Timer dimming function, contact MEAN WELL for details(safety pending).
LED street lighting
LED high-bay lighting
Parking space lighting
LED fishing lamp
LED greenhouse lighting
Type HL for use in Class, Division 2 Ⅰ
hazardous (Classified) location.
320W Constant Voltage + Constant Current LED Driver
HLG-320Hseries
■Model Encoding
Function options
Rated output voltage (12V/15V/20V/24V/30V/36V/42V/48V/54V)
Rated wattage
Series name
■Description
HLG-320H series is a 185W AC/DC LED driver featuring the dual mode constant voltage and constant
current output. HLG-185H operates from 90305VAC and offers models with different rated voltage ranging～
between 12V and 54V. Thanks to the high efficiency up to 94%, with the fanless design, the entire series is
able to operate for -40~ +90℃℃case temperature under free air convection. The design of metal housing
andIP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications.HLG-320H
is equipped with various function options, such asdimming methodologies, so as to provide the optimal design
flexibility for LED lighting system.
Constant Voltage + Constant Current mode output
Metal housing with classdesignI
IP67 / IP65 rating for indoor or outdoor installations
•Function options: output adjustable via potentiometer;
3 in 1 dimming
Typical lifetime > 62000 hours
7 years warranty
■Features■Applications
File Name:HLG-320H-SPEC 2016-04-29
FMM
110
SELV
IP65IP67
Type HL
Bauar
Sicherheit
egelgema
tgepruft
od
be
www.
ID2000000000
tuv.com
wacg
os
HLG--320H15A
Type
Blank
A
IP Level
IP67
IP65
Io and Vo fixed
Io and Vo adjustable through built-in potentiometer
FunctionNote
In Stock
In Stock
BIP673 in 1 dimming function (1~10VDC, 10V PWM signal and resistance)
Terminal block for I/O connection. Output voltage and constant current
level can be adjusted through internal potentiometer.
In Stock
C
D
------
IP67
By request
By request
Produktspezifikationen
| Marke: | Mean Well |
| Kategorie: | Nicht kategorisiert |
| Modell: | HLG-320H-24B |
| Breite: | 90 mm |
| Tiefe: | 256 mm |
| Gewicht: | 2030 g |
| Produktfarbe: | Silber |
| Höhe: | 43 mm |
| Energieschutzeigenschaften: | Over current, Over voltage, Short circuit |
| Zweck: | Lighting |
| Betriebstemperatur: | -40 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb: | 20 - 95 % |
| Temperaturbereich bei Lagerung: | -40 - 80 °C |
| Luftfeuchtigkeit bei Lagerung: | 10 - 95 % |
| Netzteiltyp: | Drinnen |
| Ausgangsstrom: | 13.34 A |
| Ausgangsspannung: | 24 V |
| Ausgangsleistung: | 320 W |
| Eingangsspannung: | 90-305 V |
| Nachhaltigkeitszertifikate: | RoHS |
| Eingangsfrequenz: | 47/63 Hz |
| Starkstromtyp: | AC-an-DC |
| Effizienz: | 94 % |
| Einstellbare Ausgangsspannung: | Ja |
