Installation & operating instructions
MXL017/50/65/85 Target (all models)
UK contact:
Helpline: +44 (0)1553 811000
Email: support@maxview.co.uk
Web: www.maxview.co.uk
Maxview reserve the right to change specifications without prior notice
9111330 Iss 6G
Visit: www.maxview.co.uk - Search ‘Target’ for potential software updates
Contents:
Introduction 2
Proper use & operation 2
Safety precautions 3
Application example 4
Connections & features 5
Product contents 5
Required tools and equipment 5
Selecting an installation location 6
Positioning Control Box 6
Attaching Antenna Mount Plate 7
and LNB Park Plate
Electrical installation 8
Attaching Antenna Unit to 9
Mount Plate
Installing cables 9
Installing Cable Entry Plate 10
Installing Control Box 10
Introduction:
Please read these instructions fully before using the antenna for the first time. The operation of the antenna has
been designed to be as simple as possible however should you require any technical assistance please contact
Maxview customer service on +44 (0)1553 811000 or visit www.maxview.co.uk.
Proper use & operation:
The Target is designed to be installed in a motorhome, caravan or horsebox to automatically locate a television
broadcast satellite when the vehicle is stationary. The system comprises of 2 main components.
1. The Antenna which is to be permanently mounted externally to the roof structure of a motorhome/caravan
horsebox. The construction of the roof structure should be suitably robust and have no protruding obstacles
2. The Control Box is designed to be mounted internally in a cupboard. This controls the antenna unit through a
cable connection and is powered by 12v DC only.
Use of the equipment for any other purpose than the one specified is not permitted and will invalidate the
warranty.
All instructions and models are subject to change. In accordance with policy of progressive product, the company
reserve the right to alter specifications.
Copyright© these instructions are the sole property of Maxview Ltd and may not be reproduced.
Please keep these instructions safe for future reference.
Recycle packaging where facilities exist.
Page 2
Connection diagram 11
Attaching Satellite Dish to Unit 11
Finding a satellite 12
Reference 12
Interface details 13
How to operate your system 13
Ignition mode 14
Connecting to a Satellite Receiver 14
Power consumption 14
Software update 15
Fault finding 16
Error modes 16-17
Skew adjustment 18
Guarantee 19
Environmental 19
Specifications 20
