Seite 1/10
2009-2019 Microchip Technology Inc. DS00003016A-page 1
GENERAL DESCRIPTION
It is the purpose of this document to provide a list of suggested magnetics for use with the Microchip LAN family of prod-
ucts. The manufacturer, part number, package, number of cores, operating temperature range, and conguration are
included for each suggested magnetic. Each product family table is categorized into “Qualied Magnetics” and “Sug-
gested Magnetics” as dened below:
QUALIFIED MAGNETICS
Magnetics listed under this heading have been tested in order to verify proper operation with the specic Microchip
device listed with it. The testing accomplished has been either formal UNH 100BASE-TX PMD testing, UNH 10BASE-
T MAU testing and/or in-house testing performed by Microchip. The designer can assume with a high degree of con-
dence, that with proper PCB design techniques, the combinations of Microchip devices and magnetics presented in this
category will perform to the highest standards.
SUGGESTED MAGNETICS
Magnetics listed under this heading have not been tested in order to verify proper operation with the specic Microchip
device listed with it. This category of magnetic has been evaluated by the contents of the vendor supplied data sheet
and legacy performance only. However, the designer can assume with some degree of condence, that with proper PCB
design techniques, the combinations of Microchip devices and magnetics presented in this category will perform to high
standards. Magnetics in this category have been targeted for future Qualication Testing. Magnetics in this category may
or may not advance to the Qualied Magnetics category. It is important to note, there is the remote possibility that a
Suggested Magnetic, upon failing Qualication Testing, may be removed from the Suggested Magnetic category at any
time by Microchip.
AN 8.13
Suggested Magnetics
AN 8.13
DS00003016A-page 2 2009-2019 Microchip Technology Inc.
LAN8187, LAN8700, LAN8710, LAN8720, LAN9131, LAN9132, LAN9210, LAN9211, LAN9215, LAN9217,
LAN9218, LAN9220, LAN9221, LAN9303, LAN9303M, LAN9311, LAN9312, LAN9313, LAN9420, LAN9500,
LAN9500A, LAN9512, LAN9513, LAN9514
Qualied Magnetics
Vendor Part Number Package Cores Temp Conguration
Pulse H1102 16-pin SOIC 4 0 - +70 C HP Auto-MDIX
Halo TG110-RP55N5 16-pin SOIC 4 0 - +70 C HP Auto-MDIX
Halo HFJ11-RP26E-
L12RL
Integrated RJ45 4 0 - +70 C HP Auto-MDIX
POE
Delta RJSE1R5310A Integrated RJ45 4 0 - +70 C HP Auto-MDIX
Suggested Magnetics
Pulse J0011D01B Integrated RJ45 4 0 - +70 C HP Auto-MDIX
Midcom 000-7219-35 Cardbus 4 0 - +70 C HP Auto-MDIX
Bothhand TS6121C 16-pin SOIC 4 0 - +70 C HP Auto-MDIX
Bothhand LU1S041X-43 Integrated RJ45 4 0 - +70 C HP Auto-MDIX
LAN8187i, LAN8700i, LAN8710i, LAN8720i, LAN9215i, LAN9218i, LAN9221i, LAN9303i, LAN9303Mi,
LAN9311i, LAN9313i, LAN9420i, LAN9500i, LAN9500Ai, LAN9512i, LAN9513i, LAN9514i
Qualied Magnetics
Vendor Part Number Package Cores Temp Conguration
Pulse HX1188 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
Halo TG110-RPE5N5 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
Halo HFJ11-RPE26E-
L12RL
Integrated RJ45 4 -40 - +85 C HP Auto-MDIX
POE
TDK TLA-6T717W Integrated RJ45 4 -40 - +85 C HP Auto-MDIX
Delta LFE8505T 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
Suggested Magnetics
Midcom 000-7090-37R 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
Midcom MIC66211-5171T-
LF3
Integrated RJ45 4 -40 - +85 C HP Auto-MDIX
POE
Elec & Eltek 820-M0323R 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
2009-2019 Microchip Technology Inc. DS00003016A-page 3
AN 8.13
LAN7500
Qualied Magnetics
Vendor Part Number Package Cores Temp Conguration
Halo HFJ11-1G02E Integrated RJ45 8 0 - +70 C HP Auto-MDIX
Suggested Magnetics
Halo TG1G-S002NZRL 24-pin SOIC-W 8 0 - +70 C HP Auto-MDIX
LAN8810i, LAN7500i
Suggested Magnetics
Vendor Part Number Package Cores Temp Conguration
Halo TG1G-E012NZRL 24-pin SOIC-W 8 -40 - +85 C HP Auto-MDIX
LAN89218, LAN89303
Suggested Magnetics
Vendor Part Number Package Cores Temp Conguration
Halo TG110-AE050N5 16-pin SOIC 4 -40 - +85 C HP Auto-MDIX
Halo TG110-AEX50N5LF 16-pin SOIC 4 -40 - +125 C HP Auto-MDIX
