Installation Manual

Type：

：

：

：：Enclosed Type Switching Power Supply

(Families: G3, NE, LRS, SE, PFC, HSP, SPV, USP, RST, G5, MSP)

Introduction

Enclosed type switching power supplies possess a metal or plastic case for covering their internal PCB and will be

installed inside the case of the end system. Mean Well’s enclosed type power supplies include 2 different groups of

power supplies, with built-in fan and without built-in fan, depending on their rated power or design concept.

Installation

（）1Before any installation or maintenance work, please disconnect your system from the utility.

Ensure that it can’t be re-connected inadvertently!

（）2Keep enough insulation distance between mounting screws and internal components of power supplies. Please

refer to case drawing on specifications to receive the maximum length of mounting screw.

（）3Mounting orientations other than standard orientation or operate under high ambient temperature may

increase the internal component temperature and will require a de-rating in output current. Please refer to

the specification sheets to receive the optimum mounting position and information about the de-rating curve.

（）4Fans and ventilation holes must be kept free from any obstructions. Also a 10-15 cm clearance must be kept

when the adjacent device is a heat source.

（）5Input and Output terminal

Terminal Screw

Series

Screw Size

Suggested

Torque

RSP-750 / 1000 / 1500 / 2000 / 2400 / 3000

SE-450 / 1000 / 1500

HEP-600MSP-300 ，HRP-300，HRPG-300，

SP-480，SP-750，SPV-1500，USP-500，RST-10000

M4 10-12kgf-cm

HRP-075 / 100 / 150 / 200，HRPG-150 / 200

LRS-035 / 050 / 075 / 100 / 150 / 150F / 200 / 350

MSP-100 / 200

NED-035 / 050 / 075 / 100，NET-035 / 050 / 075

NES-025 / 035 / 050 / 075 / 100 / 150 / 200 / 350

QP-200 / 320 / 375

RD-050 / 065 / 085 / 125，RID-050 / 065 / 085 / 125

RS-035 / 050 / 075 / 100 / 150

RSP-075 / 100 / 150 / 200 / 320

SP-075 / 100 / 150 / 200 / 240 / 320，SPV-150/300

SE-100 / 200 / 350，HSP-250，PSP-600

M3.5 8-10 kgf-cm

RSP-1600

RD-035，RT-050 / 065 / 085 / 125

RQ-050 / 065 / 085 / 125

TP-075 / 100 / 150，QP-100 / 150

RS-015 / 025

NES-015，USP-150

M3 6-8 kgf-cm

ERP-350

HDP-190 / 240

NEL-200 / 300

#6 8-10 kgf-cm
