INSTALLATION INSTRUCTIONS

99-5849CH

The World’s best kits.

®

MetraOnline.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 9/12/23 INST99-5849CH

ATTENTION:With the key out of the

ignition, disconnect the negative battery

terminal before installing this product.

Ensure that all installation connections,

especially the air bag indicator lights, are

plugged in before reconnecting the battery

or cycling the ignition to test this product.

NOTE: Refer also to the instructions

included with the aftermarket radio.

KIT COMPONENTS

• A) Radio trim panel • B) Radio brackets • C) Pocket • D) Heated seat buttons (L & R) Blank panels • E) #8 x 3/8” Phillips screws

(4)

• F) Panel clips (6)

• G) HVAC interface and wiring harness (not shown) • H) Antenna adapter (not shown)

TOOLS REQUIRED

• Panel removal tool • Phillips screwdriver

• 9/32” Socket wrench • Cutting tool

TABLE OF CONTENTS

Dash Disassembly ..............................................2-3

Kit Preparation .......................................................4

Kit Assembly

– ISO DIN radio provision with pocket .................5

– ISO DDIN radio provision ...................................5

Axxess Interface Installation ...........................6-10

Final Assembly ......................................................11

Configuration ...................................................12-14

WIRING & ANTENNA CONNECTIONS

Wiring Harness: Axxess interface built into kit

Antenna Adapter: Included with kit

USB Replacement Hubs: #AXFD-USB or

#AXFD-USB2 (sold separately)

Ford F150 2015-2020*

F250/350/450/550 XL 2020-2022*

Visit MetraOnline.com for more detailed information about

the product and up-to-date vehicle specific applications

* Models equipped

with 4.2-inch color

screen and single

zone climate controls

ABCD

F

E

KIT FEATURES

• ISO DIN radio provision with pocket • ISO DDIN radio provision

• Integrated passenger airbag indicator • Painted charcoal

• Included interface for climate and steering wheel functions

Note: This kit will not support the Pro Trailer Backup Assist™ feature, nor the

massaging seats.

Note: Factory B&O amplified sound systems require an additional interface,

sold separately. Part # AXA2B-FD1.
