3 GB/IE

Introduction / Safety advice

Collector’s Display Cabinet



Introduction

Before assembling and using the product for the first time, take time

to familiarise yourself with the product first. Read the following as-

sembly instructions and safety instructions carefully. Only use the

product as described and for the designated areas of application. Please keep

these instructions in a safe place. If you hand this product on to a third party,

you must also pass on all documents relating to the product.



Proper Use

This article is intended for storing and displaying small, lightweight objects. The

product is intended for private indoor use only. Any use other than previously

mentioned or any product modification is prohibited and can lead to injuries

and / or product damage. The manufacturer is not liable for any damages

caused by any use other than for the intended purpose. The product is not

intended for commercial use.



Description of Parts

1

Top panel

2

Bottom panel

3

Side frames

4

Back panel

5

Glass panels (sides)

6

Glass shelves

7

Doors

8

Dowels (approx. ø 5.8 x 30 mm)

9

L-shaped metal plate

10

Screws (approx. ø 3.5 x 14 mm)

11

Magnetic door stopper

12

Glass support dowels (including 2 x spares)

13

Metal pins

14

Screws (approx. ø 4 x 27 mm)

15

Hinge caps

16

Screws (approx. ø 3 x 10 mm)

17

Door hinges

18

$2//ů9/

19

$2//l screws (approx. ø 79x 50 mm)

20

Plastic caps

21

Feet

22

Dowels (approx. ø 8 mm)

23

Wall-mount-screws (approx. ø 4.5 x 60 mm)

24

Lock

25

Metal plate

26

Plastic rings

27

Screws (approx. ø 3.5 x 20 mm)

28

Nuts

29

Door handle

30

Metal stirrups

31

Bump cushion for metal stirrup

32

Bump cushion for door handle

33

Key

34

Lock with keyhole

35

Connection plate

36

Striker plate

37

Plain washer

38

Screw (approx. ø 3.5 x 7 mm)

39

Plastic caps for wall-mount screws



Supply Scope

Note: Take care when unpacking that you do not inadvertently throw away

any assembly material.

Immediately after unpacking, check that the delivery is complete and that the

product and all its parts are in perfect condition. Do not under any circum-

stances assemble the product if the delivery is incomplete.

1 x Top panel

1 x Bottom panel

2 x Side frames

1 x Back panel

2 x Glass panels (sides)

10 x Glass shelves

2 x Doors

10 x Dowels (approx. ø 5.8 x 30 mm)

1 x L-shaped metal plate

4 x Screws (approx. ø 3.5 x 14 mm)

1 x Magnetic door stopper

42 x Glass support dowels (including 2 x spares)

2 x Metal pins

4 x Screws (approx. ø 4 x 27 mm)

6 x Hinge caps

12 x Screws (approx. ø 3 x 10 mm)

6 x Door hinges

1 x $2//ů9/

12 x $2//l screws (approx. ø 79x 50 mm)

6 x Plastic caps

4 x Feet

4 x Dowels (approx. ø 8 mm)

4 x Wall-mount-screws (approx. ø 4.5 x 60 mm)

1 x Lock

1 x Metal plate

2 x Plastic rings

18 x Screws (approx. ø 3.5 x 20 mm)

2 x Nuts

1 x Door handle

2 x Metal stirrups

2 x Bump cushion for metal stirrup

1 x Bump cushion for door handle

2 x Key

1 x Lock with keyhole

1 x Connection plate

1 x Striker plate

1 x Plain washer

1 x Screw (approx. ø 3.5 x 7 mm)

4 x Plastic caps for wall-mount screws

1 x Assembly and installation instructions



Technical data

Dimensions (without feet): approx. 68 x 110 x 20 cm (W x H x D)

Max. load: 1 kg per shelf

Safety advice

KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A SAFE PLACE

FOR FUTURE REFERENCE!



WARNING!

RISK OF LOSS OF LIFE OR ACCIDENT

TO INFANTS AND CHILDREN! Never leave children un-

supervised with the packaging materials. Danger of suffocation.

 CAUTION! RISK OF INJURY! Make sure that all parts are undamaged

and assembled correctly. Improper assembly carries a risk of injury.

Damaged parts may affect the safety and function of the product.

 Make sure that this product is standing on a solid, level surface.

 Wall mounting is necessary otherwise the product may tip over.
