely attach to

the oor/wall or mount in accordance with the installation instructions.

The apparatus shall not be exposed to dripping or splashing and that

no objects lled with liquids, such as vases, shall be placed on the

apparatus. No naked ame sources, such as lighted candles, should

be placed on the apparatus.

CAUTION AVIS

RISK OF ELECTRIC SHOCK

DO NOT OPEN

RISQUE DE CHOC ELECTRIQUE

NE PAS OUVRIR



Waste Electrical & Electronic Equipment

WEEE

This marking shown on the product or its literature,

indicates that it should not be disposed with other

household wastes at the end of its working life. To

prevent possible harm to the environment or human

health from uncontrolled waste disposal, please

separate this from other types of wastes and recycle it

responsibly to promote the sustainable reuse of material

resources. Household users should contact either the

retailer where they purchased this product, or their local government

ofce, for details of where and how they can take this item for

environmentally safe recycling. Business users should contact their

supplier and check the terms and conditions of the purchase contract.

This product should not be mixed with other commercial wastes for

disposal.

Common Safety Symbols

Symbol Description

Alternating current

Protective conductor terminal

On (Power)

Off (Power)



Caution, possibility of eletric shock

Caution









Produktspezifikationen

Marke:	Lightware
Kategorie:	Schalter
Modell:	MMX6x2-HT220
Display-Typ:	LCD
Upgradefähige Firmware:	Ja
Breite:	482 mm
Tiefe:	300 mm
Gewicht:	4800 g
Mitgelieferte Kabel:	AC, LAN (RJ-45)
Produkttyp:	AV-Matrix-Umschalter
Produktfarbe:	Schwarz
Steuerung:	Tasten
Höhe:	43.9 mm
Material:	Metall
AC Eingangsspannung:	100 - 240 V
AC Eingangsfrequenz:	50 - 60 Hz
Eingebautes Display:	Ja
Betriebstemperatur:	0 - 50 °C
Relative Luftfeuchtigkeit in Betrieb:	10 - 90 %
Schnellstartübersicht:	Ja
Zertifizierung:	CE
Stromverbrauch (Standardbetrieb):	40 W
Anzahl Ethernet-LAN-Anschlüsse (RJ-45):	2
Stromverbrauch (max.):	120 W
Menge pro Packung:	1 Stück(e)
Gehäusematerial:	Metall
HD-Typ:	4K Ultra HD
Anzahl HDMI-Anschlüsse:	6
Ethernet LAN Datentransferraten:	10, 100 Mbit/s
Temperaturbereich bei Lagerung:	-40 - 70 °C
Audio Kanäle:	7.1 Kanäle
HDCP:	Ja
Unterstützte Grafik-Auflösungen:	1024 x 768 (XGA),1280 x 720 (HD 720),1600 x 1200 (UXGA),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),3840 x 2160,4096 x 2160
3D:	Ja
Rack-Einbau:	Ja
USB-Stecker:	Mini-USB B
Anzahl der USB-Anschlüsse:	1
Maximale Auflösung:	3840 x 2160 Pixel
HDMI-Version:	1.4
Ethernet Schnittstellen Typ:	Schnelles Ethernet
Textzeilen:	2 Zeilen
Gehäusefarbe:	Schwarz
Nachhaltigkeitszertifikate:	RoHS
Anzahl der HDMI-Ausgänge:	2
Wärmeableitung:	120 BTU/h
Maximaler Arbeitsabstand:	170 m
HDMI-In:	4
Unterstütze 3D-Formate:	Frame packing, Side by side, Top and bottom
HDCP-Version:	1.4
Video Porttyp:	HDMI
Anzahl HDMI-Ausgangsschnittstellen:	2
Rack-Kapazität:	1U
Anzahl HDMI-Eingangsschnittstellen:	4
RJ-45-Eingangsanschlüsse:	2
USB-Port-Typ:	Mini USB Type-B
RJ-45-Ausgangsanschlüsse:	2
Erweiterte Display-Identifikationsdaten (EDID):	Ja
Displaynummern der Buchstaben:	16
Bidirektional:	Ja
Keine Videokompression:	Ja
EDID-Management:	Ja
Keine Signalverzögerung:	Ja
Anschlüsse für analoge Audioeingänge:	4
Anschlüsse für analoge Audioausgänge:	2
