MEGATRON
®
LED Under Cabinet Luminaire – PINOLIGHT
TECHNICAL SPECIFICATION
Instruction Manual
Model Number
MT77223 MT77224 MT77225
Wattage 4W 7,5W 9,5W 13W
Luminous Flux 400lm 800llm 1000lm 1400lm
Voltage 220–240V~ 220–240V~ 220–240V~ 220–240V~
Frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz
Color Temperature 3.000�K/4.000�K 3.000�K/4.000�K 3.000�K/4.000�K 3.000�K/4.000�K
CRI Ra80 Ra80 Ra80 Ra80
Lifetime 25.000h 25.000h 25.000h 25.000h
On/Off >40.000x >40.000x >40.000x >40.000x
IP Rating IP20 IP20 IP20 IP20
Dimmable No No No No
CAUTIONS:
• Read the entire manual carefully before installation and operation.
• Installation or replacement should be performed only by licensed and qualified electricans.
• DO NOT disassemble the inner part of the luminaire. Doing so many result in luminaire damage or malfunction.
• Switch OFF the power source before installation, replacement and cleaning.
• Wearing gloves during installation is recommended to ensure the luminaire is kept in the best condition.
• Before replacement of the luminaire, turn it off and allow it to cool down. Heat-resistant gloves are mandatory when handling the
luminaire.
• Do not operate the luminaire if the external flexible cable or cord is damaged. The replacement of the luminaire should be
handled by a licensed and qualified electrician for safety purpose.
• The minimum safety distance from the illuminated object is 0,1m.
• The luminaire is non-dimable. Do not use in dimmer circuits!
• The light source of this fixture is not replaceable; when the light source reaches its end of life, replace the entire fixture.
• The manufacturer accepts no liability for any damage resulting from the misuse of the luminaire or from when is it used with inap-
propriate equipment.
• Consult your dealer if you have any enquiries.
• Important warning for drilling in walls: before drilling, make sure that there are no gas and water pipes or power lines behind
or near the drilling spots. Drilling and mounting should be performed only by qualified personnel. Be sure to pay attention at the
condition and material of the walls, as the mounting material is not suitable for all wall types. Please inquire about recommended
screws and raw plugs for your wall type and wall condition. The manufacturer accepts no liability for improper wall raw plug
mounting and the herefrom resulting damages.
----
0,1m
Part List:
Mounting Clips Screws and dowels Power Cord 180cm
MT77229 (connection)
Power Patch Cord 15cm
MT77222
MT77223
MT77224
MT77225
MT77222
MT77223
MT77224
MT77225
MT77222
MT77223
MT77224
MT77225
Not included in the delivery
2 pcs 3 pcs 2 pcs 3 pcs 1 pcs To be ordered separately
ATTENTION:
• Instant start is allowed.
• Designed only for indoor applications.
• The operating temperature of the luminaire is -20�C to +40�C.
IDV GmbH Birkenweiherstraße 2 D-63505 Langenselbold Germany www.megatron-licht.eu| | | |
GB
LED
IDV GmbH Birkenweiherstraße 2 D-63505 Langenselbold Germany www.megatron-licht.eu| | | |
GB
Correct disposal of this product
This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possi-
ble harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmental safe recycling.
INSTALLATION:
1. Mounting information:
• This luminaire is a class II luminaire and can only be used with 220-240V, 50/60Hz power supply.
• A distance of min. 60 cm has to be maintained between the luminaire and the water supply and/or the sink.
• Do not mount the luminaire over the cooking plate/area.
• Keep steam, dripping water and other liquids away from the luminaire.
2. Mounting:
3. Extension possibilities:
2.
Identify the preferred mounting location for the lumi-
naire before installation. Pay attention to the power
supply cable length for correct placement (6cm).
2.
Screw the supplied mounting clips to the marked
locations.
OFF
ON
1.
5.
3. 4.
Insert the supply cable and affix the luminaire into
the mounting clips. Connect the luminaire to the
mains.
If you connect several lights together, they will
be switched individually.
LED
25mm
Max.
20m length
3
2
1
The luminaires can be extended linearly or
through the corner connection power patch
cord MT77229 (A). To extend the luminaires
you have to remove the blind plug (B) from
the female connector side.
(A)
(B)
MEGATRON
®
LED Under Cabinet Luminaire – PINOLIGHT
Instruction Manual
Article No. Wattage (W) Lenght (mm) Luminaire (pcs)
MT77222 4 313 Max. 60
MT77223
7,5 573
Max. 35
MT77224 9,5 873 Max. 22
MT77225 13 1173 Max. 17
