W11532445D
PLASTIC TUB DISHWASHER OWNER'S MANUAL
GUIDE DāUTILISATION DU LAVE-VAISSELLE AVEC
CUVE EN PLASTIQUE
Table of Contents/Table des matiĆØres
DISHWASHER SAFETY .................................................... 2
Dishwasher Safety ......................................................... 2
DISHWASHER MAINTENANCE AND CARE ......................... 4
User-Maintenance Instructions ......................................... 4
INSTALLATION REQUIREMENTS....................................... 5
Tools and Parts ............................................................. 5
Location Requirements ................................................... 7
Cabinet Opening Dimensions ........................................... 7
Drain Requirements ....................................................... 7
Water Supply Requirements............................................. 8
Electrical Requirements ..................................................8
INSTALLATION INSTRUCTIONS ........................................8
Before You Begin ........................................................... 9
Prepare Cabinet Opening ā New Utilities.............................9
Install Optional Moisture Barrier (Recommended for Wood
Countertops)................................................................. 9
Electrical Connection .................................................... 10
Prepare Dishwasher ..................................................... 10
Remove Access Panel .................................................. 11
Connect Water Line to Fill Valve ...................................... 12
Connect Fill Hose to Fill Valve......................................... 13
Drain Hose Connection ................................................. 13
Power Cord Connection ................................................ 13
Install Door Handle (on some models) .............................. 15
Place Dishwasher in Cabinet .......................................... 16
Choose Anchor Attachment Method................................. 17
Final Installation Check ................................................. 17
Secure Dishwasher in Cabinet Opening ............................ 19
Direct Wire Connection ................................................. 19
Connect Water Line to House Shutoff Valve....................... 21
Connect Drain Hose ..................................................... 21
Complete Installation .................................................... 23
Install Access Panel ..................................................... 24
Check Operation ...................................................... ............... 24
If Dishwasher Does Not Operate ..................................... 25
Additional Tips............................................................. 25
SĆCURITĆ DU LAVE-VAISSELLE..................................... 26
SƩcuritƩ du lave-vaisselle .............................................. 26
ENTRETIEN ET RĆPARATION DU LAVE-VAISSELLE .......... 28
Instructions dāentretien pour lāutilisateur ............................ 28
EXIGENCES DāINSTALLATION ........................................ 29
Outils et piĆØces............................................................ 29
Exigences dāemplacement ............................................. 31
Dimensions de lāouverture de lāarmoire ............................. 32
Exigences dāĆ©vacuation................................................. 32
SpĆ©cifications de lāalimentation en eau ............................. 32
SpƩcifications Ʃlectriques .............................................. 32
INSTRUCTIONS DāINSTALLATION ................................... 33
Avant de commencer .................................................... 33
PrĆ©paration de lāemplacement ā nouvelles unitĆ©s................ 34
Installer la barriĆØre anti-humiditĆ© en option (recommandĆ©e
pour les comptoirs en bois) ............................................ 34
Raccordement Ć©lectrique............................................... 35
PrƩparation du lave-vaisselle.......................................... 35
Retrait du panneau dāaccĆØs............................................ 36
Branchement de lāarrivĆ©e dāeau Ć la valve de distribution ...... 37
Branchement du tuyau de distribution Ć la valve de
distribution .. ............................................................... 38
Raccord du tuyau de vidange ......................................... 38
Branchement du cĆ¢ble Ć©lectrique .................................... 39
Installer la poignĆ©e de porte (sur certains modĆØles) ............. 40
Placer le lave-vaisselle dans lāarmoire .............................. 41
Choix de lāoption de fixation............................................ 42
VĆ©rification finale de lāinstallation ..................................... 42
Fixation du lave-vaisselle dans lāouverture dāencastrement
de lāarmoire ................................................................ 44
MĆ©thode de raccordement direct ..................................... 44
Branchement de lāarrivĆ©e dāeau au robinet dāarrĆŖt de la
maison ...................................................................... 46
Raccordement du tuyau de vidange ................................. 46
Fin de lāinstallation ....................................................... 48
Installation du panneau dāaccĆØs ...................................... 49
VĆ©rification du fonctionnement ................................. .............. 49
Si le lave-vaisselle ne fonctionne pas ............................... 50
Conseils supplƩmentaires.............................................. 50
2
DISHWASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word āDANGERā or āWARNING.ā These
words mean:
DANGER You can be killed or seriously injured if you don't
immediately follow instructions.
WARNING You can be killed or seriously injured if you donāt follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using your dishwasher, follow basic precautions, including the following:
ļæ½Read all instructions before using the dishwasher.
ļæ½Use the dishwasher only for its intended function.
ļæ½Use only detergents or wetting agents recommended for
use in a dishwasher and keep them out the reach of
children.
ļæ½When loading items to be washed:
1. Locate sharp items so that they are not likely to damage
the door seal; and
2. Load sharp knives with the handles up to reduce the
risk of cut-type injuries.
ļæ½Do not wash plastic items unless they are marked
"dishwasher safe" or the equivalent. For plastic items not so
marked, check the manufacturer's recommendations.
ļæ½Do not touch the heating element during or immediately
after use.
ļæ½Do not operate your dishwasher unless all enclosure
panels are properly in place.
ļæ½Do not tamper with controls.
ļæ½Do not abuse, sit on, or stand on the door or dish racks of
the dishwasher.
ļæ½To reduce the risk of injury, do not allow children to play in
or on a dishwasher.
ļæ½Under certain conditions, hydrogen gas may be produced
in a hot-water system that has not been used for two weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-
water system has not been used for such a period, before
using the dishwasher, turn on all hot-water faucets and let
the water flow from each for several minutes. This will
release any accumulated hydrogen gas. As the gas is
flammable, do not smoke or use an open flame during this
time.
ļæ½Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
ļæ½Do not use replacement parts that have not been
recommended by the manufacturer (e.g. parts made at
home using a 3D printer).
SAVE THESE INSTRUCTIONS
3
GROUNDING INSTRUCTIONS
ļæ½For a grounded, cord-connected dishwasher:
The dishwasher must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance for
electric current. The dishwasher is equipped with a cord
having an equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with all local
codes and ordinance.
WARNING: Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualified electrician or service representative if
you are in doubt whether the dishwasher is properly grounded.
Do not modify the plug provided with the dishwasher; if it will not
fit the outlet, have a proper outlet installed by a qualified
electrician.
ļæ½For a permanently connected dishwasher:
The dishwasher must be connected to a grounded metal,
permanent wiring system, or an equipment-grounding
conductor must be run with the circuit conductors and
connected to the equipment-grounding terminal or lead on
the dishwasher.
SAVE THESE INSTRUCTIONS
WARNING
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
