2011-2021 Microchip Technology Inc.DS40001585E-page 1
PIC10(L)F320/322
High-Performance RISC CPU
•Only 35 Instructions to Learn:
-All single-cycle instructions, except branches
•Operating Speed:
-DC – 16MHz clock input
-DC – 250ns instruction cycle
•Eight-Level Deep Hardware Stack
•Interrupt Capability
•Processor Self-Write/Read access to Program
Memory
•Pinout Compatible to other 6-Pin PIC10FXXX
Microcontrollers
Memory
•Up to 512 Words of Flash Program Memory
•64 Bytes Data Memory
•High-Endurance Flash Data Memory (HEF)
-128B of nonvolatile data storage
-100K erase/write cycles
Special Microcontroller Features
•Low-Power 16MHz Internal Oscillator:
-Software selectable frequency range from
16 MHz to 31 kHz
-Factory calibrated to 1%, typical
•Wide Operating Range:
-1.8V to 3.6V (PIC10LF320/322)
-2.3V to 5.5V (PIC10F320/322)
•Power-on Reset (POR)
•Power-up Timer (PWRT)
•Brown-out Reset (BOR)
•Ultra Low-Power Sleep Regulator
•Extended Watchdog Timer (WDT)
•Programmable Code Protection
•Power-Saving Sleep mode
•Selectable Oscillator Options (EC mode or
Internal Oscillator)
•In-Circuit Serial Programming™ (ICSP™) (via
Two Pins)
•In-Circuit Debugger Support
•Fixed Voltage Reference (FVR) with 1.024V,
2.048V and 4.096V (‘F’ variant only) Output
Levels
•Integrated Temperature Indicator
•40-year Flash Data Retention
eXtreme Low-Power (XLP) Features
(PIC10LF320/322)
•Sleep Current:
-20nA @ 1.8V, typical
•Operating Current:
-25A @ 1MHz, 1.8V, typical
•Watchdog Timer Current:
-500nA @ 1.8V, typical
Peripheral Features
•Four I/O Pins:
-One input-only pin
-High current sink/source for LED drivers
-Individually selectable weak pull-ups
-Interrupt-on-Change
•Timer0: 8-Bit Timer/Counter with 8-Bit
Programmable Prescaler
•Timer2: 8-Bit Timer/Counter with 8-Bit Period
Register, Prescaler and Postscaler
•Two PWM Modules:
-10-bit PWM, max. frequency 16kHz
-Combined to single two-phase output
•A/D Converter:
-8-bit resolution with three channels
•Configurable Logic Cell (CLC):
-Eight selectable input source signals
-Two inputs per module
-Software selectable logic functions including:
AND/OR/XOR/D Flop/D Latch/SR/JK
-External or internal inputs/outputs
-Operation while in Sleep
•Numerically Controlled Oscillator (NCO):
-20-bit accumulator
-16-bit increment
-Linear frequency control
-High-speed clock input
-Selectable Output modes
-Fixed Duty Cycle (FDC)
-Pulse Frequency (PF) mode
•Complementary Waveform Generator (CWG):
-Selectable falling and rising edge dead-band
control
-Polarity control
-Two auto-shutdown sources
-Multiple input sources: PWM, CLC, NCO
6/8-Pin Flash-Based, 8-Bit Microcontrollers
