Seite 1/5

6W AC-DC Reliable Industrial Adaptor

G S 0 6 E s e r i e s

■Model Encoding

File Name:GS06E-SPEC 2020-09-01

■Model Encoding

EN62368-1

P1J06

Series name

Rated wattage

EURO 2 pin AC plug

Output voltage

DC plug type

C+ tuning fork type

P1J: Plug for standard model, 2.1 5 5 11mm,ψ× ψ×.

Other options available by customer requested (see Page 4~5)

{

■ ■Features Applications

■Description

•

Universal AC inpu ranget / Full

•2 pole EURO plug, Class power Ⅱunit

•No load power consumption<0.075W

•Energy efficiency Level Ⅵ

•Comply with EU ErP and meet CoC Version 5

•Protections: Short circui verloa voltaget / O d / Over

•Fully enclosed plastic case

•Pass LPS

•Various DC plug quick adapter accessory available

(Plug kit sold sperately

,please refer to : )

•2 years warranty

•Consumer electronic devices

•Telecommunication devices

•Office facilities

•Industrial equipments

GS06E is a highly reliable, 6W wall-mounted style single-output green adaptor series. This product is

a class power unit (no FG), equipped with a 2-Pin standard European AC power plug, adopting the Ⅱ

input range from 90VAC to 264VAC. The entire series supplies different models with output voltages ranging

between 5VDC and 48VDC that can satisfy the demands for various types of consumer electronic devices.

With the efficiency up to 83% and the extremely low no-load power consumption below 0.075W, GS06E is

compliant with EU ErP, and meet Code of Conduct(CoC) Version 5

. The supreme feature allows the adaptor

to save the energy when it is either under the operating mode or the standby mode. The entire series utilizes

the 94V-0 flame retardant plastic case, providing the double insulation that effectively prevents electrical

shock.GS06E is certified for the international safety regulations.

TPTC004

https://www.meanwell.com/upload/pdf/DC_plug.pdf

Über die gesetzliche Gewährleistung hinausgehende Garantieangaben sind Herstellergarantien.

SPECIFICATION

ORDER NO.

SAFETY MODEL NO.

DC VOLTAGE Note.2

RATED CURRENT

CURRENT RANGE

RATED POWER

RIPPLE & NOISE (max.) Note.3

OUTPUT

SETUP, RISE, HOLD UP TIME

VOLTAGE RANGE

FREQUENCY RANGE

EFFICIENCY (Typ.)

AC CURRENT

INPUT

ENVIRONMENT

INRUSH CURRENT (max.)

LEAKAGE CURRENT(max.)

SAFETY STANDARDS

WORKING TEMP.

WORKING HUMIDITY

STORAGE TEMP., HUMIDITY

TEMP. COEFFICIENT

VIBRATION

MTBF

DIMENSIONOTHERS

NOTE

PACKING

PROTECTION

5V 7.5V 9V 12V 15V 18V 24V 48V

GS06E-1

GS06E-1-1

GS06E-2 GS06E-3 GS06E-4 GS06E-5 GS06E-6 GS06E-8

1.00A 0.8A 0.66A 0.5A 0.4A 0.33A 0.25A 0.125A

0 ~ 1.00A 0 ~ 0.8A 0 ~ 0.66A 0 ~ 0.5A 0 ~ 0.4A 0 ~ 0.33A 0 ~ 0.25A 0 ~ 0.125A

5W 6W 6W 6W 6W 6W 6W 6W

50mVp-p 80mVp-p 80mVp-p 100mVp-p 120mVp-p 150mVp-p 180mVp-p 200mVp-p

VOLTAGE TOLERANCE Note.4

LINE REGULATION Note.5

LOAD REGULATION Note.6

±5.0%

±±±±±±±±0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5% 0.5%

±5.0%

1500ms, 50ms, 5ms at full load

90 ~ 264VAC 127 ~ 370VDC

47 ~ 63Hz

68% 80% 75% 77% 79.5% 81% 81% 83%

0.2A / 100VAC

Cold start 30A/ 115VAC 50A / 230VAC

0.25mA / 240VAC

TUV EN62368-1, EAC TP TC 004 approved

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

I/P-O/P:4242VDC

I/P-O/P:100M Ohms / 500VDC / 25 / 70% RH℃

500Khrs min. MIL-HDBK-217F(25 )℃

0 ~ +50 (Refer to "Derating Curve")℃

20% ~ 90% RH non-condensing

-20 ~ +85 , 10 ~ 95% RH non-condensing℃

± ℃ ℃0.03% / (0 ~ 40 )

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

32*66*42.5mm (L*W*H)

100g ; 90pcs / 10Kg / CARTON

CONNECTOR

PLUG

CABLE

See page 4~5 ; Other type available by customer requested

 ℃



  μ μ













OVERLOAD

OVER VOLTAGE

Protection type : Hiccup mode, recovers automatically after fault condition is removed

>120% rated output voltage

>105% rated output power for 5V ; >110% rated output power for 7.5 ~ 48V

Protection type : Clamp by zener diode

GS06E-1P1J GS06E-11P1J GS06E-2P1J GS06E-3P1J GS06E-4P1J GS06E-5P1J GS06E-6P1J GS06E-8P1J

SAFETY &

EMC

(Note. 7)

EMC IMMUNITY

EMC EMISSION

Parameter

Standard

EN55032(CISPR32)

EN61000-3-2

Test Level / Note

Class B

-------

EN61000-3-3

Class B

Class A

Parameter

ESD

Standard

EN61000-4-2

Test Level /Note

EN61000-4-3

EN61000-4-4

EN61000-4-6

EN61000-4-5

EN61000-4-8

EN61000-4-11

EN55032(CISPR32)

＞ .95% dip 0 5 periods, 30% dip 25 periods,

＞95% interruptions 250 periods

Conducted emission

Radiated emission

Harmonic current

Voltage flicker

EFT bursts

Surge susceptibility

Level 3, 8KV air; Level 2, 4KV contact

Conducted susceptibility

Level 2, 3V/m

Level 3, 1KV/L-N

Level 1, 1A/m

Level 2, 3V

Level 2, 1KV

RF field susceptibility

Magnetic field immunity

Voltage dips , interruption

6W AC-DC Reliable Industrial Adaptor

GS06E series

Fil e Name: GS0 6E-SPEC 202 0-09-01

Über die gesetzliche Gewährleistung hinausgehende Garantieangaben sind Herstellergarantien.

Derating Curve Static Characteristics

Mechanical Specification

Unit:mm

0 10 20 30 5040

100

AMBIENT TEMPERATURE ( )℃

INPUT VOLTAGE (VAC) 60Hz

90 10095 120110 160140 200180 240220 264

100

LOAD (%)

13.6

4ψ

18.3

19.8

34.5 1±

Name Plate

UL2468 20AWG 1200/-0mm for 5~9V

UL2468 24AWG 1800/-0mm for 12~48V

19 0.5±

66 1±

32 1±

42.5 1±

62.5 1±

6W AC-DC Reliable Industrial Adaptor

GS06E series

2 pole EURO plug

Fil e Name:GS0 6E-SPEC 202 0-0 9-01

Über die gesetzliche Gewährleistung hinausgehende Garantieangaben sind Herstellergarantien.
