4K Motorized Varifocal Bullet Camera

with Smart Motion Detection

Important Installation Guidelines

Additional Installation Tips:

• Point the camera where there is the least amount of obstructions (e.g., tree branches).

• Install the camera where vandals cannot easily reach.

• Secure cabling so that it is not exposed or easily cut.

• This camera is rated for outdoor use. Installation in a sheltered location is

recommended.

• Smart motion detection is enabled by default. When enabled, the camera's recording

frame rate is 20 frames per second.

• To obtain the maximum 30 frames per second, smart motion detection must be

disabled.

Optimizing Person and Vehicle Detection Accuracy:

• Angle the camera so that objects of interest appear in the bottom ⅔ of the camera

image.

• Choose a location where objects of interest will be no further than 50ft (~15m) from

the camera.

Optimal accuracy for objects

within 50ft (~15m) and in the

bottom ⅔ of the image.

Lower accuracy for objects

further away than 50ft (~15m)

and/or in the top ⅓ of the image.

• Angle the camera between 30~60° down from the

level position.

• Install the camera between 8-16ft (2.5-5m) off of

the ground.

Level position (i.e., ceiling)

Optimal

angle

range

NOTE: Accuracy of person and vehicle detection will

be inuenced by multiple factors, such as the object’s

distance from the camera, the size of the object, and

the height and angle of the camera. Night vision will

also impact the accuracy of detection.

LNB9292_QSG_EN_R3

• For a full list of compatible recorders, visit lorex.com/compatibility.

• Not intended for submersion in water. Installation in a sheltered location

recommended.

• This camera includes an Auto Mechanical IR Cut Filter. When the camera changes

between Day/Night viewing modes, an audible clicking noise may be heard from the

camera. This clicking is normal, and indicates that the camera lter is working.

• For optimal remote viewing from your recorder, an upload speed of 256kbps per

camera is required (default setting). For example, your Internet service package

must support 2Mbps or greater upload speed for 8 cameras, 4Mbps or greater for 16

cameras, and 8Mbps or greater for 32 cameras (your Internet service provider can

conrm your upload speed). You may lower the resolution and bitrate of camera video

streams to further boost performance for slower Internet connections. See your NVR's

user manual at lorex.com for full instructions (see "Conguring Recording Quality"

section).

Disclaimers

Dimensions

9.5”/242mm

3.6”/91mm

• 4K Motorized Varifocal Bullet Camera with Smart Motion Detection

• Mounting Kit*

• Mounting Template*

• Ethernet Extension Cable with Pre-attached RJ45 Cable Gland*

• Allen Key*

* Per camera in multi-camera packs.

Package Contents

ATTENTION:

It is recommended to connect the camera to the NVR or an external PoE

switch. If using a DC power adapter (not included) with the camera, a

REGULATED power supply is REQUIRED for use with this camera. Use of a

non-regulated, non-conforming power supply can damage this product and

voids the warranty.

• Use the camera only with compatible Lorex NVRs.

• Read this guide carefully and keep it for future reference.

• Follow all instructions for safe use of the product and handle with care.

• Use the camera within given temperature, humidity and voltage levels

noted in the camera’s specications.

• Do not disassemble the camera.

• Do not point the camera directly towards the sun or a source of

intense light.

• Use only a regulated power supply with the product (optional). Use of a

non-regulated, non-conforming power supply can damage the product

and void the warranty.

• Periodic cleaning may be required. Use a damp cloth only. Do not use any

harsh, chemical-based cleaners.

• The supplied cable is rated for surface mounting only. Cables for in-wall

and oor-to-oor installations are sold separately (CMR type). These and

other cables are available at lorex.com.

Safety Precautions

lorex.com

Ethernet

Extension

Cable

RJ45 Cable Gland

Using the RJ45 Cable Gland(Optional)

The RJ45 cable gland is pre-attached to the

included Ethernet extension cable.

The RJ45 cable gland covers the camera’s Ethernet connector and the RJ45 plug to

provide weather-resistance and protection from dust, dirt and other environmental

contaminants.

To use the RJ45 cable gland:

RJ45 Cable Gland BarrelCamera Ethernet Connector

NOTE: The RJ45 cable gland is weather-resistant. Seal the cap with silicone and/or

electrical tape for additional sealing if it will be exposed to precipitation regularly.

Twist the RJ45 cable gland barrel securely onto the camera Ethernet connector.

Need Help?

Visit us online for up-to-date software

and complete instruction manuals

Click on the Downloads tab

4

Visit lorex.com

Search for the model

number of your product

Click on your product

in the search results

3

2

1

Copyright © 2023 Lorex Corporation

As our products are subject to continuous improvement, Lorex reserves the right to

modify product design, specications and prices, without notice and without incurring

any obligation. E&OE. All rights reserved.

Nocturnal Series

Lorex N10

LNB9292

Quick Start Guide
